TRACO POWER TXL Series Installation Instructions

INSTALLATION INSTRUCTIONS
TXL 015 Series
Order Code
TXL 015-3.3S
TXL 015-05S
TXL 015-12S
TXL 015-15S
TXL 015-24S
TXL 015-48S
Total output power must not exceed specified max output power.
Output is adjustable by potentiometer with an insulated screwdriver.
Input
V =115VAC V
in
current:
TXL 015
0.32 A typ.
Output Voltage Adjustment range:
Only single output models
Operating temperature range:
Natural Air Convection Cooling
Output Power Derating:
Storage temperature range:
Non operating
Connections:
Terminal for wiring:
Case material:
Mounting inserts:
http://www.tracopower.com
Switching Power Supply
AC-Input
Voltage Range Power max.
85 – 264VAC
43 – 67Hz
120 – 375VDC
Universal Input
=230VAC
in
0.20 A typ.
±10%
-20°C – +70°C max
-4°F – +158°F max
Between V
of 1%/V! At V
above +50°C – +70°C
above 122°F – +158°F
-40°C – +75°C max
-40°F – +167°F max
Screw type terminal COMBICON.
Recommended tightening torque 0.5 to 0.7Nm (4.5 to 6.2lb.in)
Y or Ring shape recommended (max. diameter = 6.0mm)
Nickel plated steel base and cover
M3 screws
2 different places; 2 on the side and 2 on the bottom.
Output
DC-Output
10 Watt 3.3V / 3.0A
15 Watt 5.0V / 3.0A
15 Watt 12.0V / 1.3A
15 Watt 15.0V / 1.0A
15 Watt 24.0V / 0.63A
15 Watt 48.0V / 0.32A
Power
Consumption
TXL 015
= 85Vac and V
in
= 85Vac  Pout = 85% max
in
Recommended
Circuit breaker
(Characteristic C)
V =115VAC V
in in
18.5 Watt typ. 19 Watt typ.
= 100 Vac  load derating
in
%

2.5 /
K
%

1.39 /
°F
5A
=230VAC
Rev: 43/08-1
