- Page 1 Anschütz GmbH Zeyestr. 16-24 24106 Kiel Germany www.anschuetz.com Bearing Sight Operator and Service Manual Type: CP 190 Type: 143-021 (Telescopic) Type: 143-024 Edition: 001 10000001879...
- Page 2 Copyright Dieses Dokument sowie dessen Inhalt sind urheberrechtlich This document and its content are copyright protected. Distribution, geschützt. Die Weitergabe,Vervielfältigung und Speicherung sowie reproduction and storage as well as translation and exploitation of die Übersetzung wie auch Verwendung dieses Dokuments oder this document and its content, in whole or in parts and regardless of dessen Inhalts, als Ganzes oder in Teilen und egal in welcher Form what form, are prohibited without prior express written permission.
-
Page 3: Table Of Contents
2 Operation................................8 2.1 Preliminary Remarks..........................8 2.2 Safety Instructions for Operation......................8 2.3 Setting into Operation..........................9 2.3.1 Install Bearing Sight CP 190......................9 2.3.2 Install Bearing Sight 143-021 / 143-024..................9 2.4 Normal Operation Procedures........................9 2.4.1 Take Direct Sun Bearings (Pencil-of-Light Method)................9 2.4.2 Take Bearings of Terrestrial and Celestial Objects..............10 2.5 Setting out of Operation......................... - Page 4 Bearing Sight Table of Contents 4.3 Bearing Sight CP 190..........................16 4.4 Bearing Sight 143-021........................... 16 4.5 Bearing Sight 143-024........................... 17 5 Annex................................18 5.1 Drawings..............................18 10000001879 Edition: 001...
-
Page 5: List Of Figures
Bearing Sight List of Figures List of Figures Fig. 1: Bearing Sight CP 190, Equipment Overview....................3 Fig. 2: Bearing Sight 143-021, Equipment Overview..................... 4 Fig. 3: Bearing Sight 143-024, Equipment Overview..................... 5 Fig. 4: Bearing Sight CP 190, Principle......................... 6 Fig. - Page 6 Bearing Sight List of Figures 10000001879 Edition: 001...
-
Page 7: List Of Tables
Bearing Sight List of Tables List of Tables Tab. 1: Change History............................1 Tab. 2: Dimensional Drawings..........................2 Tab. 3: Bearing Sight CP190, Maintenance Schedule..................12 Tab. 4: Bearing Sight 143-021 / 143-024, Maintenance Schedule..............13 Edition: 001 10000001879... - Page 8 Bearing Sight List of Tables 10000001879 Edition: 001...
-
Page 9: List Of Abbreviations
Bearing Sight List of Abbreviations List of Abbreviations ISPC Illustrated Spare Parts Catalog Edition: 001 10000001879... - Page 10 Bearing Sight List of Abbreviations 10000001879 VIII Edition: 001...
-
Page 11: Introduction
Change History Tab. 1: Change History Change Remarks Replaces documents: Edition: 001 216 Telescopic Bearing Sight and Bearing Sight 2414 Bearing Sight CP 190 Safety General Safety Regulations The following safety symbols are used in this manual: WARNING! -
Page 12: List Of Annex Documents
Bearing Sight Introduction List of Annex Documents Tab. 2: Dimensional Drawings Documentation No. Designation NB99-HP0065 Bearing Sight CP190 143 E 021 HP005 Telescopic Bearing Sight 143-021 143 E 024 HP005 Bearing Sight 143-024 10000001879 Edition: 001... -
Page 13: Description
It provides the possibility to take compass bearings and relative bearings. 1.2 Equipment Overview Bearing Sight CP 190 Fig. 1: Bearing Sight CP 190, Equipment Overview Diopter sight (fore sight) Swiveling mirror Claw mount Prism... -
Page 14: Fig. 2: Bearing Sight 143-021, Equipment Overview
Bearing Sight 1 Description Telescopic Bearing Sight 143-021 Fig. 2: Bearing Sight 143-021, Equipment Overview Fore sight Aft sight Eyepiece Rotary knob for selecting colored visors Lever for astro-mirror Knurled nut with claw Index line V-shaped sight notch Drying cartridge holder Astro-mirror 10000001879 Edition: 001... -
Page 15: Technical Data
Fig. 3: Bearing Sight 143-024, Equipment Overview Fore sight Astro-mirror with rotary knob Colored visor Aft sight Eyepiece Knurled nut with claw Index line 1.3 Technical Data Type CP 190 143-021 143-024 Height 145.5 mm 352.5 mm 246.5 mm Dimensions Width 138.5 mm 110 mm... -
Page 16: Technical Description
Functional Description 1.5.1 Bearing Sight CP 190 Fig. 4: Bearing Sight CP 190, Principle Bearings of terrestrial and celestial objects are taken by means of aft sight, fore sight and mirror and simultaneously reading off the true bearing. The bearing can be read off through the centrically fixed prism. -
Page 17: Fig. 5: Bearing Sight 143-021 / 143-024, Principle
Bearing Sight 1 Description With the fore sight turned down, its V-shaped sight notch can be used for taking coarse bearings of objects located in the horizontal plane. Through a small window fitted in the base plate, a partial view of the graduation of the 360°... -
Page 18: Operation
Bearing Sight 2 Operation 2 Operation 2.1 Preliminary Remarks User Rights The manual is a complete documentation of the system or equipment. Some functions may not be accessible depending on user rights. All functions or operations are described irrespective of the actual user rights of the user. Markup Elements The manual uses different markup elements for hardware and software. -
Page 19: Setting Into Operation
Install Bearing Sight CP 190 Procedure 1. Place the Bearing Sight CP 190 on the bezel of the repeater compass. 2. Place the 3 holding claws over the edge of the bezel. ► The Bearing Sight CP 190 is securely fixed. -
Page 20: Take Bearings Of Terrestrial And Celestial Objects
Procedure 1. See chapter 1.5.2. 2.5 Setting out of Operation 2.5.1 Uninstall Bearing Sight CP 190 Procedure 1. Remove the 3 holding claws. ► The device is released and it can be taken off into upwards direction. 10000001879 Edition: 001... -
Page 21: Uninstall Bearing Sight 143-021 / 143-024
Bearing Sight 2 Operation 2.5.2 Uninstall Bearing Sight 143-021 / 143-024 Procedure 1. Loosen both knurled nuts by about 1 turn. 2. Take hold of the device in such way that the knurled nut on the eyepiece side is pressed inwards. ►... -
Page 22: Installation And Maintenance
Bearing Sight 3 Installation and Maintenance 3 Installation and Maintenance 3.1 General Information 3.1.1 Reference to ISPC All maintenance tasks comprise information about the support equipment, consumables and spare parts that are used in this task. Besides the designation and the quantity, a reference to the Illustrated Spare Parts is given. -
Page 23: Maintenance Schedule Bearing Sight 143-021 / 143-024
Bearing Sight 3 Installation and Maintenance 3.2.2 Maintenance Schedule Bearing Sight 143-021 / 143-024 Tab. 4: Bearing Sight 143-021 / 143-024, Maintenance Schedule Frequen- Maintenance Task Reference Clean the bearing sight. If required chapter 3.2.4 Replace the drying cartridge. Yearly chapter 3.2.5 Check all hinges, joints and shafts. -
Page 24: Check All Hinges, Joints And Shafts (Type 143-021 / 143-024)
Bearing Sight 3 Installation and Maintenance Procedure 1. Turn out the cartridge holder. 2. Take the fresh cartridge out of its airtight envelope and put it into the holder so that the small openings remain visible. 3. Turn in the cartridge holder, making sure that the sealing is in its proper position. Note If no spare cartridge is available, regenerate the used one by heating it up to anything between 100 and 150 °C by means of a heating plate and allow it to dry out for up to... -
Page 25: Spare Parts Catalog
Bearing Sight 4 Spare Parts Catalog 4 Spare Parts Catalog 4.1 General Remarks All depicted items in the following figure(s) which are not mentioned in the corresponding table(s) are not available as spare part for this unit. Since further development may cause modifications to existing equipment, its conformity with the relevant illustrations and drawings is not always ensured. -
Page 26: Bearing Sight Cp 190
Bearing Sight 4 Spare Parts Catalog 4.3 Bearing Sight CP 190 Fig. 7: 01-0000 Fig. No. Designation 1. Part No. Remarks Item No. 2. Part No. 01-0000 Bearing sight CP 190 2014045 RAL 9005 4.4 Bearing Sight 143-021 Fig. No. Designation 1. -
Page 27: Bearing Sight 143-024
Bearing Sight 4 Spare Parts Catalog 4.5 Bearing Sight 143-024 Fig. 8: 02-0000 Fig. No. Designation 1. Part No. Remarks Item No. 2. Part No. 02-0000 Bearing sight 143-024 4003716 RAL7016 Edition: 001 10000001879... -
Page 28: Annex
Bearing Sight 5 Annex 5 Annex 5.1 Drawings 10000001879 Edition: 001... - Page 30 TO THIS BOX: Hierzu Kasten: NB08-012.00-027 Gewicht / Weight: 2,6 kg DISTANCE FROM MAGNETIC COMPASS STANDARD TYPE: STEERING TYPE: 0,40m 0,30m Benennung: Peildiopter / Bearing sight Maßzeichnung / Dimensional Drawing Klütz Erstellt durch Genehmigt 5000000468789 20.09.23 Zeichnungsnummer: 143-021.HP005 Seite: 1 838.143 20.02.86 Sche...
- Page 31 TO THIS BOX: Hierzu Kasten: NB08-012.00-028 Benennung: Peildiopter / Bearing sight Maßzeichnung / Dimensional Drawing Klütz Erstellt durch Genehmigt Zeichnungsnummer: 143-024.HP005 Seite: 1 500000046789 20.09.23 839.143 20.02.86 Sche von: 1 Ausgabe- Vers. Änderung Name Ers. für: Id.Nr. : datum...
