- Page 1 Installation Guide Models Covered: Dartmouth Bath Shower Mixer TDACC02 / TDACBB02 / TDACBL02 Dartmouth Bath Filler TDACC07 / TDACBB07 / TDACBL07 Please keep this booklet for future reference. Installer: When you have read these instructions, please ensure you leave them with the user.
-
Page 2: Table Of Contents
I N T R O D U C T I O N Thank you for buying a Heritage Product. When you buy a Heritage product, you can be confident that it not only features a beautiful, distinctive, classic design, but that it has also been made to the very highest quality standards. -
Page 3: Safety Notes
S A F E T Y N O T E S All products manufactured and supplied by If power tools are used do not forget to: Heritage are safe to use provided that they - Wear eye protection are installed, operated and receive regular - Unplug equipment after use maintenance in accordance with these instructions. -
Page 4: Pack Contents
P A C K C O N T E N T S Bath Filler Bath Shower Mixer TDAC__02 TDAC__07 T O O L S R E Q U I R E D Cross Head Adjustable 32mm Drill Screwdriver Spanner Box Spanner 17mm Socket Electronic 2.5mm, 2mm... -
Page 5: Installation - Bath Shower Mixer
I N S TA L L AT I O N - B AT H S H O W E R M I X E R Secure the tap to the bath by using the washers and metal Fit the tap to the bath, Fit the tap to the bath, backnuts below the bath. - Page 6 I N S TA L L AT I O N - B AT H S H O W E R M I X E R Plan where to install the wall bracket, Screw the wall bracket to the wall. making sure the hose and handset can Use wall plugs where necessary depending easily reach.
-
Page 7: Installation - Bath Filler
I N S TA L L AT I O N - B AT H F I L L E R Secure the tap to the bath Fit the tap to the bath, by using the washers and metal ensuring the plinths backnuts below the bath. -
Page 8: Maintenance
M A I N T E N A N C E To Replace Valves Undo the screws to remove the spline adaptors. Use a 17mm socket spanner to Remove cap and undo the remove the valves. grub screws to remove the handles. - Page 9 M A I N T E N A N C E Clean/Replace Outlet Using a 16mm aerator key (not supplied), unscrew the outlet and remove, including the O-Ring. Visit our website to purchase your outlet key if required. Check the outlet and seal for any damage, replace if necessary.
- Page 10 M A I N T E N A N C E To Replace Diverter Unscrew and remove the rear cap Unscrew the grub screw securing the using a coin. Use a 2.5mm hex key to 2.5mm spout and lift the spout off. remove the diverter peg.
-
Page 11: Caring For Your Product
M A I N T E N A N C E Push the diverter spline through the body and Reverse steps 1-5 to replace out the back of the product (use a long hex key the diverter assembly. to avoid the spline dropping inside the body). C A R I N G F O R Y O U R P R O D U C T Heritage products are made from premium materials, with hand polished, electroplated, PVD or EPD finishes. -
Page 12: Troubleshooting
T R O U B L E S H O O T I N G Symptom Cause Remedy Partially closed isolation valve. Open isolation valve. Instantaneous water heater cycles on Increase water flow rate or pressure and off as flow rate or pressure is too through system. -
Page 13: Guarantee
G U A R A N T E E The confidence we have in the quality of our products and services enables us to offer a free peace-of-mind product guarantee from 2 years up to a lifetime guarantee against any manufacturing faults, with proof of purchase. - Page 14 N O T E S...
- Page 15 N O T E S...
- Page 16 If you have any queries, our dedicated customer service teams and products experts are available to help. www.heritagebathrooms.com Website enquire@heritagebathrooms.com 0330 026 8503 Email us Call us UK: Heritage Bathrooms, Pooley Hall Drive, Birch Coppice Business Park, Dordon, Tamworth B78 1SG EU: Masco Europe S.à.r.l., 14 Rue Strachen, 6933 Mensdorf, Luxembourg.
