Meridian M2017BNRV Owner's Manual

52” ceiling fan

Advertisement

Quick Links

52" CEILING FAN
OWNER'S MANUAL
READ AND SAVE THESE INSTRUCTIONS
MODEL: M2017BNRV
FAN RATING AC 120V. 60Hz
CUL LISTED MODEL: AC-552A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M2017BNRV and is the answer not in the manual?

Questions and answers

Summary of Contents for Meridian M2017BNRV

  • Page 1 52” CEILING FAN OWNER'S MANUAL READ AND SAVE THESE INSTRUCTIONS MODEL: M2017BNRV FAN RATING AC 120V. 60Hz CUL LISTED MODEL: AC-552A...
  • Page 2: Tools And Materials Required

    1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; a. Blade set (5) b. Hanger bracket c.
  • Page 3: Safety Rules

    3. SAFETY RULES 1. To reduce the risk of electric shock, insure 9. To avoid personal injury or damage to the electricity has been turned off at the circuit fan and other items, be cautious when breaker or fuse box before beginning. working around or cleaning the fan.
  • Page 4: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure. appropriate fasteners and building materials.
  • Page 5: Hanging The Fan

    5. HANGING THE FAN REMEMBER to turn off the power. Follow the steps below to hang your fan properly. CUL Listed electrical box NOTE: This ceiling fan is supplied with two Hanger types of hanging assemblies; the standard bracket ceiling installation using the downrod with ball and socket mounting and the "close- to- ceiling"...
  • Page 6 CLOSE-TO-CEILING INSTALLATION 1. Remove the decorative canopy bottom Canopy cover from the canopy by depressing the three studs. (Fig. 8) Canopy bottom cover 2. Pass the 120-volt supply wires through Figure 8 the center hole in the ceiling hanger bracket as shown in Fig. 5. 3.
  • Page 7: Installation Of Safety Support

    6. INSTALLATION OF SAFETY SUPPORT An additional safety support is provided to prevent the fan from falling. Secure the safety cable to the ceiling joist with screw Hanger bracket Safety cable and washer, as illustrated in Figure 11. Figure 11 7.
  • Page 8: Finishing The Installation

    NOTE: LIGHT KITS ARE AVAILABLE AT YOU POWER LINES 120V SAVOY HOUSE RETAILER. THE FAN IS ALREADY WIRED TO SUPPORT THE LIGHT GREEN GROUND KIT OPTION. WIRING LIGHT WARNING: TO REDUCE THE RISK OF FIRE, GROUND TO MOUNTING ELECTRIC SHOCK, OR OTHER PERSONAL BRACKET OR DOWNROD INJURY.
  • Page 9: Attaching The Fan Blades

    9. ATTACHING THE FAN BLADES Caution: Remove 5 rubber packing mounts and discard before installation. Step 1. Attach the blade to the blade bracket using the screws and fiber washers as shown in Figure 17. Start screw into bracket. Repeat for the two remaining screws.
  • Page 10 11. INSTALLING THE LIGHT NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Step 1. Remove the 3 screws from the mounting plate. Step 2. While holding the light kit under Connection plugs Mounting plate your...
  • Page 11: Operating Your Fan

    13. FAN WITHOUT LIGHT (OPTIONAL) 1. Disassemble the switch housing from the light kit by removing nut and washer on the center of switch housing, you can keep the light kit for future use. 2. Attach the plastic plug to the switch housing.
  • Page 12: Troubleshooting

    15. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds 1. Make sure all motor housing screws are snug. noisy.
