Summary of Contents for AGFA DR 10e C

  • Page 1 DR Detector Calibration Key User Manual 0134K EN 20240524 1323...
  • Page 2: Table Of Contents

    XD 10, XD⁺10, XD 14, XD⁺14, XD 17, XD⁺17, XF⁺10, XF⁺14, XF⁺17 Exposure Sequence..14 DR 10s and DR 14s Exposure Sequence..................16 DR 10e C, DR 14e C and DR 17e C Exposure Sequence............18 DR 18M and DR 24M Exposure Sequence..................20 DX-D 10C, DX-D 10G, DX-D 20C, DX-D 20G Exposure Sequence..........21...
  • Page 3: Legal Notice

    Agfa and the Agfa rhombus are trademarks of Agfa-Gevaert N.V., Belgium or its affiliates. DX-D is a trademark of Agfa NV, Belgium or one of its affiliates. All other trademarks are held by their re- spective owners and are used in an editorial fashion with no intention of infringement.
  • Page 4: Scope

    DR Detector Calibration | Introduction to this Manual | 4 Scope This manual contains information for the calibration and maintenance of the following DR Detec- tors: • DR 10e C • DR 10s • DR 14e C • DR 14e G • DR 14s •...
  • Page 5: Disclaimer

    DR Detector Calibration | Calibrating the DR Detector | 5 Disclaimer Agfa assumes no liability for use of this document if any unauthorized changes to the content or format have been made. Every care has been taken to ensure the accuracy of the information in this document. However, Agfa assumes no responsibility or liability for errors, inaccuracies or omissions that may appear in this document.
  • Page 6: About Gain Calibration

    DR Detector Calibration | Calibrating the DR Detector | 6 About Gain Calibration Regular calibration of the DR Detector assures constant image quality. This calibration eliminates the effect of sensitivity deviations over the panel and/or corrects non-unifomity in the X-ray beam. The sensitivity deviations of pixels across the DR Detector are affected by the quantity and pattern of the effective X-ray dose on the detector.
  • Page 7: Calibration Frequency

    DX-D 40C, DX-D 40G, DX-D 45C, DX-D 45G, DX-D 60C, DX-D XD 10, XD⁺10, XD 14, XD⁺14, XD 17, XD⁺17 XF⁺10, XF⁺14, XF⁺17 DR 10e C, DR 14e C, DR 17e C 12 months DR 10s, DR 14s DX-D 25C, DX-D 30C, DX-D 35C...
  • Page 8 DR Detector Calibration | Calibrating the DR Detector | 8 DR 10e C, DR 14e C, DR 17e C A single set of calibration data is used for all NX work- stations on which the DR Detector is used. Choose one NX workstation that will be used for calibration and perform the regular calibration each time on the same NX workstation.
  • Page 9: Calibration Workflow

    14 • DR 10s and DR 14s Exposure Sequence on page 16 • DR 10e C, DR 14e C and DR 17e C Exposure Sequence on page 18 • DR 18M and DR 24M Exposure Sequence on page 20 •...
  • Page 10: Required Material

    DR Detector Calibration | Calibrating the DR Detector | 10 Required material For calibration of all DR Detectors, apart from DR 18M, DR 24M and DX-D 25C, an Agfa calibration filter (Cu 1.5 mm) is required. For calibration of DR 18M and DR 24M, a calibration PMMA block is required.
  • Page 11: Preconditions

    DR Detector Calibration | Calibrating the DR Detector | 11 Preconditions • Clean the DR Detector (see the DR Detector user manual for instructions). • Make sure that all parts of the X-Ray system that may affect imaging (e.g. the DAP meter) are in their normal position and clean.
  • Page 12: Procedure

    To calibrate the DR Detector: 1. Log in to NX. To calibrate DR 10e C, DR 14e C or DR 17e C, you have to log in to a user account with adminis- trator rights. 2. Stop the NX software completely.
  • Page 13 Note If calibration fails again contact your local service representative. 10.Exit the Calibration Tool. 11.Start the NX software. In the Start menu, select All programs > Agfa > NX > Restart NX completely. Related information DR 10s and DR 14s Exposure Sequence...
  • Page 14: Xd 10, Xd⁺10, Xd 14, Xd⁺14, Xd 17, Xd⁺17, Xf⁺10, Xf⁺14, Xf⁺17 Exposure Sequence

    X-ray tube. Grid Remove the grid. Filtration Mount the Agfa calibration filter (Cu 1.5 mm). Check that there is no additional filtration. Collimation The collimation area should extend at least 1.5 cm on each side of the DR Detector.
  • Page 15 DR Detector Calibration | Calibrating the DR Detector | 15 Ralco collimators may limit the X-ray field. To overrule the limitation, the collimator must be un- locked using a key and the collimation must be applied manually. Exposure Sequence Procedure: 1. Set the mAs value to the indicative value for the first exposure level. 2.
  • Page 16: Dr 10S And Dr 14S Exposure Sequence

    DR Detector parallel to the axis of the X- ray tube. Grid Remove the grid. Filtration Mount the Agfa calibration filter (Cu 1.5 mm). Check that there is no additional filtration. Collimation The collimation area should extend at least 1.5 cm on each side of the DR Detector.
  • Page 17 DR Detector Calibration | Calibrating the DR Detector | 17 1. Set the mAs value to the indicative value for the exposure level. 2. Make exposures as instructed by the DR Calibration Tool. To avoid overheating of the X-ray tube, limit the rate of exposures to two per minute. Calibrating DR 10s and DR 14s on DX-D 100 On a DX-D 100 mobile X-ray unit that is upgraded to support DR 10s or DR 14s, an extra step is needed to activate the DR Detector during calibration.
  • Page 18: Dr 10E C, Dr 14E C And Dr 17E C Exposure Sequence

    DR Detector every 12 months. Modality Settings Note To calibrate DR 10e C, DR 14e C or DR 17e C, you have to log in to a user account with administrator rights. The indicative exposure levels for each exposure are specified by the DR Calibration Tool.
  • Page 19 DR Detector Calibration | Calibrating the DR Detector | 19 On modalities that support automatic collimation, the collimation settings are applied automatical- ly and must be checked by the user. Ralco collimators may limit the X-ray field. To overrule the limitation, the collimator must be un- locked using a key and the collimation must be applied manually.
  • Page 20: Dr 18M And Dr 24M Exposure Sequence

    DR Detector Calibration | Calibrating the DR Detector | 20 DR 18M and DR 24M Exposure Sequence Modality Settings The indicative exposure levels for each exposure are specified by the DR Calibration Tool. Table 6: Modality settings 28 kV 160 mAs mAs (indicative value for first exposure level) Filtration MoMo Note If the exposure settings used for a previous calibration are known, use these settings.
  • Page 21: Dx-D 10C, Dx-D 10G, Dx-D 20C, Dx-D 20G Exposure Sequence

    Remove the grid. If the grid is fixed, use 32 mAs as indicative mAs- value. Filtration Mount the Agfa calibration filter (Cu 1.5 mm). Check that there is no additional filtration. Collimation Collimation area should extend at least 1.5 cm on each side if the detector.
  • Page 22 DR Detector Calibration | Calibrating the DR Detector | 22 Exposure Sequence Procedure: 1. Set the mAs value to the indicative value for the exposure level. 2. Make exposures as instructed by the DR Calibration Tool. 0134K EN 20240524 1323...
  • Page 23: Dx-D 25C Exposure Sequence

    DR Detector Calibration | Calibrating the DR Detector | 23 DX-D 25C Exposure Sequence Modality Settings Apply these modality settings: Table 8: Modality settings 75 kV mAs (indicative value for first ex- 12.5 mAs posure level) mAs (indicative value for second 8 mAs exposure level) mAs (indicative value for third ex- 4 mAs posure level)
  • Page 24 DR Detector Calibration | Calibrating the DR Detector | 24 Ralco collimators may limit the X-ray field. To overrule the limitation, the collimator must be un- locked using a key and the collimation must be applied manually. Exposure Sequence Procedure: 1. Set the mAs value to the indicative value for the first exposure level. 2.
  • Page 25: Dx-D 30C And Dx-D 35C Exposure Sequence

    X-ray tube. Grid Remove the grid. Filtration Mount the Agfa calibration filter (Cu 1.5 mm). Check that there is no additional filtration. Collimation The collimation area should extend at least 1.5 cm on each side of the DR Detector.
  • Page 26 DR Detector Calibration | Calibrating the DR Detector | 26 Ralco collimators may limit the X-ray field. To overrule the limitation, the collimator must be un- locked using a key and the collimation must be applied manually. Exposure Sequence Procedure: 1. Set the mAs value to the indicative value for the uniformity check. 2.
  • Page 27: Dx-D 40C And Dx-D 40G Exposure Sequence

    X-ray tube. Grid Remove the grid. Filtration Mount the Agfa calibration filter (Cu 1.5 mm). Check that there is no additional filtration. Collimation The collimation area should extend at least 1.5 cm on each side of the DR Detector.
  • Page 28 DR Detector Calibration | Calibrating the DR Detector | 28 Ralco collimators may limit the X-ray field. To overrule the limitation, the collimator must be un- locked using a key and the collimation must be applied manually. Exposure Sequence Procedure: 1. Set the mAs value to the indicative value for the first exposure level. 2.
  • Page 29: Dx-D 45C, Dx-D 45G, Dx-D 60C And Dx-D 60G Exposure Sequence

    X-ray tube. Grid Remove the grid. Filtration Mount the Agfa calibration filter (Cu 1.5 mm). Check that there is no additional filtration. Collimation The collimation area should extend at least 1.5 cm on each side of the DR Detector.
  • Page 30 DR Detector Calibration | Calibrating the DR Detector | 30 Ralco collimators may limit the X-ray field. To overrule the limitation, the collimator must be un- locked using a key and the collimation must be applied manually. Exposure Sequence Procedure: 1. Set the mAs value to the indicative value for the first exposure level. 2.
  • Page 31: Fixed Dr Detector (4343R, Pixium Rad 4343) Exposure Sequence

    Grid Remove the grid. If the grid is fixed, use 32 mAs as indicative mAs-value. Filtration Mount the Agfa calibration filter (Cu 1.5 mm). Check that there is no additional filtration. Collimation 46 cm x 46 cm (collimation area should extend at least 1.5 cm on each side of the detector) Note If the exposure settings used for a previous calibration are known, use these settings.
  • Page 32: Fixed Dr Detector (Pixium Rf4343 Fl) Exposure Sequence

    The X-ray tube must be centered on the DR detector. Check the position using the collimator light, before the filter is mounted. Filtration Mount the Agfa calibration filter (Cu 1.5 mm). Check that there is no additional filtration. Collimation Maximum collimation area Note If the exposure settings used for a previous calibration are known, use these settings.
  • Page 33: Problem Solving

    DR Detector Calibration | Problem solving | 33 the required exposure level. After adjusting the dose setting, it may be necessary to repeat previ- ous exposures as well. During calibration for static image mode, the DR Calibration Tool may request to perform a rapid sequence exposure. Do not initiate a next exposure before the DR Calibration Tool displays the instruction.
  • Page 34: Dr Calibration Tool Stalls

    DR Detector Calibration | Problem solving | 34 DR Calibration Tool Stalls Problem The DR Calibration Tool stalls. Cause A virus scanner interferes with the DR Calibration Tool. Workaround Disable the virus scanners on the workstation and restart the cali- bration procedure. Problem The DR Calibration Tool stalls for a short time. Cause Information must be retrieved from the DR Detector.
  • Page 35: Generator Error

    DR Detector Calibration | Problem solving | 35 Generator error Problem The calibration of a detector for dynamic imaging is interrupted by a generator error. The software console displays the following error code. RAD_RUN_TIME_LIMIT Cause The remaining heat capacity of the X-ray tube is insufficient for the next exposure.
  • Page 36: Generator Controls Are Disabled

    DR Detector Calibration | Problem solving | 36 Generator controls are disabled Problem The calibration of a detector for dynamic imaging cannot be contin- ued because the generator controls in the software console are sud- denly disabled. Cause A communication problem with the generator has occurred. Workaround 1.
