English Technical specifications Important notes Multi-way (3-way via Wi-Fi) Troubleshooting Device overview Installation steps Integrations Español Especificaciones técnicas Notas importantes Interruptor de tres vías Resolución de problemas Descripción general del dispositivo Pasos para la instalación Integraciones...
Via Del Laghetto, 18/20 33080 Porcia (PN) - ITALY support@iottysmarthome.com Technical specifications 4 Gang Smart Switch Model: U4DR ID: LDWU44 Input: 110-120 Vac Frequency: 50-60Hz Current: only switch - without dimmer module: max 5A per output | with dimmer module:...
Overcurrent protective device external: 15A circuit breaker Minimal distance between the back of iotty device and the electrical box: 0.20 in (5 mm) UL number: E527071 For warranty information visit us at https:// iottysmarthome.com/pages/limited-warranty Important notes Safety Precaution Incorrect installation is dangerous or illegal.
A 3-way switch allows you to control an electrical load (lights) from 2 different locations. Thanks to the Multi-way feature, you can connect multiple iotty switches together through the Wi-Fi network and take control of the same light. For more details check: https://iottysmarthome.
Device overview button device It makes the iotty Wi-Fi visible again. Useful to re-register the device on the app, update the Wi-Fi credentials, or turn off the device Wi-Fi.. Reset button It restarts the device, all settings remain saved. Reserved for troubleshooting Black protective film covering the dimming indicator.
Installation steps Turn off the power at the circuit breaker for the switch you are replacing. Main power supply 110 Vac = Live/power = Neutral = Load/light Remove your old switch and label your wires. Remember that you must have neutral wire.
Page 8
= Live/power = Neutral = Load/light Wire the iotty plate Connect N to the Neutral wire. Connect the load wires: connect the blue wires to each load. Connect L and the black RL wires to the Power. In the picture...
Page 9
Install the Dimmer Module Plug the dimmer module in the back of the iotty Smart Switch and remove the black protective film covering the dimming indicator on the front of the device to see the touch slider on the glass. If you...
Page 10
Screw the iotty switch in Push all the wires back into the wall box (do not push the wires using the back of the switch). Insert the device in the wall box and screw it in. Position the switch so that the AP and reset buttons are located...
Page 11
Attach the glass faceplate Position the faceplate so that the little circle is located at the bottom. Attach your Smart Switch faceplate.
GET IT ON GET IT ON Turn on the power and register device Turn on the power at the circuit breaker. Check if the wiring was made correctly by tapping on the glass to turn on and off the light. If you have installed a Dimmer Module, swipe on the vertical slider to dim the light.
Dispositivo de protección externo contra sobrecorriente: Disyuntor de 15 A Distancia mínima entre la parte posterior del iotty y la caja eléctrica: 0.20 in (5 mm) Número UL:: E527071 Notas importantes Instrucciones de seguridad La instalación incorrecta puede llegar a ser peligrosa o, incluso, ilegal según qué...
Los interruptores de “3-way” son aquellos tipos de interruptores que permiten controlar un componente eléctrico desde dos puntos diferentes. Gracias a la capacidad del iotty de conmutar varias salidas, puedes conectar múltiples interruptores iotty por Wi-Fi para controlar la misma lámpara.
Para más información acerca de la garantía de este producto, consulte https://iottysmarthome.com/ pages/limited-warranty Descripción general del dispositivo Botón AP Hace que iotty Wi-Fi sea de nuevo dispositivo visible. Útil para volver a registrar el dispositivo en la app, actualizar las credenciales de Wi-Fi o apagar la Wi-Fi del dispositivo.
Apaga el contactor del interruptor que estás sustituyendo. Alimentación 110 Vac Corriente o L1 Neutro o L2 = Carga/lámpara Retira el viejo interruptor y pon una etiqueta en los cables. Recuerda que debes tener el cable neutro para instalar el interruptor iotty.
Page 19
Corriente o L1 Neutro o L2 = Carga/lámpara Realiza el cableado de la placa iotty Conecta N al cable neutro. Conecta los cables RL: conecta el cable de carga (azul) a la carga/lámpara. Conecta L a la fuente de alimentación. Conecta los cables negros de RL a la fuente de alimentación.
Page 20
Instala el módulo de atenuación Inserta el módulo de atenuación en la parte posterior del dispositivo y retire la película protectora negra que cubre el indicador de atenuación en la parte delantera del dispositivo para ver el deslizador táctil en el cristal. Si no lo tienes, ve al siguiente paso...
Page 21
Enrosca el interruptor iotty Introduce todos los cables en la caja de pared (no lo hagas con la parte trasera del interruptor). Inserta eldispositivo en la caja de pared y atorníllalo. Coloca el interruptor de forma que los botones AP y de...
Page 22
Coloca el cristal Coloca el cristal de forma que el círculo pequeño se sitúe en la parte inferior. Fija el cristal a tu Interruptor Intelligente iotty...
GET IT ON GET IT ON Conectar la electricidad y register device Enciende el contactor del interruptor. Comprueba si el cableado se ha realizado correctamente tocando el círculo para encender y apagar la luz. Si has instalado el modulo dimmer, pasa el dedo por el deslizador vertical para cambiar la intensidad de la luz.
Page 24
Los dispositivos iotty son compatibles con las integraciones siguientes works with Hey Google Si necesitas más información, puedes ponerte en contacto con nosotros en support@ iottysmarthome.com o visitar nuestra sección de preguntas frecuentes:...
