Summary of Contents for Bego Motova 100

  • Page 1 Motova 100 English Translation of the original instructions...
  • Page 2 This symbol is printed on the large mixing bowls. It indicates that these relatively heavy mixing bowls must be held firmly once mixing is complete. BEGO Bremer Goldschlägerei Wilh. Herbst GmbH & Co • Wilhelm Herbst-Straße 1 • D-28359 Bremen Telefon +49 421 2028-0 • Telefax +49 421 2028-100 • www.bego.com...
  • Page 3: Table Of Contents

    Motova 100 Contents Page Operating Instructions Safety instructions --------------------------------------------------------------------------- 4 About the unit Unit description ------------------------------------------------------- 6 Technical data --------------------------------------------------------- 6 Scope of delivery and special accessories ------------------------ 7 Operation Installation ------------------------------------------------------------- 8 Switch on --------------------------------------------------------------- 8 Set mixing duration--------------------------------------------------- 8...
  • Page 4: Safety Instructions

    Place of use l Repairs The unit has been designed solely for use in dental Repairs may be carried out solely by BEGO laboratories and comparable establishments for customer service or by persons authorised by research, commercial and training purposes. • The BEGO customer service.
  • Page 5 Motova 100 Special safety instructions concerning this unit l The mixing bowl is held onto the device by vacuum. If the vacuum is insufficient, the mixing bowl will fall down! The mixing bowl must therefore be held firmly after the start...
  • Page 6: About The Unit Unit Description

    Motova 100 Unit description Motova 100 is a vacuum mixing device for the mixing of investment materials, silicone, plaster and other forming materials in the dental laboratory. START The mixing duration can be set between STOP 1 and 255 seconds. In addition, a post-evacuation time between 1 and 30 seconds can be set.
  • Page 7: Scope Of Delivery And Special Accessories

    Motova 100 Scope of delivery Art. No. 26 280 (230 V) 26 281 (110 V) Motova 100 device complete with: 1 Holder for wall mounting 2 Mains cable 3 Mixing bowl (M 550 ml) * 4 Three spare air filters * 5 Two spare fuses * (230 V: 3.15 A)
  • Page 8: Operation Installation

    Motova 100 Installation Insert the device in the table stand 1 (accessories) and place on a stable working surface or fasten the device with the holder 2 on a wall. Take into account the total weight. max 12 kg Connect the mains cable 3 to the device and a correctly grounded plug (see safety instructions).
  • Page 9: Filling

    Motova 100 Filling l Select the appropriate mixing bowl: a) Mixing bowls in the M series: for investment material and plaster, not for silicone Mixing bowls in the MS series: only for silicone. b) The filling level must lie between...
  • Page 10: Mixing

    Motova 100 Mixing l Push the mixing bowl with cover into the holder 1 and hold firmly with the hand! l Press the Start/Stop key: The vacuum is generated and displayed on the manometer 2. Hold the mixing bowl firmly until the manometer displays 0.8 bar.
  • Page 11: Settings: Warning Signal

    Motova 100 Settings Warning signal Warning signals are set at the factory. They sound at the end of mixing and when the vacuum is stopped as a signal to hold the mixing bowl firmly. The warning signals can be deactivated: l During switch on, hold the - and + keys pressed down.
  • Page 12: Maintenance Replace Air Filter

    Motova 100 Replace air filter F I L F I L After 999 mixing processes, the display shows F I L F I L F I L . The air filter should be replaced but work can be continued immediately:...
  • Page 13: Replace O-Rings And Discs In Mixing Bowl

    Motova 100 Replace O-rings and discs in mixing bowl Tools such as probes and screwdrivers can be used to replace the O-rings if they are difficult to access. Components must be removed to replace the O-rings and discs S (see diagram).
  • Page 14: Faults Elimination Of Faults

    Motova 100 Elimination of faults Faults Cause Rectification Always switch the device off beforehand! Main switch is No power. Check mains connection. switched on, Remove fuse holder 1 display is not lit up. Fuse is defective. and replace fuse. If the fault recurs, send for the customer service.
