- Page 1 INSTALLATION GUIDE MODELS COVERED: Wilton Vanity Units Please keep this booklet for future Reference. Installer: when you have read these instructions please ensure you leave them with the user.
-
Page 2: Table Of Contents
INTRODUCTION Thank you for buying a Heritage Product. When you buy a Heritage product, you can be confident that it not only features a beautiful, distinctive, classic design, but that it has also been made to the very highest quality standards. To ensure that it works to its full potential, it needs to be fitted correctly. These fitting instructions have been created to give you all of the information you need and, if you need any further help, please do not hesitate to give us a call on 0330 026 8503. -
Page 3: Safety Note
SAFETY NOTE Please read these instructions and retain for future use. All products manufactured and supplied by Heritage are safe, provided they are installed correctly, used correctly, and receive regular maintenance in accordance with these instructions. If you are in any doubt about your ability to install this product safely you must employ the services of an competent person who has experience of fitting products of this nature. -
Page 4: Dimensions
DIMENSIONS 600mm Freestanding Unit 800mm Freestanding Unit... - Page 5 DIMENSIONS 1000 1010 Right Hand Corner Unit Right Hand Unit Shown Left Hand Corner Unit 1200 1220 1200mm Curved Unit...
-
Page 6: Installation
INSTALLATION OF VANITY UNITS The unit shown in these instructions are for illustration purposes only. All products in this range can be fitted using the guide below. To level the unit, adjust the feet underneath. IMPORTANT (Curved Units Only) Make sure that the length of screws will not damage the internal or external... - Page 7 INSTALLATION OF VANITY UNITS SECURING THE WORKTOP Once your Heritage Wilton Worktop and Undercounter Basin are ready to install, apply Follow the instructions silicone sealant along the vanity unit before placing that are supplied with the worktop, secure and wipe off any excess. your worktop and basin for installation information GOOD TO KNOW...
-
Page 8: Fitting Door Hinges
DOOR ADJUSTMENT QUICK MOUNTING RELEASE PLATE DOOR/ HINGE FIXINGS Clip the hinge into the front of the mounting plate VANITY on inside of unit first before pushing the back of the UNIT hinge against the plate it clips into position. Adjust the door as required- see Hinge Adjustment diagram. -
Page 9: Caring For Your Product
C A R I N G F O R Y O U R P R O D U C T Your furniture unit has a high quality finish and should be treated with care to preserve the visible surface. A few tips for preventing defects from forming: Occasionally wipe the surface with a soft damp cloth and dry with a soft dry cloth. - Page 10 If you have any queries, our dedicated customer service teams and products experts are available to help. www.heritagebathrooms.com Website enquire@heritagebathrooms.com 0330 026 8503 Email us Call us Heritage Bathrooms Pooley Hall Drive, Birch Coppice Business Park, Dordon, Tamworth B78 1SG Wilkton Vanity Units - D1...
