DMH-ZF9650BT
DMH-ZF7650BT
RDS AV RECEIVER
TEC Certificate No.500102347 for DMH-ZF9650BT
TEC Certificate No.500102337 for DMH-ZF7650BT
https://www.mtcte.tec.gov.in
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DMH-ZF9650BT and is the answer not in the manual?

Questions and answers

Related Manuals for Pioneer DMH-ZF9650BT

Summary of Contents for Pioneer DMH-ZF9650BT

  • Page 1 DMH-ZF9650BT DMH-ZF7650BT RDS AV RECEIVER Operation Manual TEC Certificate No.500102347 for DMH-ZF9650BT TEC Certificate No.500102337 for DMH-ZF7650BT https://www.mtcte.tec.gov.in...

  • Page 2: Table Of Contents

    Contents Thank you for buying this Pioneer product. Please read through these instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this document in a safe place for future reference.
  • Page 3 ■ Playing data in a USB..............57 ■ Using external devices (HDMI™) ..........63 ■ Using external devices (AUX) ........... 65 ■ Displaying video images from the back camera/2nd camera ..................67 ■ Updating the firmware wirelessly ........... 69 ■ Settings..................

  • Page 4: Precaution

    Precaution Certain country and government laws may prohibit or restrict the placement and use of this product in your vehicle. Please comply with all applicable laws and regulations regarding the use, installation and operation of this product. To ensure safe driving WARNING •...

  • Page 5: In Case Of Trouble

    In case of trouble Should this product fail to operate properly, contact your dealer or nearest authorised Pioneer Service Station. When taking this product to the dealer or authorised Pioneer Service Station, make sure to bring both the unit and LCD display.

  • Page 6: About This Manual

    In this manual, the DMH-ZF9650BT screens when [Other] is selected in [Location setting] are used as examples in these instructions. Meanings of symbols used in this manual This indicates to touch the appropriate soft key on the touch screen.

  • Page 7: Important Safety Information

    • If liquid or foreign matter should get inside this product, park your vehicle in a safe place, turn the ignition switch off (ACC OFF) immediately and consult your dealer or the nearest authorised Pioneer Service Station. Do not use this product in this condition because doing so may result in a fire, electric shock or other failure.
  • Page 8 • Please remember to fasten your seat belt at all times while operating your vehicle. If you are ever in an accident, your injuries can be considerably more severe if your seat belt is not properly buckled. • Never use headphones while driving. - 8 -...

  • Page 9: To Avoid Battery Exhaustion

    To avoid battery exhaustion Be sure to run the vehicle engine while using this product. Using this product without running the engine can drain the battery. WARNING Do not install this product in a vehicle that does not have an ACC wire or circuitry available. - 9 -...

  • Page 10: Protecting The Lcd Panel And Screen

    Protecting the LCD panel and screen • Do not expose the LCD screen to direct sunlight when this product is not used. This may result in LCD screen malfunction due to the resulting high temperatures. • If you use your mobile phone close to the LCD screen and the image gets distorted in the form of spots, coloured stripes, etc., move your mobile phone away from the screen.

  • Page 11: Parts And Controls

    Parts and controls Main unit DMH-ZF9650BT DMH-ZF7650BT • Touch when the main unit and the iPhone/smartphone are not connected via Bluetooth to display the Bluetooth connection screen. • When the main unit and the iPhone/smartphone are connected via Bluetooth, the screen that is displayed varies depending on the configuration of [Companion App Key settings].

  • Page 12: Using The Touch Panel

    Touch to activate the voice recognition mode such as Siri when the iPhone is connected to the unit via Bluetooth or USB. Touch when connected to Android Auto to start Android Auto voice recognition. Touch and hold to display the mobile device search or selection screen. The volume is adjusted each time the buttons are pressed.
  • Page 13 Operating list screens ・ ・ ・ File Touching an item on the list allows you to narrow down the options and proceed to the next operation. Drag the list to view any hidden items. Appears when not all the characters can be displayed in the display area. If you touch the key, the remaining characters will display via scroll.

  • Page 14: Home Menu Screen

    Home menu screen 12:38 6/10 Favourite source/application area Touch to see the selected source/application. The source/application to be displayed can be changed as desired (page 24). NOTE If linking to PxLink app or update of the firmware is not complete, the settings icon and setting items will be displayed with a red badge.
  • Page 15 [Reconnect] is displayed on the home menu screen only when the Wi-Fi connection (Wireless Apple CarPlay or Android Auto) has failed or been disconnected automatically (page 93). - 15 -...
  • Page 16 Shortcuts Shortcuts enable you to easily operate frequently used functions on the home menu screen. NOTES • The position of the shortcuts on the home menu screen depends on the driving position setting (page 90). • Some of the shortcut keys become unavailable depending on the source. •...

  • Page 17: Starting Up The Unit

    Starting up the unit Start the engine to boot up the system. The [Select Program Language] screen appears. From the second time on, the screen shown will differ depending on the previous conditions. Select the language. Touch The [Location setting] screen appears. Select the location.

  • Page 18: Using The Pxlink App For The Av Main Unit

    Using the PxLink App for the AV main unit PxLink is an app that allows you to configure and transfer various settings of this unit. You can also update this unit’s firmware wirelessly by using this app. NOTE If linking to PxLink app is not complete, the settings icon and [Companion App Info] setting item will be displayed with a red badge.

  • Page 19: Starting Procedure

    Starting procedure • When connecting PxLink app for the first time on your Android device, disconnect Android Auto. Turn on the Wi-Fi and Bluetooth functions on your iPhone or smartphone. Touch Touch then Touch [Wi-Fi settings]. Touch [Access point] and turn it [On]. Touch Touch [Connection].

  • Page 20: Bluetooth® Connection

    Bluetooth® connection Starting procedure • If five devices are already paired, the message confirming whether to delete the registered device is displayed. If you want to delete the device, touch [Agree]. If you want to delete other device, touch [Go to DeviceList] and delete the devices manually on the mobile device select screen.

  • Page 21: Bluetooth Settings

    Connecting a third Bluetooth device (HFP only) Perform pairing from an unconnected Bluetooth device when two Bluetooth devices are connected. Of the two connected devices, the first device is disconnected and the unconnected device is connected. Bluetooth settings Touch Touch then Touch [Bluetooth settings].

  • Page 22: Switching The Connected Bluetooth Device

    Switching the connected Bluetooth device • You can register up to five Bluetooth devices on this product (page 20). • You can connect one of the registered devices to this product. In cases where the registered device is equipped with a phone function, a total of two devices can be connected at the same time when using the phone function.

  • Page 23: Wi-Fi® Connection

    Wi-Fi® connection By connecting your Wi-Fi certified mobile device to this product via Wi-Fi connection, you can use Apple CarPlay or Android Auto wirelessly. See the following chapters for the procedure on how to use Apple CarPlay or Android Auto wirelessly. • Apple CarPlay (page 35) •...

  • Page 24: Customising The Home Menu Screen

    Customising the home menu screen The [Settings] icon cannot be removed from the favourite source/application area. The [Apple CarPlay] icon and the [Android Auto] icon can be deleted from the favourite source/application area, but if Apple CarPlay or Android Auto is started, the respective icon is added automatically.
  • Page 25 TIPS • The clock and the artwork can also be removed from the favourite source/application area. • When you cancel removing, touch [Done]. Touch [Done]. Rearranging the icons in the favourite source/ application area Touch Touch [Edit]. Drag the icon to the desired position. The clock display cannot be moved.

  • Page 26: Source/Application

    • Displaying video images from the back camera/2nd camera (page 67) NOTES • HDMI and the 2nd camera can be used on DMH-ZF9650BT only. • iDatalink is equipped for Australia and New Zealand and can be used on DMH-ZF7650BT only.

  • Page 27: Displaying The Av Operation Screen

    Source list Touch to see the selected source. Selecting [Power OFF] will turn off most of the functions on this unit. The [Power OFF] mode is released in the following cases: • Footage from the rear view camera is input when the vehicle is in reverse. •...
  • Page 28 Selecting a source/an application [Source OFF] is only available for AV sources. Source/application selection screen Touch then [Sources]. Touch the source/application icon. When you select [Source OFF], the AV source is turned off. - 28 -...

  • Page 29: Radio

    Radio Starting procedure Touch Touch [Radio]. The radio screen appears. Basic operation 12:38 6/10 Seek Recalls the preset channel stored to a key from memory. Stores the current broadcast frequency to a key. Displays the preset channel list. Select an item on the list ([1] to [6]) to switch to the preset channel. Selects the FM1, FM2, FM3 or AM band.

  • Page 30: Searching By Pty Information

    Manual tuning Seek tuning or non stop seek tuning Releasing the key in a few seconds skips to the nearest station from the current frequency. Keep holding the key for long seconds to perform non stop seek tuning. Searches for a broadcast by PTY information (page 30). NOTE This function is available only when a location other than [Russia] is selected in [Location setting].

  • Page 31: Radio Settings

    To cancel the storage process Touch [Cancel]. Radio settings Touch Touch then The system setting screen appears. Touch [AV Source settings]. Touch [Radio settings]. The menu items vary according to the source. Menu Item Description [Local] Local seek tuning allows you to only tune into [Off] radio stations with sufficiently strong signals.
  • Page 32 Menu Item Description [Auto PI]*1 Searches for the same PI (Programme [On] [Off] Identification) code broadcast station from all frequency bands automatically when the broadcasting station contains RDS data. NOTE Even if you set to [Off], the PI search is automatically performed when the tuner cannot get a good reception.

  • Page 33: Apple Carplay

    Apple CarPlay You can operate iPhone applications with finger gestures such as tapping, dragging, scrolling or flicking on the screen of this product. • The compatible finger gestures vary depending on the application for the iPhone. • To use the Apple CarPlay function, first turn off the WebLink function. •...

  • Page 34: Using Apple Carplay

    • Apple CarPlay allows access to applications other than those listed that are subject to limitations while driving. • PIONEER IS NOT RESPONSIBLE AND DISCLAIMS LIABILITY FOR THIRD PARTY (NON- PIONEER) APPS AND CONTENT, INCLUDING WITHOUT LIMITATION ANY INACCURACIES OR INCOMPLETE INFORMATION.

  • Page 35: Setting The Driving Position

    Setting the driving position To achieve optimum usability of Apple CarPlay, set the driving position setting correctly according to the vehicle. The setting will be applied the next time an Apple CarPlay compatible device is connected to this product. Touch Touch then The communication setting screen appears.

  • Page 36: Adjusting The Volume

    on, only a Bluetooth audio connection will be possible for devices other than the device connected via Apple CarPlay. • Hands-free phoning via Bluetooth wireless technology is not available while Apple CarPlay is on. If Apple CarPlay is turned on during a call on a mobile phone other than an Apple CarPlay compatible device, the Bluetooth connection will be terminated after the call ends.

  • Page 37: Using Shortcuts

    Touch to mute. Touch again to cancel mute. The mute function is not available while the enhanced Siri function is used. Touch [+]/[-] to adjust the guidance volume. Displays the main sound volume. To adjust the main sound volume, press VOL (+/-) on the unit or touch [+]/[-].

  • Page 38: Android Auto

    Android Auto™ You can operate Android applications with finger gestures such as tapping, dragging, scrolling or flicking on the screen of this product. • The compatible finger gestures vary depending on the application for the smartphone. Compatible Android devices For details about compatibility of Android models, refer to the following website. https://support.google.com/androidauto For wireless connections Compatible Android phone and compatible active data plan required.

  • Page 39: Using Android Auto

    Touch [Android Auto]. 12:38 6/10 The playback screen appears. Wireless connection Connect an Android Auto compatible device to this product wirelessly (page 40). Touch Touch [Android Auto]. 12:38 6/10 The playback screen appears. Using Android Auto Android Auto may not be available in your country or region. For details about Android Auto, please refer to the Google support site: - 39 -...
  • Page 40 • Android Auto allows access to applications other than those listed that are subject to limitations while driving. • PIONEER IS NOT RESPONSIBLE AND DISCLAIMS LIABILITY FOR THIRD PARTY (NON- PIONEER) APPS AND CONTENT, INCLUDING WITHOUT LIMITATION ANY INACCURACIES OR INCOMPLETE INFORMATION.

  • Page 41: Setting The Auto-Launch Function

    ▶How can the voice recognition function help? You can use the voice recognition function by touching the button once Android Auto is activated. NOTES • For details on USB connection, refer to the Quick start guide. • When the device for Android Auto is connected to this unit, the device is also connected via Bluetooth at the same time.
  • Page 42 • The Android Auto screen is displayed automatically only when an Android Auto compatible device is correctly connected to this product. Touch Touch then Touch [Android Auto Auto-launch] to switch [On] or [Off]. - 42 -...

  • Page 43: Weblink

    Using WebLink® Important • Pioneer is not responsible for content or functions accessed via WebLink®, which are the responsibility of the application and content providers. • Availability of non-Pioneer content and services, including apps and connectivity, may change or discontinue without notice.

  • Page 44: Basic Operation

    Touch [WebLink]. 12:38 6/10 For smartphone (Android) users System requirement • For the latest OS support information, please visit HelloWebLink.com. • The video playback capability depends on the connected Android device. • For USB connection, refer to the Quick start guide. •...

  • Page 45: Hands-Free Phoning

    Hands-free phoning To use this function, you need to connect your mobile phone to this product via Bluetooth in advance (page 20). Making a phone call Touch then [Sources]. Touch [Phone]. The phone menu screen appears. Touch one of the call icons on the phone menu screen. The following items are displayed.

  • Page 46: Using The Preset Dial Lists

    Using phone book Select a contact from the phone book. Touch the desired name on the list then select the phone number. • The contacts on your phone will be automatically transferred to this product. • Update the phone book manually. •...

  • Page 47: Receiving A Phone Call

    Deleting a phone number Touch then [Sources]. Touch [Phone]. Touch Touch Touch [Yes]. Receiving a phone call Touch to answer the call. Touch to end the call. • Touch while receiving an Incoming Call to put current call on hold and accept new call.

  • Page 48: Setting The Private Mode

    Phone setting Touch Touch then Touch [Bluetooth settings]. Menu Item Description [Auto Answer] Select [On] to answer an incoming call automatically. [On] [Off] [Ring Tone] Select [Off] to use the ring tone of the paired device or [On] [Off] select [On] to use the ring tone of this unit. [Invert Name] Select [Yes] to change the order of the first and last names in the phone book.
  • Page 49 • The line-of-sight distance between this product and your mobile phone must be 10 meters or less when sending and receiving voice and data via Bluetooth technology. • With some mobile phones, the ring sound may not be output from the speakers. •...

  • Page 50: Bluetooth Audio

    Bluetooth audio Before using the Bluetooth audio player, register and connect the device to this product (page 20). • Depending on the Bluetooth device connected to this product, the available operations with this product may be limited or differ from the descriptions in this manual.
  • Page 51 Track number indicator Switches between playback and pause. Skips files forward or backward. Sets a repeat play range. Switches between random and normal file playback order. Selects a file or folder from the list to playback. NOTE This function is available only when the AVRCP version of the Bluetooth device is 1.4 or higher.

  • Page 52: Idatalink

    iDatalink™ This function equipped for Australia and New Zealand and can be used on DMH- ZF7650BT only. To activate the function, set [Australia] in [Location setting]. Using iDatalink You can access the satellite radio source provided for the vehicle. The vehicle information and many OEM systems such as steering wheel controls, warning chimes, driver safety systems, etc.
  • Page 53 • For details on installing the firmware, refer to iDatalink Maestro website. • For details on connecting this product to iDatalink Maestro, refer to the Quick start guide. • You can also check the device number on the [Firmware Information] screen of this product (page 80).
  • Page 54 Using the functions on [Car Sources] [Car Sources] is operated almost the same way as the built-in AV sources on this product is operated. For details on the operation, refer to the following relevant pages. • Operating via USB/iPhone (page 57) (page 33) •...
  • Page 55 Vehicle Information screen Climate screen Parking Assist screen - 55 -...

  • Page 56: Displaying Obstacle Detection Information

    Speed Radar Detector screen 145 169 Displaying obstacle detection information This function is only available for vehicles equipped with a parking sensor system. CAUTION This function is intended solely to assist the driver’s vision. It does not detect all dangers and obstacles, and is not a substitute for your attentiveness, judgement and care while parking your vehicle.

  • Page 57: Playing Data In A Usb

    Playing data in a USB Plugging/unplugging a USB storage device You can play audio, video or still image files stored in a USB storage device. Plugging a USB storage device • This product may not achieve optimum performance with some USB storage devices. •...
  • Page 58 Playback is performed in order of folder numbers. Folders are skipped if they contain no playable files. Basic operation You can set the screen size for the video and image files (page 92). Audio source Audio source screen 1 12:38 6/10 9999’99”...
  • Page 59 Switches the following media file types. [Music]: Audio files [Video]: Video files [Photo]: Image files Selects a file from the list. Touch a file on the list to playback. Touching a folder on the list shows its contents. You can play a file on the list by touching it.
  • Page 60 This function is available for the USB storage device only. Touch to create a database. Music Browse mode will be available after the database has been created. Touch Touch the desired category to display the file list. Touch the item. Refine the item until the desired song title or file name is displayed on the list.
  • Page 61 Performs frame-by-frame playback. Performs slow-motion playback. Sets a repeat play range for all files/the current folder/the current file. Switches the audio language. Switches the following media file types. [Music]: Audio files [Video]: Video files [Photo]: Image files Selects a file from the list. Touch a file on the list to playback.

  • Page 62: Usb Settings

    Switches between playback and pause. Skips files forward or backward. Selects the previous folder or the next folder. Rotates the displayed picture 90° clockwise. Sets a repeat play range for all files/the current folder. Switches between random and normal playback order of the files that are currently selected for repeat playback.

  • Page 63: Using External Devices (Hdmi™)

    Using external devices (HDMI™) This function can be used on DMH-ZF9650BT only. CAUTION For safety reasons, video images cannot be viewed while your vehicle is in motion. To view video images, stop in a safe place and apply the handbrake.
  • Page 64 Hides the touch panel keys. To display the keys again, touch anywhere on the screen. You can set the screen size for the video image (page 92). - 64 -...

  • Page 65: Using External Devices (Aux)

    Using external devices (AUX) You can display the video image output by the device connected to video input. • A Mini-jack AV cable (sold separately) is required for connection. For details, refer to the Quick start guide. CAUTION For safety reasons, video images cannot be viewed while your vehicle is in motion. To view video images, stop in a safe place and apply the handbrake.
  • Page 66 Basic operation 12:38 6/10 Hides the touch panel keys. To display the keys again, touch anywhere on the screen. • You can set the screen size for the video image (page 92). Switches between the video input and audio input. - 66 -...

  • Page 67: Displaying Video Images From The Back Camera/2Nd Camera

    The 2nd camera function can be used on DMH-ZF9650BT only. You can display the video image output using the device connected to the back camera input or 2nd camera input. For details, refer to the Quick start guide.
  • Page 68 Touch to switch the camera view. The 2nd camera video footage is displayed on the screen. NOTE If you touch , the previous screen temporarily appears and the rear view mode resumes after 7 seconds. (If you switch to another screen, the rear view mode may not resume depending on the screen, such as in the case of menu screens.) - 68 -...

  • Page 69: Updating The Firmware Wirelessly

    Updating the firmware wirelessly To update the firmware wirelessly, PxLink app must be installed in advance. You can only update the firmware when the vehicle is stopped and the handbrake is engaged. CAUTION • Never turn this product or your iPhone/smartphone off while the firmware is being updated. •...
  • Page 70 • If an error message appears on the screen, touch the display and perform the above steps again. NOTES • When an iPhone/smartphone (Android) on which PxLink app is installed is connected to the main unit and information about the latest firmware update is received, a notification is displayed on the screen of the main unit.

  • Page 71: Settings

    Settings You can adjust various settings in the main menu. Displaying the setting screen Touch Touch Touch one of the following categories, then select the options. System settings (page 72) Theme settings (page 84) Audio settings (page 85) Communication settings (page 89) Favourite menu Register your favourite menu items in [Favourites] to be able to quickly navigate from the [Favourites] screen to the desired menu screen with a single touch.

  • Page 72: System Settings

    Touch the star icon of the menu item to register in Favourites. The star icon for the selected menu is filled in. To cancel the registration, touch the star icon in the menu column again. Selecting a menu item registered in Favourites Touch Touch Touch...
  • Page 73 Touch [+]/[-] to adjust the volume of the speaker’s voice. [0] to [40] [Ring Volume] Touch [+]/[-] to adjust the ring volume. [0] to [40] [Luminous Bar settings] [Luminous Bar settings] can be used on DMH-ZF9650BT only. Menu Item Description [Brightness] Touch to adjust the brightness of the luminous [1] to [10] bar.
  • Page 74 2nd camera image. CAUTION Pioneer recommends the use of a camera which outputs mirror reversed images, otherwise the screen image may appear reversed. • Immediately verify whether the display changes to the rear view camera image when the gear stick is moved to REVERSE (R) from another position.
  • Page 75 • When the screen changes to full-screen rear view camera image during normal driving, switch to the opposite setting in [Camera Polarity]. • If you touch while the camera image is displayed, the displayed image turns off temporarily. Menu Item Description [Rear Viewing Camera Setting rear view camera activation.
  • Page 76 Menu Item Description [Parking Assist Guide Adjusting the guidelines by dragging or touching Adjust]* / / / on the screen. Touch [Default] to reset the settings. Turn the vehicle off before getting out to place the markings. CAUTION When adjusting the guidelines, park the vehicle in a safe place and apply the handbrake;...
  • Page 77 [PAL-M] [PAL-N] [SECAM] NOTES • [2nd Camera] can be used on DMH-ZF9650BT only. • [RSE] can be used on DMH-ZF7650BT only. If you use DMH-ZF7650BT, you can use [RSE] only when [Australia] is selected in [Location setting].
  • Page 78 [Restore settings] • This setting is available only when you stop your vehicle in a safe place and apply the handbrake. • The source is turned off and the Bluetooth connection is disconnected before the process starts. • Before starting the restore process, disconnect any device that is connected to the USB port.
  • Page 79 Menu Item Description [Dimmer Duration] Adjust the time that the dimmer is turned on or off by dragging the cursors or touching You can use this function when [Dimmer Trigger] is set to [Time]. • Each touch of moves the cursor backward or forward in the 15 minute width.
  • Page 80 Menu Item Description [Contrast] Adjust the contrast. [-24] to [+24] [Colour]* Adjust the colour saturation. [-24] to [+24] [Hue]* Adjust the tone of colour (which colour is emphasised, red [-24] to [+24] or green). [Dimmer] Adjust the brightness of the display. [+1] to [+48] [Temperature] Adjust the colour temperature, resulting in a better white...
  • Page 81 Menu Item Description [Firmware Update] Update to the latest version of the firmware by using a USB storage device or wireless connection. To update the firmware via wireless connection, PxLink app is required. For details on performing the wireless update, refer to Updating the firmware wirelessly (page 69).
  • Page 82 Menu Item Description [3D Calibration Status] Check the sensor learning status, such as the degree of learning. You can also check the current sensor values and the total number of speed pulses. To delete the learned results stored in the sensor, follow the below instructions.
  • Page 83 • Some characters may not be displayed properly. [Location setting] Menu Item Description [Location setting] Select the usage location. DMH-ZF9650BT: [Russia] [Latin America] [Other] DMH-ZF7650BT: [Russia] [Australia] [Latin America] [Other] [Safe Mode] Menu Item...

  • Page 84: Theme Settings

    NOTE [OEM Volume settings] can be used on DMH-ZF7650BT only. To activate this function, connect to the iDatalink adaptor. Theme settings The menu items vary according to the source. Menu Item Description [Background] Select the wallpaper from the preset items of the main unit or an original image via PxLink app.

  • Page 85: Audio Settings

    Menu Item Description [Appearance] Switches the screen appearance to Light mode or Dark mode. (This setting is also applied to the screen of Apple CarPlay or Android Auto.) [Dimmer] Switches to the Light mode or the Dark mode automatically according to the [Dimmer settings] (page 78).
  • Page 86 Menu Item Description [Auto Sound Leveliser] Corrects the volume according to the travel speed. [OFF] [LOW] [MID-LOW] [MID] [MID-HIGH] [HIGH] [Source Level Adjuster] Adjust the volume level of each source to prevent radical [-4] to [+4] changes in volume when switching between sources other than FM.
  • Page 87 Menu Item Description [Time Alignment] Select or customise the time alignment settings to reflect [On] [Off] the distance between the listener’s position and each Listening Position*1*2 speaker. You need to measure the distance between the [Off] [Front Left] head of the listener and each speaker unit. •...
  • Page 88 Menu Item Description [Mute Level] If an interruption caused by an audio signal occurs while Apple CarPlay or Android Auto is being used, select mute or attenuate the volume of the AV source and iPhone/ smartphone application. [ATT] The volume becomes 10 dB lower than the current volume. [Mute] The volume becomes 0.

  • Page 89: Communication Settings

    Switches the subwoofer phase between normal and reverse position. • You can also adjust the [High] and [Mid] phase in [Network Mode]. Switches the [LPF]/[HPF] setting to [On] or [Off]. When it is turned off, the high- [LPF]/[HPF] pass filter or low-pass filter of each speaker can also be turned on by touching the graph lines.
  • Page 90 [Wi-Fi settings] Menu Item Description [Wi-Fi settings] (page 23). [Driving Position] Menu Item Description [Driving Position] Setting the driving position. • Apple CarPlay (page 33) [Right] [Left] NOTE The position of the shortcuts on the home menu screen depends on the driving position setting (page 16). [Notifications] Menu Item Description...
  • Page 91 [Companion App Info] Menu Item Description [Companion App Info] A screen with information on downloading PxLink app is displayed. Touch [Connect] to display a screen with information on linking the main unit and PxLink app. Touch [Skip] to display the home menu screen. If the main unit and PxLink app are not linked, a badge is displayed in the [Companion App Info] item.

  • Page 92: Other Functions

    Other functions Setting the clock display You can set the time format, time zone, daylight saving and the date format. However, the time and date are automatically adjusted by the GPS aerial and cannot be adjusted by the user. Touch the current time on the screen. Set the following items in the settings.
  • Page 93 Touch the screen display mode key. 12:38 6/10 Screen display mode key Touch the desired mode. When a video is viewed in the widescreen mode with a setting that does not match its original aspect ratio, it may appear different. Image files can be set to either [Normal] or [Trimming] in the widescreen mode.

  • Page 94: Restoring This Product To The Default Settings

    Restoring this product to the default settings You can restore settings or recorded content to the default settings from [Restore all settings] in (page 78). - 94 -...

  • Page 95: Compatible Iphone Models

    Compatible iPhone models • iPhone 14 Pro Max • iPhone 14 Pro • iPhone 14 Plus • iPhone 14 • iPhone SE (3rd generation) • iPhone 13 Pro Max • iPhone 13 Pro • iPhone 13 • iPhone 13 mini •...

  • Page 96: Handling The Usb Connector

    • To prevent data loss and damage to the storage device, never remove it from this product while data is being transferred. • Pioneer cannot guarantee compatibility with all USB mass storage devices and assumes no responsibility for any loss of data on media players, iPhone, smartphone or other devices while using this product.

  • Page 97: Detailed Information For Playable Media

    Detailed information for playable media Compatibility Common notes about the USB storage device • Do not leave the USB storage device in any location with high temperatures. • Depending on the kind of the USB storage device you use, this product may not recognise the storage device or files may not be played back properly.

  • Page 98: Media Compatibility Chart

    Media compatibility chart General • Maximum playback time of audio file stored on an USB storage device: 8 h (480 minutes) USB storage device CODEC FORMAT MP3, WMA, WAV, AAC, FLAC, AVI, MPEG-PS, MPEG-TS, MP4, 3GP, MKV, MOV, ASF, FLV, M4V MP3 compatibility •...
  • Page 99 SAMPLING FREQUENCY 8 kHz to 48 kHz TRANSMISSION RATE 16 kbps to 320 kbps (CBR) FLAC compatibility • If the sampling frequency of the file exceeds 48 kHz, the sampling frequency is reduced automatically to 48 kHz when the file is played. SAMPLING FREQUENCY 8 kHz to 192 kHz QUANTISATION BIT RATE...
  • Page 100 .mkv Maximum resolution 1 920 × 1 080 Maximum frame rate 30 fps .mov Maximum resolution 1 920 × 1 080 Maximum frame rate 30 fps .flv Maximum resolution 1 920 × 1 080 Maximum frame rate 30 fps .wmv/.asf Maximum resolution 1 920 ×...

  • Page 101: Specifications

    14.4 V DC (12.0 V to 14.4 V allowable) Grounding system: Negative type Maximum current consumption: 10.0 A <DMH-ZF9650BT> Dimensions (W × H × D): Body (excluding the monitor mounting part): 178 mm × 50 mm × 156 mm Nose: 170 mm ×...
  • Page 102 22 W × 4 (50 Hz to 15 kHz, 5 %THD, 4 Ω LOAD, Both Channels Driven) Load impedance: 4 Ω (4 Ω to 8 Ω [2 Ω for 1 ch] allowable) Preout output level (max): 4.0 V (DMH-ZF9650BT), 2.0 V (DMH-ZF7650BT) Equaliser (13-Band Graphic Equaliser): Frequency: 50 Hz/80 Hz/125 Hz/200 Hz/315 Hz/500 Hz/800 Hz/1.25 kHz/2 kHz/3.15 kHz/5 kHz/8...
  • Page 103 Speaker level: -24 dB to +10 dB (1 dB/step) <Network Mode> HPF (High): Frequency: 1.25 kHz/1.6 kHz/2 kHz/2.5 kHz/3.15 kHz/4 kHz/5 kHz/6.3 kHz/8 kHz/10 kHz/12.5 kHz Slope: -6 dB/oct, -12 dB/oct, -18 dB/oct, -24 dB/oct Phase (High): Normal/Reverse HPF (Mid): ON/OFF Frequency: 25 Hz/31.5 Hz/40 Hz/50 Hz/63 Hz/80 Hz/100 Hz/125 Hz/160 Hz/200 Hz/250 Hz Slope:...
  • Page 104 AAC decoding format: AAC-LC (Low Complexity) FLAC decoding format: Ver. 1.3.0 WAV signal format: Linear PCM Sampling frequency: 16 kHz/22.05 kHz/24 kHz/32 kHz/44.1 kHz/48 kHz/96 kHz/192 kHz <USB image> JPEG decoding format: .jpeg, .jpg, .jpe Pixel Sampling: 4:2:2, 4:2:0 Decode Size: MAX: 7 680 (H) ×...
  • Page 105 Bluetooth Version: Bluetooth 5.2 certified Output power: +4 dBm Max. (Power class 2) Bluetooth Low Energy output power: +5 dBm Max. Frequency band(s): 2 402 MHz to 2 480 MHz Bluetooth profiles: HFP (Hands Free Profile) 1.7.2 PBAP (Phone Book Access Profile) 1.2.3 A2DP (Advanced Audio Distribution Profile) 1.3.2 AVRCP (Audio/Video Remote Control Profile) 1.6.2 SPP (Serial Port Profile) 1.2...
  • Page 106 LW tuner (Location setting: Russia) Frequency range: 153 kHz to 281 kHz Wi-Fi Version: IEEE 802.11 a/n/ac (5 GHz) Frequency channel: 149 ch (5 GHz) Security: WPA2 (Personal)/WPA3 (Personal) Output power: +14.5 dBm Max (5 GHz) GNSS receiver System: GPS L1C/A, SBAS L1C/A, GLONASS L1OF, Galileo E1B/C SPS (Standard Positioning Service) Reception system: 92 channel Multi-channel reception system...

  • Page 107: Trademark · Copyright, Etc

    Kernel 2.0 under T-License 2.2 granted Bluetooth SIG, Inc. and any use of such by TRON Forum (www.tron.org). marks by Pioneer Corporation is under licence. Other trademarks and trade • Pioneer accepts no responsibility for names are those of their respective data lost from an iPhone, even if that owners.
  • Page 108 not responsible for the operation of this vehicle or its compliance with safety and regulatory standards. Please note that the use of this product with iPhone, iPod, or iPad may affect wireless performance. • Works with Siri through the microphone. •...

  • Page 109: Troubleshooting

    The screen is covered by a caution found here, contact your dealer or the message and the video cannot be nearest authorised Pioneer service shown. facility. • The handbrake lead is not connected or the handbrake is not applied.
  • Page 110 – Select the appropriate setting for that • The reverse lead on the receiver may image. not be connected to the proper wire at the reverse lamp. iPhone cannot be operated. – Check the connection and make sure • The iPhone is frozen. that the violet/white lead of the –...
  • Page 111 – Perform the connection process. – Disconnect the smartphone from the • Of the two mobile phones connected to cable and wait until the smartphone this product at the same time, if the first cools down. • More battery power was consumed phone is dialling, ringing or a call is in progress, dialling cannot be performed than was gained from charging.

  • Page 112: Error Messages

    If the error persists, storage device. record the error message and contact – Check that the files in the USB storage device your dealer or your nearest Pioneer are compatible with this product. service centre. • Security for the connected USB storage device is enabled.
  • Page 113 • This type of file is not supported on this performing the above action, please product. contact your dealer or an authorised – Select a file that can be played. Pioneer Service Station. Apple CarPlay Android Auto Connection failed. To use Android Auto, please check the •...
  • Page 114 Bluetooth pairing failed. • The Bluetooth pairing failed for some reasons. – Pair this product with the device manually. To use Android Auto, please stop your car and check your Android phone. • The default settings are displayed on the screen of the Android Auto compatible device or images are not output from the Android Auto compatible device.

  • Page 115: Appendix

    Content application(s) or service by its product: provider. • Latest version of the Pioneer compatible • Pioneer is not liable for any issues that connected content application(s) for the may arise from incorrect or flawed app- smartphone, available from the service based content.

  • Page 116: Notice Regarding Video Viewing

    Availability of non- operating temperature range, because Pioneer content and services, including the LCD screen may not operate apps and connectivity, may change normally and could be damaged.
  • Page 117 LCD screen. Image quality will improve with an increase in temperature. • The product lifetime of the LED backlight is as follows; DMH-ZF9650BT: More than 10 000 hours DMH-ZF7650BT: More than 30 000 hours However, the lifetime may decrease if used in high temperatures.
  • Page 118 Pioneer Electronics Asiacentre Pte. Ltd. https://pioneer-india.in/ Pioneer India Electronics Pvt. Ltd. <Latin> https://pioneer-latin.com/ Pioneer International Latin America, S.A. https://www.pioneer-mexico.com.mx/ Pioneer Electronics de México S.A. de C.V. <Russia> https://www.pioneer-rus.ru/ Pioneer RUS Limited Liability Company © 2024 PIONEER CORPORATION <OPM_DMHZF9650BTES_EG_A> ES <KKYZ24G>...
