MODEL / MODELO:
OGGM3901
Manual de Instrucciones
MICROONDAS
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR ESTE APARATO
Instruction Manual
MICROWAVE OVEN
READ ALL INSTRUCTIONS BEFORE USING THIS DEVICE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OGGM3901 and is the answer not in the manual?

Questions and answers

Summary of Contents for Oster OGGM3901

  • Page 1 MODEL / MODELO: OGGM3901 Manual de Instrucciones MICROONDAS LEA TODAS LAS INSTRUCCIONES ANTES DE USAR ESTE APARATO Instruction Manual MICROWAVE OVEN READ ALL INSTRUCTIONS BEFORE USING THIS DEVICE...
  • Page 2: Table Of Contents

    I N DI CE INSTRUCCIONES DE SEGURIDAD IMPORTANTES............2 GUÍA DE INSTALACIÓN......................5 INSTRUCCIONES DE CONEXIÓN..................6 DIAGRAMA DEL PRODUCTO.....................8 PANEL DE CONTROL......................9 INSTRUCCIONES DE OPERACIÓN.................10 GUÍA DE UTENSILIOS......................15 MANTENIMIENTO ......................17 Español-1...
  • Page 3 &/ ! 93 86 ; 5 6 7 /5 B6 84 2 2 / 3 5 7 B& >7 & B7C 4 8/>; > .?@ABC(?DEFEGH(@I@J@DCK(HFLGDJEGCK(BHMH(KHN?EJ(EAKDJ?GGECAHK(BH(KHN?JEB@B(MOKEG@KP(EAGF?QHAR BC(F@K(KEN?EHADHKS( '()*+,*-./'0 T( 1@J@( JHB?GEJ( HF( JEHKNC( BH( U?HV@B?J@KP( GWCU?H( HFLGDJEGCP( EAGHABECP( FHKECAHK(@(IHJKCA@K(C(HXICKEGEYA(@(HAHJNZ@(BH(VEGJCCAB@K(HXGHKE[@S( ;2(%H@(DCB@K(F@K(EAKDJ?GGECAHK(@ADHK(BH(?DEFE\@J(F@(@IFEG@GEYA2( 32(%H@(Q(KEN@(F@K(HKIHGZ]EG@KS(12+*.'3./!-*402'+'0*)/,'+02!4/56*0*72!4/./8-0'0 *-*+"9'0#/.+!!-('40*7.*4/)':;...
  • Page 4 Para reducir el riesgo de lesiones a personas: 1. No sobrecaliente los líquidos. 2. Revuelva el líquido antes y a la mitad de la cocción. 3. No use contenedores con lados rectos y cuellos angostos. 4. Después de calentar, permita que el contenedor se mantenga en el horno microondas por un período de tiempo corto antes de retirarlo.
  • Page 5: Guía De Instalación

    GU Í A DE I N STA L A CI Ó N INSTALACIÓN DE COCINA Remueva todo el material de empaque y tector encontrado en el microondas o en accesorios. Examine la puerta del horno para cualquier daño como dentaduras o cobertura de Mica color café...
  • Page 6: Instrucciones De Conexión

    IN S T R UC C I O N E S D E C ON E X IÓ N Este electrodoméstico debe estar conectado a tierra. En el evento de un corto circuito eléctrico, el estar conectado a tierra reduce el riesgo de choque eléctrico al proveer un cable de escape para la corriente eléctrica.
  • Page 7 INTERFERENCIA RADIAL 1. Operar el microondas puede causar interferencia en su radio, TV o equipo similar. 2. Cuando hay interferencia, puede ser reducida o eliminada al tomar las siguientes me- didas: 2. Reoriente la antena receptora del radio o televisión 3.
  • Page 8: Diagrama Del Producto

    D I A G R AM A DE P R OD U CTO NOMBRES DE PARTES DEL HORNO Y ACCESORIOS Remueva el horno y todos los materiales del cartón y la apertura del horno. Su horno viene con los siguientes accesorios: Bandeja de vidrio 1 Anillo de tornamesa 1 Manual de instrucciones 1...
  • Page 9: Panel De Control

    PA N E L DE CO N T RO L Tiempo de Descongelado Descongelado Cocción por Tiempo por Peso Potencia Reloj Temporizador Palomitas Papas Pizza de Maíz Vegetales Bebidas Cena Congelados COCCIÓN RÁPIDA DETENER INICIAR Cancelar Memoria 1. Tiempo de cocción 8.
  • Page 10: Instrucciones De Operación

    I NS T R U C CI O N E S D E O P E R A CI Ó N 1. Nivel de Energía 10 niveles de energía están disponibles. 2. Opciones de Reloj 1. Presione reloj una vez, “00:00” aparecerá en el display. 2.
  • Page 11 nivel de energía. 4. Presione “Iniciar/+30Seg.” Para iniciar la cocción. Ejemplo: Para cocinar la comida con 50% de nivel de energía de microondas por 15 minutos. a. Presione “Tiempo de Cocción” una vez. Aparecerá “00:00”. b. Presione “1,5,0,0” en ese orden. c.
  • Page 12 8. Palomitas de Maíz a. Presione “Palomitas de Maíz” repetidamente hasta que el número que usted desea aparezca en el display “1.75”, “3.0”, “3.5” Onz aparecerán en ese orden. Por ejemplo, presione “Palomitas de Maíz” una vez, aparecerá “1.75”. b. Presione “Iniciar/+30Seg.” Para cocinar, la alarma sonará una vez. Cuando la coc- ción termine la alarma sonará...
  • Page 13 display, “4.0”, “8.0”, “14.0” Onz aparecerán en ese orden. Por ejemplo presione “Pizza” una vez, “4.0” aparecerá. b. Presione “Iniciar/+30Seg.” Para cocinar, la alarma sonará una vez. Cuando la coc- 14. Función Memoria a. Presione “Memoria” para elegir procesos de 1-3. La pantalla mostrara 1,2,3. guardar el proceso.
  • Page 14 16. Función de bloqueo para niños Bloqueo: En modo de espera, presione “Detener/Cancelar” por 3 segundos, habrá una alarma larga denotando el ingreso al modo de bloqueo para niños; mientras tanto el dis- ” play mostrará “ Para deshabilitar el bloqueo, mantenga presionado el botón D “...
  • Page 15: Guía De Utensilios

    G U Í A DE U T EN S IL IO S ADVERTENCIA Riesgo de lesión personal Los utensilios cerrados ajustadamente podrían explotar. Contenedores cerrados deberán ser abiertos y bolsas plásticas deberán ser perforadas antes de cocinar. Vea las instrucciones en “Materiales que puede utilizar en un horno microondas o a evitar en un horno microondas.”...
  • Page 16 El foam plástico puede derretirse o contaminar el líquido dentro cuando se expone Foam plástico a temperaturas altas. La madera se seca al utilizar en microondas y puede quebrarla o rajarla. Madera ESPECIFICACIONES OGGM3901 Modelo: 120V~60Hz Energía de Introducción 1250W (Microondas): 800W Energía de Emisión (Microondas):...
  • Page 17: Solución De Problemas

    M A N T EN IMIE N TO Solución de Problemas Revise su problema utilizando la tabla inferior e intente las soluciones para cada proble- ma. Si el microondas sigue sin funcionar apropiadamente, contacte al contacto de servicio autorizado más cercano. PROBLEMA POSIBLE CAUSA POSIBLE REMEDIO...
  • Page 18 INDEX IMPORTANT SAFETY INSTRUCTIONS...............2 INSTALLATION GUIDE..................4 GROUNDING INSTRUCTIONS................4 PRODUCT DIAGRAM...................6 CONTROL PANEL....................7 OPERATING INSTRUCTIONS................8 UTENSILS GUIDE....................13 MAINTENANCE ....................15 English-1...
  • Page 19: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances basic safety precautions should be followed, including following: To reduce the risk of burns, electric shock, fire, injury to persons or exposure WARNING - to excessive microwave energy: 1. Read all instructions before using the appliance. 2.
  • Page 20: Precautions To Avoid Possible Exposure To Excessive Microwave Energy

    THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk of injury to persons: 1) Do not overheat the liquid. 2) Stir the liquid both before and halfway through heating it. 3) Do not use straight-sided containers with narrow necks.
  • Page 21: Countertop Installation

    INSTALLATION GUIDE Countertop Installation Remove all packing material and accessories. Cabinet: Remove any protective film found Examine the oven for any damage such as on the microwave oven cabinet surface. dents or broken door. Do not install if oven is Do not remove the light brown Mica cover damaged.
  • Page 22: Radio Interference

    Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounded plug, and 3-slot receptacle that will accept the plug on the appliance.
  • Page 23 5. The oven has several built-in safety switches to ensure that the power remains off when the door is open. Do not tamper with these switches. 6. Do not operate the microwave oven empty. Operating the oven with no food or food that is extremely low in moisture can cause fire, charring or sparking.
  • Page 24: Product Diagram

    PRODUCT DIAGRAM Names of Oven Parts and Accessories Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray Turntable ring assembly Instruction Manual A) Control panel B) Turntable shaft C) Turntable ring assembly D) Glass tray E) Observation window...
  • Page 25: Control Panel

    CONTROL PANEL Tiempo de Descongelado Descongelado Cocción por Tiempo por Peso Potencia Reloj Temporizador Palomitas Papas Pizza de Maíz Vegetales Bebidas Cena Congelados COCCIÓN RÁPIDA DETENER INICIAR Cancelar Memoria (1) Time Cook (2) Time Defrost (3) Power (4) Clock (5) Auto menu: Popcorn, Potato, Pizza, Frozen vegetable, Beverage, Dinner plate (6) Number Buttons:0-9 (7) Weight Defrost (8) Kitchen Timer function...
  • Page 26 OPERATING INSTRUCTIONS 1. Power Level 10 power levels are available. Level Power 100% Display PL10 2. Clock Setting (1) Press " "once, "00:00" will display. RELOJ (2) Press the number keys and enter the current time. For example, time is 12:10 now, please press "1, 2, 1, 0" in turn. (3) Press "...
  • Page 27 Example: to cook the food with 50% microwave power for 15 minutes. a. Press " " once. "00:00" displays. TIEMPO DE COCCION b.Press "1", "5", "0", "0" in order. POTENCIA " once, then press "5" to select 50% microwave power. c.Press "...
  • Page 28: Frozen Vegetable

    7. Time Defrost Function (1) Press " DESCONGELADO POR TIEMPO " once, LED will display "dEF2". (2) Press number pads to input defrosting time. The effective time range is 0:01~99:99 (3) The default microwave power is power level 3. If you want to change the power level, press "...
  • Page 29: Dinner Plate

    DINNER PLATE a) Press " CENA " repeatedly until the number you wish appears in the display, "9.0", "12.0", "18.0" Oz will display in order. For example, press " " once, " 0" appears. CENA "INICIAR/+30SEG. b) Press " to cook, buzzer sounds once. When cooking finishes, buzzer sounds five times and then turn back to waiting state.
  • Page 30: Inquiring Function

    15. Multi-stage cooking At most 2 stages can be set for cooking. In multi-stage cooking, if one stage is defrosting, then defrosting shall be placed at the first stage automatically. Note: Auto cooking cannot work in the multi-stage cooking. Example: if you want to cook with 80% microwave power for 5 minutes + 60% microwave power for 10 minutes.
  • Page 31: Utensils Guide

    UTENSILS GUIDE Personal Injury Hazard CAUTION - Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches should be pierced before cooking. See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven."...
  • Page 32: Specifications

    Plastic foam may melt or contaminate the liquid inside when exposed to high temperature. Wood Wood will dry out when used in the microwave oven and may split or crack. Specifications Model: OGGM3901 Rated Voltage: 120V~60Hz Rated Input Power(Microwave): 1250W Rated Output Power(Microwave): 800W Oven Capacity: 25 liters(0.9 cu.ft.)
  • Page 33: Troubleshooting

    MAINTENANCE Troubleshooting Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does not work properly, contact the nearest authorized service center. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY a. Electrical cord for oven is a.
  • Page 34 Hecho en China. © 2022 Sunbeam Products, Inc. All rights reserved. The Oster™ logo is a trademark of Sunbeam Products, Inc. used under license. Manufactured, distributed or sold by Household Solutions, S.A., official licensee for this product. One-year limited warranty.
