Installation Instructions
PE80 Series - Electric Latch Retraction (56-) Exit Devices
With Optional:
53- Prefix (Latch Monitor Switch)
54- Prefix (Exit Trim Lever Monitor Switch)
55- Prefix (Request to Exit - Push Bar Signal Switch)
P773 NE, P774 NE, P775 NE, P776 NE (Electromechanical Exit Trim, Narrow)
P773 WE, P774 WE, P775 WE, P776 WE (Electromechanical Exit Trim, Wide)
WARNING
This product can expose you to lead
which is known to the state of California
to cause cancer and birth defects or other
reproductive harm. For more information go
to www.P65warnings.ca.gov.
1-800-727-5477 • www.sargentlock.com
Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or
in part without the express written permission of SARGENT Manufacturing Company is prohibited.
A8297-1 05/23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Assa Abloy PE80 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sargent Assa Abloy PE80 Series

Summary of Contents for Sargent Assa Abloy PE80 Series

  • Page 1 For more information go to www.P65warnings.ca.gov. A8297-1 05/23 1-800-727-5477 • www.sargentlock.com Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 2: Table Of Contents

    Power Mode Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 3 For additional wire connections and operation instructions: 55- Refer to instruction sheet A8299 for wire connections. A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 4: Overview

    Installation Instructions Overview Description The Sargent 56- prefix ELR works with PE80 Series exit devices to provide remote-controlled latch retraction. It is compatible with the following prefixes/options: • 53 - Latchbolt Monitor Switch: The latch monitor provides tamper resistant latch monitoring. The monitor switch is activated when there is physical movement of the latch.

  • Page 5: Hinge Requirements

    Note: When calculating voltage drop, use 1A as the recommended current draw for the 56- ELR. A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 6: Wire Locations And Positions

    (56- PWR+ 24VDC) *If 53-NC contact is required, refer to Appendix A-Wiring re-configuration section. A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 7: Dip Switch

    1. PWR/TMR ON = Power Mode 2. DLY1 3. DLY2 4. DLY3 PCBA Module A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 8: Electrolynx Wiring System

    Note: The three inch harness is not included with the product, door, or hinge, and must be ordered separately. (Part number available in Power Mode Wiring section) A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 9: Power Mode Wiring

    6. Store excess wiring under end cap and assemble with provided screws. Avoid pinching wires A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 10 1” diameter hole in door Rail Bracket Cover A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 11: Input Requirements

    ElectroLynx Power Mode Wiring * Pink and Tan not used in Power Mode A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 12: Typical Wiring

    Do not cycle the power supply. 56- PE80 Series Exit Device Typical Power Mode Wiring A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 13: Troubleshooting

    Prior to electrical troubleshooting, confirm that the mechanical system properly functions; i.e., that the push bar fully retracts all latches and the door opens freely. Refer to applicable Sargent PE80 Series Exit Device product instruction sheet to correct mechanical installation issues.

  • Page 14: Section 2: Power Mode

    On vertical rod exit devices, verify that the latchbolts do not enter hold-back position until the push rail is fully depressed. • Adjust device mechanically, as required, before applying power. A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 15 Dip switches 2, 3, 4 are used to configure the timer delay in timer mode. Timer Delay Settings = 5 seconds A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 16 7. Store excess wiring under end cap and assemble with provided screws. Avoid pinching wires. A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 17 -Yellow (55- NC)________ Appendix A-Wiring re-configuration sec- tion. Figure 9 ElectroLynx Timer Mode Installation A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 18: Non-Electrolynx Opening Installation

    Non-ElectroLynx Timer Mode Connection 56- Wires with ElectroLynx Connector Removed Figure 10 Timer Mode Installation A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 19: Typical Wiring

    Refer to settings in Section 3-g (Fig. 18-20) for DIP Switch timer delay settings. A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 20: Led Signaling Chart

    Prior to electrical troubleshooting, confirm that the mechanical system properly functions; i.e., that the push bar fully retracts all latches and the door opens freely. Refer to applicable Sargent PE80 Series Exit Device product instruction sheet to correct mechanical installation issues.
  • Page 21 • The number of devices connected to the power supply. • Symptoms of problem (i.e., observed behavior). A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 22 53‐       Latch Monitor Switch (Form C) in Chassis 55‐      Push Bar Switch (Form C) in Rail EGND   Earth Ground connection to metal rail, required Power Mode  Retracts push bar/latch when 24VDC power is applied, releases when power is removed Timer Mode   Device is powered, a momentary closure from external switch across Time+ to Time‐  retracts push bar/latch for dip switch setting of 0 to 20sec, or remains retracted until switch is opened  then push bar/latch releases after (0‐20sec)  ET     Electrified Exit Trim (Fail Safe or Fail Secure) Ecoflex 10 to 28VDC 54‐     ET Outside Lever Monitor Switch (Form C) Type: 12/24VDC, Continuous Duty A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.

  • Page 23: Wire Configuration

    • 54- N.O. • 54- N.C. See page 22 for wire table . A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 24 53- N.C. location 26-8 (26 pin connector position 8) . Figure 12 A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 25 Crimp socket Pin 2 contact Figure 13 Do not tilt crimped terminals during insertion . A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 26 5. Insert tan wire into 26-18 for (54- N.O.), or 26-20 for (54- N.C.) . Figure 14 A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 27 Crimp socket Pin 2 contact Figure 15 Do not tilt crimped terminals during insertion . A8297-1 05/23 Copyright © 2023 SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 28 New Haven, CT 06511 USA 800-810- 9473 • www.sargentlock.com Copyright © 2023 Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. Patent pending and/or patent - www.assaabloydss.com/patents.
