Summary of Contents for Crosley CFW7700LR0
- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. CROSLEY CFW7700LR0 Owner's Manual Shop genuine replacement parts for CROSLEY CFW7700LR0 Find Your CROSLEY Dryer Parts - Select From 130 Models -------- Manual continues below --------...
-
Page 2: Table Of Contents
Care and Cleaning .......... 19-22 Features ...............5 Solutions to Common Problems ....... 23-26 Operating Instructions ........6-15 Warranty ............27 Washer Settings Chart ......... 16 Notes ..............28 Stain Removal Guide ........17-18 Français ..............29 www.crosley.com USA 1-800-944-9044 Canada 1-800-265-8352... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING WARNING For your safety the following information in this manual Please read all instructions before using this washer. must be followed to minimize the risk of fi re or explosion or to prevent property damage, personal injury or death. Recognize safety symbols, words and Do not store or use gasoline or other fl... -
Page 4: Prevent Fire
IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fi re, electrical shock, or injury to persons when using this washer, comply with the basic warnings listed below. Failure to comply with these warnings could result in serious personal injuries. You can be killed or seriously injured if you don’t follow these Important Safety Instructions: PREVENT FIRE PROTECT CHILDREN... -
Page 5: Prevent Injury
IMPORTANT SAFETY INSTRUCTIONS PREVENT INJURY PREVENT INJURY AND DAMAGE TO THE WASHER • To prevent shock hazard and assure stability during To prevent serious personal injury and damage to the operation, the washer must be installed and electrically washer: grounded by a qualifi ed service person in accordance •... -
Page 6: Features
Vent Latch Stainless Steel Wash Drum Adjustable Cascading Leveling Legs Wash Vanes ® As an ENERGY STAR Partner, the Crosley Corporation has determined that this prod- uct meets the ENERGY STAR ® guidelines for energy effi ciency. -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Normal Operating Sounds You may or may not hear the following sounds from your new washer: A. DRAIN HOSE The washer has a fl exible drain hose to carry water from the washer to the stand pipe of your home. - Page 8 OPERATING INSTRUCTIONS Operating Your Washer, continued Prepare items for washing. Add laundry load to washer. • Empty pockets. • Brush off lint and dirt. Shake out rugs and beach towels. • Close zippers, fasten hooks, tie strings and sashes, and remove non-washable trims and ornaments. •...
-
Page 9: For Best Results
OPERATING INSTRUCTIONS Operating Your Washer, continued Add laundry products to the dispenser. For best results Use a low-sudsing, high effi ciency detergent to prevent oversudsing in front load washers. Look for this symbol on the detergent label: Detergent, liquid chlorine bleach and liquid fabric soft- ener will be dispensed at the proper times in the cycle. - Page 10 OPERATING INSTRUCTIONS Operating Your Washer, continued Other Wash Products Liquid Chlorine Bleach • Color-safe bleach, water conditioner, detergent • If desired, add liquid chlorine bleach to the cham- booster and enzyme products may be added with the ber labeled “Liquid Bleach” and marked with this detergent.
- Page 11 OPERATING INSTRUCTIONS Operating Your Washer, continued when the buttons are pressed. To change the set- tings or options, press Pause, make the new selec- Select the appropriate cycle and settings for tions and press Start again. the load. • To change the cycle once the cycle has begun, •...
-
Page 12: Cycle Selection
OPERATING INSTRUCTIONS This manual covers many models and not all cycles, options, or features listed are available on every model. Consoles shown above for reference only. Your model may differ. Cycle Selection Turn the cycle selector in either direction to the cycle NOTE desired. -
Page 13: Whitest Whites
OPERATING INSTRUCTIONS Cycle Selection, continued Allergy Normal If you have asthma or allergy sufferers in your home, The Normal cycle provides 15 minutes of reversing use this cycle to combine hot water temperature tumble wash action for normally soiled loads. Fresh (boosted with internal heater), fast speed tumbling and Water Rinse, and Energy Saver are available options. -
Page 14: Cycle Settings
OPERATING INSTRUCTIONS Cycle Settings NOTE For best results Follow the fabric care label instructions This setting has been certifi ed by NSF International, on items to be dried. an independent third party testing and certifi cation Appropriate wash temperature, spin speeds, soil level and organization dedicated to public health, safety and options will automatically be displayed for each cycle. -
Page 15: Cycle Options
OPERATING INSTRUCTIONS Cycle Options IMPORTANT • If steam is selected, rinse temperatures will be elevated. • If washer is paused during a steam wash cycle, the door will remain locked due to higher temperature in drum. DO NOT force open - it will unlock upon cooling. -
Page 16: Other Features
OPERATING INSTRUCTIONS Other Features Status Display/Status Lights STATUS DISPLAY The estimated total cycle time will be displayed when the cycle is selected. The time may increase if water The following will also be displayed at the ap- pressure is low, oversudsing occurs or the load becomes propriate times during the cycle: unbalanced. -
Page 17: Washer Settings Chart
WASHER SETTINGS CHART These Temperature, Spin Speeds, Soil Levels and Options are available with the following cycles: Auto Temp Sanitize Warm Cold Cold Water Clean Spin Speed High Medium No Spin Soil Level Heavy Normal Light Extra Light Options Energy Saver Add Steam Pre Wash Delay Start... -
Page 18: Stain Removal Guide
STAIN REMOVAL GUIDE Safe Stain Removal Procedures WARNING To reduce the risk of fi re or serious injury to persons or property, comply with the basic warnings listed below: HARMFUL VAPOR HAZARD • Read and comply with all instructions on stain re- Do not use or mix liquid chlorine bleach with other moval products. -
Page 19: Stain Removal Suggestions
STAIN REMOVAL GUIDE Stain Removal Suggestions STAIN TREATMENT Adhesive tape, chewing Apply ice. Scrape off excess. Place stain face down on paper towels. Saturate with pre- gum, rubber cement wash stain remover or nonfl ammable dry cleaning fl uid. Baby formula, dairy Use product containing enzymes to pretreat or soak stains. -
Page 20: Care And Cleaning
CARE AND CLEANING Inside Routine Cleaning (Preventative) To help prevent odors, mold or mildew, leave the door open for a few hours after use or whenever the washer is not in use. CAUTION ENTRAPMENT and TIP-OVER HAZARD Do not leave the door open if there are small children or pets present. -
Page 21: Daily Preventative Maintenance
CARE AND CLEANING Other Inside Routine Cleaning (Preventative) Cleaning Dispenser Drawer Area NOTE Detergent and fabric softener may build up in the dispenser drawer. Residue should be removed once or twice a month. • Remove the drawer by pulling the drawer out until it stops. - Page 22 CARE AND CLEANING Inside Cleaning (Aggressive) In cases where the Clean Washer cycle along with care and cleaning of rubber gasket folds isn’t done, and severe odor, mold, mildew, or residue buildup have developed, follow the below cleaning procedure to help alleviate the problem.
-
Page 23: Winterizing Instructions
CARE AND CLEANING Outside Routine Cleaning • When washing is completed, wipe top and sides of washer with a damp cloth. Turn water faucets off to prevent pres- sure build-up in the hoses. • Clean the cabinet with mild soap and water. Never use harsh, gritty or abrasive cleansers •... -
Page 24: Common Washing Problems
SOLUTIONS TO COMMON PROBLEMS Common Washing Problems Many washing problems involve poor soil and stain removal, residues of lint and scum, and fabric damage. For satisfactory washing results, follow these suggestions provided by The Soap and Detergent Association. PROBLEM POSSIBLE CAUSES SOLUTIONS PREVENTIVE MEASURES Blue stains... - Page 25 SOLUTIONS TO COMMON PROBLEMS Common Washing Problems, continued PROBLEM POSSIBLE CAUSES SOLUTIONS PREVENTIVE MEASURES Yellow buildup • Agitation time too short. • Soak in detergent booster or product • Select correct wash cycle. of body soil on • Wash water temperature containing enzymes.
-
Page 26: Service Prevention Checklist
SOLUTIONS TO COMMON PROBLEMS Service Prevention Checklist Before calling for service, review this list. It may save both time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this washer. OCCURRENCE POSSIBLE CAUSE SOLUTION NOISE... - Page 27 SOLUTIONS TO COMMON PROBLEMS Service Prevention Checklist, continued OCCURRENCE POSSIBLE CAUSE SOLUTION WATER Water collects in folds of This is a result of the washing action and the bellows at the end of is part of the normal operation of the the cycle.
-
Page 28: Warranty
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Crosley Corporation. In Canada, your appliance is warranted by Crosley Canada Corp. Crosley Corporation authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under this warranty must be performed by Crosley Corporation, Crosley Canada Corp, or an authorized service company. -
Page 29: Notes
NOTES...
