Asus D700SD Service Manual
Hide thumbs Also See for D700SD:

Advertisement

Quick Links

Service Overview
D700SD_ Service_manual
COPYRIGHT INFORMATION
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC.("ASUS").
ASUS PROVIDES THIS MANUAL "AS IS"WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR
DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR INTHIS MANUAL OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owners' benefit, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE
FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECTTO CHANGE AT
ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A
COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY
ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE
PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Copyright ○
2023 ASUSTeK COMPUTER INC. All Rights Reserved.
c
LIMITATION OF LIABILITY
Circumstances may arise where because of a default on ASUS' part or other liability, you are entitled to
recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to
claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death)
and damage to real property and tangible personal property; or any other actual and direct damages resulted
from omission or failure of performing legal duties under this Warranty Statement, up to the listed contract
price of each product.
1-1
V1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the D700SD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Asus D700SD

  • Page 1 2023 ASUSTeK COMPUTER INC. All Rights Reserved. LIMITATION OF LIABILITY Circumstances may arise where because of a default on ASUS' part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and tangible personal property;...
  • Page 2 Service Overview ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement. This limit also applies to ASUS' suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible.
  • Page 3: Service Overview

    Desktop and necessary cautions and tools before performing any service and repairs. o provide the best service and support for the ASUS DESKTOP D700SD .we have provided the below information for technicians from distributors and resellers to perform the complete Desktop disassembly and assembly.
  • Page 4: Front View

    Disassembly Procedure DESK TOP PC D700SD Overview The illustrations below show the Desktop PC’s overview from front view, side view and back view. Most of the parts will be discussed in this manual. FRONT VIEW Refer to the following diagram to identify the components on this front of the system.
  • Page 5: Front Bezel

    Disassembly Procedure Components The illustrations below show the components of the D700SD. FRONT BEZEL FRONT BEZEL ASSY According to shipments on location Hard Disk Drive According to shipments on location According to shipments on location 2 - 5...
  • Page 6: Mother Board

    Disassembly Procedure According to shipments on location Mother Board Memory According to shipments on location 2 - 6...
  • Page 7: Power Supply

    Disassembly Procedure Power Supply According to shipments on location VGA CARD WLAN Module 2 - 7...
  • Page 8 Disassembly Procedure FAN DUCT According to shipments on location FAN DUCT REAR SW BOARD According to shipments on location 2 - 8...
  • Page 9: Smart Board

    Disassembly Procedure SMART BOARD According to shipments on location HDD HOUSING Cable & Others ODD & Cable According to shipments on location 2 - 9...
  • Page 10 Disassembly Procedure HDD CABLE According to shipments on location HDD PW CABLE SW cable SMART BOARD cable ( W.H CABLE 2.54 1*5P TO 5P) 2 - 10...
  • Page 11: Disassembly And Assembly

    Be sure to use proper tools described before. SUS Desktop PC D700SD consists series of various modules. This chapter describes the procedures for the complete Desk Top PC disassembly and assembly (Assemble process please look up from the last page). In addition, in between procedures, the detailed disassembly procedure of individual modules will be provided for your service needs.
  • Page 12 Disassembly Procedure Disassembly Caution ASUS hereby provides a basic instruction for the disassembly of ASUS products, i.e. to remove components and materials that require selective treatments, which are defined by Annex II of the European Union (EU) Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC.
  • Page 13 Disassembly Procedure Appropriate Tools The illustrations below show the appropriate tools that should be used for the Desktop service and repair. Automatic Screwdriver Plastic Blade Antistatic Gloves 2 - 13...
  • Page 14: Power Off

    Disassembly Procedure POWER OFF The illustrations below show how to remove the power cable from the Desk Top PC. 1.Remove the power cord by pulling it from the arrow side. Parts ⚫ AC POWER CORD*1 2 - 14...
  • Page 15: Side Cover

    Disassembly Procedure SIDE COVER The illustrations below show how to remove the side cover from the Device. 1.Loosen 2 screws of red circle, if you will latch it, please following the step back. 2.Pulling out the left side deco bezel. Parts ⚫...
  • Page 16 Disassembly Procedure Front Bezel The illustrations below show how to remove the Front Bezel from the Device 1. Press the arrow to lift the clasp. 2.Remove the Front Bazel slowly. Assemble Notice: 2 - 16...
  • Page 17 Disassembly Procedure 2 - 17...
  • Page 18 Disassembly Procedure 3 .The Front of device. Parts ⚫ FRONT BEZEL ASSY//SUNPRO 2 - 18...
  • Page 19 Disassembly Procedure FAN DUCT FAN DUCT The illustrations below show how to remove the from the Desk Top PC. 1 .Open the cover in the direction of the arrow. 2. Remove FAN DUCT. 2 - 19...
  • Page 20 Disassembly Procedure 3.Remove 2 screws from the FAN DUCT REAR. Parts ⚫ Total screw *2 ⚫ FAN DUCT*1 ⚫ FAN DUCT REAR*1 2 - 20...
  • Page 21 Disassembly Procedure Memory Module The illustrations below show how to remove the power cable from the Desk Top PC. (Example) 1 Press the button in the direction of the arrow. 2. Hold both sides of the memory module with both hands and pull it out vertically. Parts ⚫...
  • Page 22 Disassembly Procedure VGA CARD The illustrations below show how to remove the VGA CARD from the Desk Top PC Remove 2 screws on the PCI iron of the top cover. 2.Remove the VGA CARD. Parts VGA CARD*1 ⚫ Total screw* 2 ⚫...
  • Page 23 Disassembly Procedure WLAN Module The illustrations below show how to remove the WLAN Module from the Desk Top PC Remove the external WIFI antenna. Remove 2 ACETATE tape & 1 screw on the WLAN card and disconnect WIFI antenna. 2 - 23...
  • Page 24 Disassembly Procedure Assemble Notice: 2 - 24...
  • Page 25 Disassembly Procedure Parts ⚫ WIFI6 AX+BT5.2(2*2)M.2 2230 *1 ⚫ Total screws 1 SSD & Card Reader Board The illustrations below show how to remove the Card Reader Board. 1.Remove 1 screw and take out the SSD. 2 - 25...
  • Page 26 Disassembly Procedure 2.Remove SSD pad, disconnect W.H CABLE 2.54 1*5P TO 5P on the SMART CARD READER BD and remove 4 screws. Pull up 2 - 26...
  • Page 27 Disassembly Procedure Notice:Please add CRD MYLAR * 3 when you assemble the Card Reader Board. 2 - 27...
  • Page 28 Disassembly Procedure Assemble notice: Smart BD Cable assemble notice 2 - 28...
  • Page 29 Disassembly Procedure Cables arrange notice!!! Please follow below picture to assemble different SSD.(PCIE/OPTANE/SATA SSD) 2 - 29...
  • Page 30 Disassembly Procedure Notice:1.If only install 1 pc SSD,please install it on smart card .2.If install 2 pcs SSD, please choose the faster or lowerer capacity to install on the smart card .3.Install the OS in the SSD on the smart card. Parts ⚫...
  • Page 31 Disassembly Procedure POWER SUPPLY The illustrations below show how to remove the power supply from the Device. (example) 1.Cut the white cable tie and disconnect and disconnect CPU Power Supply cables (4 PIN and 6PIN) 2.Remove 3 screws from the PSU and take out it. 2 - 31...
  • Page 32 Disassembly Procedure PSU assemble Notice: Parts ⚫ Total screw *3 ⚫ PSU TFX 2 - 32...
  • Page 33 Disassembly Procedure ODD & HDD(Option) The illustrations below show how to remove the ODD & HDD from the Device. 1.Disconnect ODD cable,ODD power cable. Remove 2 screws from the ODD TOOLESS HOLDER and take out it. 2. Disconnect HDD&ODD Power Supply cable. 2 - 33...
  • Page 34 Disassembly Procedure 3.Disconnect HDD cable,HDD power cable and take out it. 2 - 34...
  • Page 35 Disassembly Procedure HDD Assemble notice: Installing the 90 SATA HDD CABLE to the connector of the HDD, follow the picture as shown Installing the HDD PW CABLE to the connector of the HDD, follow the picture as shown. 2 - 35...
  • Page 36 Disassembly Procedure Parts ⚫ SATA3 HDD 1TB 7200RPM 3.5'*1 ⚫ HDD HOUSING ⚫ DVD S-MULTI DL 8X/6X/8X6X/5X *1 ⚫ HDD PW CABLE ⚫ Total screw *2 2 - 36...
  • Page 37: Power Switch Board

    Disassembly Procedure POWER SWITCH BOARD The illustrations below show how to remove the SW BOARD board from the Device 1 .Remove 2 screws to remove the POWER SWITCH BOARD and SW CABLE . POWER SWITCH BOARD SW CABLE 2 - 37...
  • Page 38 Disassembly Procedure 2. Remove 1 screw on the FIO SHIELD. Parts ⚫ POWER SWITCH BD.*1 ⚫ SW cable *1 FIO SHIELD*1 ⚫ ⚫ W.H CABLE 2.54 1*5P TO 5P*1 ⚫ Total screw *3 2 - 38...
  • Page 39 Disassembly Procedure CPU COOLER & CPU The illustrations below show how to remove the CPU COOL & CPU from the Device. 1.The cable route of CPU fan. 2.Loosen the 4 screws follow the number Assemble notice: follow the number to screw. 2 - 39...
  • Page 40 Disassembly Procedure 3 . Pull up the thermal. 4.Pull out the CPU pole and Lift the other end of the CPU bar about 100 and take CPU away. Lift the other end of the CPU bar about 100 and take CPU away. ‘...
  • Page 41 Disassembly Procedure *Pin facing down on Processor Packaging* *Please note that if you wish to install directional, CPU triangle must be aligned MB triangle * 2 - 41...
  • Page 42 Disassembly Procedure Parts CPU COOLER*1 ⚫ ⚫ CPU *1 Assembly Notice: For CPU COOLER Assembly, please follow the pic bellow to stick mainboard washer *4pcs before assemble the CPU COOLER. (ECN CHANGE). Pick up mainboard washer *4pcs (P/N: 13PF03B0L02011) through the ILM nuts (as shown in figure 1 red circle) and stick then on the mainboard, and used finger to press the washer to make sure it firmly stick on the mainboard (as shown in figure 2 purple circle).
  • Page 43 Disassembly Procedure MIAN BOARD The illustrations below show how to remove the MB from the Device (example) 1.Remove 2 screws and take out the IO Bracket. SCREW #6-32 5L NI // IN WIN/ 8.0±0.8kgf/cm 2.Remove 9 screws from MB and take MB away. 2 - 43...
  • Page 44 Disassembly Procedure Assemble notice: a. Install the M/B into Chassis in accordance with graphic presentation.Can't shave and can't leak to injure M/B and I/O shell fragment b.Locking 4 screws in diagonal sequence (from 1 to 4) then use screws to secure the MB in clockwise from outside to inside way(refer the below MB ).
  • Page 45 Disassembly Procedure c. After installing M/B to chassis make sure that all of the port of M/B have already faced outwards. USB AL FOIL TPM MODULE 2 - 45...
  • Page 46 Disassembly Procedure MOS PAD &CHOKE PAD D700SD MOS PAD 80X10X7.5 CHOKE PAD 80X7.5X6.5 Parts ⚫ Total screw *11 D700SD MAIN BD. ⚫ 2 - 46...
