Summary of Contents for deconta C 60 L
- Page 1 Operating instructions (original) Water treatment C 60 L Type 628 Language: EN Version: 2 Phone: 02874/9156-0 deconta GmbH Fax: 02874/9156-11 Date of issue: Im Geer 20 E-Mail: info@deconta.com 01.10.2024 46419 Isselburg Web: www.deconta.com...
-
Page 2: Table Of Contents
6.3.2 Legislation ....................18 6.3.3 Qualification of staff ................18 6.3.4 Warning of residual risks ................. 18 6.3.5 Means of transportation ................18 Internal transport ....................19 Water treatment C 60 L 2 from 30 Original operating instructions Version 2... - Page 3 14 Storage ........................... 28 15 Waste disposal....................... 29 15.1 Qualification of staff ....................29 15.2 Legislation ......................29 15.3 Waste ........................29 16 EC Declaration of Conformity ..................30 Water treatment C 60 L 3 from 30 Original operating instructions Version 2...
-
Page 4: Product And Manufacturer
Product and manufacturer Product and manufacturer Product The following product is described in these operating instructions: Water treatment C 60 L Serial number: see type plate Manufacturer Name and address deconta GmbH Im Geer 20 46419 Isselburg Telephone 02874/9156-0 02874/9156-11 e-mail info@deconta.com... -
Page 5: About These Operating Instructions
The operator must keep these operating instructions or extracts thereof within easy reach in the immediate vicinity of the machine. If the machine is handed over to another person, the operator passes these operating instructions on to this person. Water treatment C 60 L 5 from 30 Original operating instructions Version 2... -
Page 6: Warnings
Description of the hazard and the cause of the hazard Consequence Description of the possible consequences of the hazard for humans, animals and the environment Escape Recommendations on how hazards can be avoided Water treatment C 60 L 6 from 30 Original operating instructions Version 2... -
Page 7: Symbols
The instruction sign is a safety sign that prescribes certain behaviour. The following table provides an overview of the instruction symbols used and their meaning. Symbol Meaning Symbol Meaning Wear safety shoes Use protective clothing Water treatment C 60 L 7 from 30 Original operating instructions Version 2... -
Page 8: Description Of The Machine
This section contains information on understanding the machine. General description General description of the product The Water treatment system was designed and built by deconta GmbH, Im Geer 20, 46419 Isselburg. Electric hot water cylinder for heating shower water. The water can be filled either manually via a filling opening (with bucket) or automatically with a permanently connected fresh water hose. -
Page 9: Scope Of Delivery
Description of the machine Scope of delivery The scope of delivery of the machine includes the following items: ▪ Water treatment C 60 L ▪ Filters ▪ Service pack ▪ These operating instructions Return delivery after termination of a rental... -
Page 10: Operating Modes
Product - waste products: Geka connection for filtered wastewater into the sewage system ▪ Product - material feed: Geka connection for contaminated shower water ▪ Product - base: Castors Water treatment C 60 L 10 from 30 Original operating instructions Version 2... -
Page 11: Type Plate
The following accessories are optionally available for Water treatment: Designation Article no. Illustration Waste water hose 5m with 3/4" Geka BU1504 connection Fresh water hose 5m with 1/2" Geka BU1504a connection Water treatment C 60 L 11 from 30 Original operating instructions Version 2... -
Page 12: Technical Data
230 V ▪ Current consumption: 11 A ▪ Heat output: 2000 W ▪ Useful water volume: 60 litres ▪ Tank filling: automatic or manual via filling opening Water treatment C 60 L 12 from 30 Original operating instructions Version 2... -
Page 13: Security
For this reason, persons leaving the decontamination area via airlocks must shower when leaving. The deconta Water treatment system heats the shower water and treats (filters) the contaminated wastewater. The user must comply with the operating parameters specified in the operating instructions. -
Page 14: Misapplication
Operating the machine in a technically unsatisfactory condition, not being aware of safety and hazards and not observing all instructions in the documentation Use in potentially explosive atmospheres Water treatment C 60 L 14 from 30 Original operating instructions Version 2... -
Page 15: Tasks And Qualifications Of Staff
Qualified waste disposal Disposer Dispose of the machine company for legally compliant, proper and professional disposal of the machine Water treatment C 60 L 15 from 30 Original operating instructions Version 2... -
Page 16: Notes On Occupational Health And Safety
Instruction of persons with regard to protective devices and supplementary protective devices Instruction of persons with regard to residual risks This list is not exhaustive and does not claim to be complete. Water treatment C 60 L 16 from 30 Original operating instructions Version 2... -
Page 17: Transport
Disconnect the appliance from the power supply. To empty, remove the Geka sealing cap on the "Empty tank" connection and open the ball valve. Ball valve Sealing cap Water treatment C 60 L 17 from 30 Original operating instructions Version 2... -
Page 18: Loss Of Warranty Claims
The size of the transport surface must be dimensioned so that the machine can be parked safely on the transport surface without falling. Machine may fall due to unintentional change of position when loading and unloading onto/from a means of transportation. Water treatment C 60 L 18 from 30 Original operating instructions Version 2... -
Page 19: Internal Transport
Machine may fall down due to unintentional change of position when loading and unloading onto/from a means of transportation. Water treatment C 60 L 19 from 30 Original operating instructions Version 2... -
Page 20: Assembly
The Water treatment system is delivered ready for operation ex works and is intended for immediate commissioning. Do not operate the appliance if it is visibly damaged. Contact deconta GmbH immediately. Put into operation This section contains information on commissioning the machine. - Page 21 Wastewater pump start Hot water start The wastewater pump can be switched on manually by pressing and holding the "Wastewater pump start" switch. Water treatment C 60 L 21 from 30 Original operating instructions Version 2...
-
Page 22: Operation
One person is required to use the machine. Tools required No tools are required to use the machine. Equipment required No equipment is required to use the machine. Water treatment C 60 L 22 from 30 Original operating instructions Version 2... -
Page 23: Maintenance
Only change filters when the appliance is switched off. Only use approved filters. Pull out the mains plug before opening the housing Water treatment C 60 L 23 from 30 Original operating instructions Version 2... -
Page 24: Personal Protective Equipment Required
Remove dirty filters when damp to prevent the release of filter dust ▪ Only use approved filters ▪ Damaged filter cartridges must not be used Union nut Filter head spanner Pressure gauge filter monitoring Water treatment C 60 L 24 from 30 Original operating instructions Version 2... -
Page 25: Reduction Of Legionella Growth
To clean the hoses and shower device, the heated water should also be removed from the shower device for approx. 3 minutes. Caution: Danger of scalding! Alternatively, an authorised disinfectant can also be used. Water treatment C 60 L 25 from 30 Original operating instructions Version 2... -
Page 26: Spare Parts
If this is not possible, the alternative spare parts should correspond to the properties of the original spare parts in order to ensure safe, trouble-free and economical use of the machine. Water treatment C 60 L 26 from 30 Original operating instructions... -
Page 27: Circuit Diagram
Circuit diagram Circuit diagram Water treatment C 60 L 27 from 30 Original operating instructions Version 2... -
Page 28: Cleaning
During storage, care must be taken to ensure that contamination with other substances is excluded. Drinking water hoses (freshwater hoses) and wastewater hoses must be stored separately. Water treatment C 60 L 28 from 30 Original operating instructions Version 2... -
Page 29: Waste Disposal
The operator of the machine or the person authorised to dispose of the waste is responsible for compliance with these legal regulations. 15.3 Waste The waste generated by the machine must be disposed of properly and professionally in accordance with the law. Water treatment C 60 L 29 from 30 Original operating instructions Version 2... -
Page 30: Ec Declaration Of Conformity
Safety of machinery - Safety-related parts of control systems - Part 2: Validation (ISO 13849-2:2012) Name and address of the person authorised to compile the technical documentation: Boland, Thomas - deconta GmbH - Im Geer 20 - 46419 Isselburg Place: Isselburg Date: 03.05.2023...
