Summary of Contents for Heritage Bathrooms Dartmouth TDACC310
- Page 1 Installation Guide Models Covered: Dartmouth 3 Hole Wall Mounted Basin Mixer TDACC310 / TDACBB310 / TDACBL310 Please keep this booklet for future reference. Installer: When you have read these instructions, please ensure you leave them with the user.
-
Page 2: Table Of Contents
I N T R O D U C T I O N Thank you for buying a Heritage Product. When you buy a Heritage product, you can be confident that it not only features a beautiful, distinctive, classic design, but that it has also been made to the very highest quality standards. -
Page 3: Safety Notes
S A F E T Y N O T E S All products manufactured and supplied by If power tools are used do not forget to: Heritage are safe to use provided that they - Wear eye protection are installed, operated and receive regular - Unplug equipment after use maintenance in accordance with these instructions. -
Page 4: Pack Contents
P A C K C O N T E N T S T O O L S R E Q U I R E D Cross Head Adjustable Pipe Cutter Drill Screwdriver Spanner 17mm Socket Electronic 2.5mm Safety Goggles Spanner Detector Hexagonal Key... -
Page 5: Prior To Installation
P R I O R T O I N S TA L L AT I O N Typical Installation Plan your installation, ensuring that the spout projection of the mixer will be able to reach inside your basin. Rear Access Point Supporting Baton... -
Page 6: Installation
P R I O R T O I N S TA L L AT I O N Diameter of Centre Point Take note of the following dimensions when Each Handle/ Valves fitting, or mark on the fitting location where Spout Shroud Edges needed. - Page 7 I N S TA L L AT I O N Mark and drill the Front fixing holes (4mm Cut-Out Rear Access drill size). Secure Point the valve body using suitable fixings for REMEMBER Refer to the critical dimensions on pg. 5. Allow Baton for the wall finish when...
-
Page 8: Operation
I N S TA L L AT I O N Operation Cold Cold Push up the handle shrouds and fit the handles using the grub screws and fit the handle caps. Screw 2.5mm the shrouds on to the fittings to secure. -
Page 9: Maintenance
M A I N T E N A N C E To Replace Valves Undo the Undo the screws to screws to remove remove the spline the spline adaptors. adaptors. Undo the grub Undo the grub screws and caps to screws and caps to Use a 17mm socket Use a 17mm socket... -
Page 10: Spare Parts
M A I N T E N A N C E Clean/Replace Outlet Using a coin, Using a coin, unscrew unscrew to remove to remove the aerator, the aerator, including the including the O-Ring. O-Ring. Check the aerator and seal for any damage, replace if necessary. -
Page 11: Caring For Your Product
C A R I N G F O R Y O U R P R O D U C T Heritage products are made from premium materials, with hand polished, electroplated, PVD or EPD finishes. Your taps or shower should be regularly cleaned with warm water, a mild pH-neutral liquid soap, and polished with a soft cloth. - Page 12 If you have any queries, our dedicated customer service teams and products experts are available to help. www.heritagebathrooms.com Website enquire@heritagebathrooms.com 0330 026 8503 Email us Call us UK: Heritage Bathrooms, Pooley Hall Drive, Birch Coppice Business Park, Dordon, Tamworth B78 1SG EU: Masco Europe S.à.r.l., 14 Rue Strachen, 6933 Mensdorf, Luxembourg.
