Note: Please refer to the original service manual for:
DVD Mechanism Unit (BRS11D), Order No. PSG1201015AE
Speaker system SB-XH175EP-K, Order No. PSG1202026CE

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Before Repair and Adjustment ------------------------- 4
1.3. Protection Circuitry ---------------------------------------- 4
1.5. Caution For Fuse Replacement------------------------ 6
1.6. Safety Part Information----------------------------------- 6
2 Warning -------------------------------------------------------------- 7
DVD Home Theater Sound System
Model No.
Product Color: (K)...Black Type
PAGE
2.2. Precaution of Laser Diode -------------------------------8
3 Service Navigation --------------------------------------------- 12
3.1. Service Information -------------------------------------- 12
4 Specifications ---------------------------------------------------- 13
4.1. Others (Licences) ---------------------------------------- 14
© Panasonic Corporation 2012. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
SA-XH175EE
SA-XH175GS
PSG1202022CE
PAGE
