Summary of Contents for iotty i3SPLUS

  • Page 1 Model: i3SPLUS ID: LSW2i3S MLS2i3S01...
  • Page 2: Table Of Contents

    English Technical specifications Important notes Multi-way (3-way via Wi-Fi) Troubleshooting Device overview Installation steps Integrations Italiano Specifiche tecniche Note importanti Deviatore Risoluzione dei problemi Panoramica del dispositivo Istruzioni di installazione Integrazioni...
  • Page 3: Technical Specifications

    Via Del Laghetto, 18/20 33080 Porcia (PN) - ITALY iotty@iotty.com support@iotty.com Technical specifications i3S PLUS Smart Shades Switch Model: i3SPLUS ID: LSW2i3S Input: 230 Vac Frequency: 50Hz Max 5A per RL Ambient temperature: 25°C Operating temperature: from 0°C to 40°C Only works with 2.4GHz Wi-Fi band...
  • Page 4: Important Notes

    compliance with the RF exposure requirement, a separation distance of 20 cm between the device and the human should be maintained. Important notes Safety Precaution Incorrect installation is dangerous or illegal. Install in accordance with all national and local codes. Hire a professional electrician if you are not familiar or not comfortable with electrical work, or if the wiring in your electrical box looks different from the...
  • Page 5: Multi-Way (3-Way Via Wi-Fi)

    Multi-way (3-way via Wi-Fi) [Available only for the central key of the iotty Smart Shades Switch] A 3-way switch allows you to control an electrical load (lamp) from 2 different locations. Thanks to the Multi-way feature, you can connect multiple iotty switches together through the Wi-Fi network and take control of the same light.
  • Page 6: Device Overview

    It restarts the device, all settings remain saved. DOWN button function function It makes the iotty Wi-Fi visible again. Switch 1 Useful to re-register the device on the app, update the Wi-Fi credentials, or turn off the device Wi-Fi.. wall Distance 0.20 in •...
  • Page 7: Installation Steps

    Installation steps Turn off the power at the circuit breaker for the switch you are replacing. Remove your old switch and label your wires. Remember that you must have neutral wire.
  • Page 8 = Load/lamp = Tubular motor IOTTY Wire the iotty plate Insert the neutral wire into terminal N. Insert the phase into terminal L, into one terminal of RL1 and one of RL3. Insert the wire for the up function into the free terminal of RL1.
  • Page 9 Electrical scheme for a load that needs a pulse to activate: = Power IOTTY = Neutral Main power L N RL3 RL2 RL1 supply 230 To set the switch properly, go to the iotty app, go to Device Settings and under “Switch Type” select “Pulse Switch”.
  • Page 10 Screw the iotty switch in Push all the wires back into the wall box (do not push the wires using the back of the switch). Insert the device in the wall box and screw it in. Position the switch so that the AP and reset buttons are located...
  • Page 11 Hide a key and attach the glass faceplate If you want to hide one or more keys of the plate, now is the time to insert the black paperboard found in the box. Insert it over the silkscreen of the desired key in the back of the glass plate.
  • Page 12: App

    Turn on the power and register device Turn on the power at the circuit breaker. Check if the wiring was made correctly by tapping on the glass to turn on and off the light. Now the installation is complete and you can proceed to register the device.
  • Page 13: Integrations

    Hey Google If you need more information you can contact us at support@iotty.com or visit our FAQ section...
  • Page 14: Specifiche Tecniche

    33080 Porcia (PN) - ITALY iotty@iotty.com support@iotty.com Specifiche tecniche i3S PLUS Interruttore Intelligente per Tende e Tapparelle Modello: i3SPLUS ID: LSW2i3S Tensione in ingresso: 230 Vac Frequenza: 50Hz Max 5A per RL Temperatura ambiente: 25°C Temperatura di funzionamento: da 0°C a 40°C Funziona solo con la banda Wi-Fi 2.4GHz...
  • Page 15: Note Importanti

    di 20 cm tra il dispositivo e il corpo umano. Per garantire la conformità con le disposizioni all’esposizione alle RF, deve essere mantenuta una distanza di 20 cm tra il dispositivo e il corpo umano. Note importanti Misure di sicurezza L’installazione scorretta è...
  • Page 16: Deviatore

    Il deviatore è un tipo di interruttore che permette di accendere un punto luce da 2 diverse postazioni. Grazie alla funzionalità Deviatore senza fili, si possono connettere insieme più interruttori iotty attraverso la connessione Wi-Fi e così controllare la stessa luce da diversi punti.
  • Page 17: Panoramica Del Dispositivo

    Panoramica del dispositivo Pulsante mm 83,73 [in 3,296] di reset Riavvia il dispositivo, tutte le impostazioni rimangono salvate. Pulsante di AP Funzione di Funzione di salita discesa Rende il Wi-Fi del dispositivo nuovamente visibile. Tasto 1 Utile per rieffettuare la registrazione del dispositivo sull’app, aggiornare le credenziali per la rete Internet o spegnere il Wi-Fi della placca.
  • Page 18: Istruzioni Di Installazione

    Istruzioni di installazione Stacca la corrente dal contattore principale dell’interruttore che stai sostituendo. Rimuovi il vecchio interruttore e individua i cavi. Ricorda che è necessario avere il cavo neutro.
  • Page 19 = Funzione di salita = Funzione di discesa = Carico/lampadina = Motore tubolare IOTTY Cabla il dispositivo Inserisci il cavo neutro nel morsetto etichettato con N. Inserisci la fase nel morsetto L, in un morsetto di RL1 e in uno di RL3. Inserisci il cavo per la funzione di salita nel morsetto libero di RL1.
  • Page 20 In caso di carichi che hanno bisogno di un impulso per l’attivazione: = Fase IOTTY = Neutro Corrente L N RL3 RL2 RL1 principale 230 Vac Per impostare correttamente l’interruttore, vai sulla app di iotty, sulle impostazioni del dispositivo e sotto “Tipo di tasto” seleziona “Pulsante”...
  • Page 21 Avvita iotty Spingi tutti i cavi nella scatola a muro (non farlo con il retro dell’interruttore). Inserisci il dispositivo nella scatola a muro e avvitalo. Posiziona l’interruttore in modo che i pulsanti AP e reset si trovino sulla destra.
  • Page 22 Nascondi un tasto e attacca il vetro Se vuoi nascondere uno o più tasti della placca, è il momento di inserire il cartoncino nero che trovi nella scatola. Inseriscilo sopra la serigrafia del tasto desiderato, nel retro della placca in vetro. Se non vuoi utilizzare il tasto scelto, potrai disattivarlo dopo la registrazione.
  • Page 23: App

    Riattacca la corrente e registra il dispositivo Accendi il contattore dell’interruttore. Controlla se il cablaggio è stato fatto correttamente toccando il cerchietto per accendere e spegnere la luce. Ora l’installazione è completata e puoi procedere alla registrazione del dispositivo.
  • Page 24 I dispositivi iotty sono compatibili con le integrazioni seguenti works with Hey Google Se hai bisogno di maggiori informazioni puoi contattarci su support@iotty.com oppure visita le Domande Frequenti...
