Model M118A07
Ballistic shot shell pressure sensor, 103,420 kPa, 0.04 pC/kPa, M10x1 integral mtg thd
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: 716-684-0987
E-mail: info@pcb.com
Web: www.pcb.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PCB Piezotronics M118A07
Summary of Contents for PCB Piezotronics M118A07
- Page 1 Model M118A07 Ballistic shot shell pressure sensor, 103,420 kPa, 0.04 pC/kPa, M10x1 integral mtg thd Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 716-684-0001 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com...
-
Page 2: Repair And Maintenance
Assistance is needed to safely operate equipment PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T. - Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
- Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
- Page 5 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
-
Page 6: Installation
BALLISTICS PRESSURE TRANSDUCER MODELS 165B02 AND 118A07 OPERATION MANUAL INTRODUCTION INSTALLATION The Model 165B02 & 118A07 are, charge mode When choosing an installation method, the advantages ballistics transducers with welded diaphragm and a and disadvantages of each method must be carefully rugged quartz element of proven reliability ideally suited weighed. - Page 7 BALLISTICS PRESSURE TRANSDUCER MODELS 165B02 AND 118A07 OPERATION MANUAL Before installing the transducer in previously used When using the recess mount technique, note that the mounting ports, clean out the residue remaining from length of the passage may limit the usable frequency previous tests as shown in Figure 3.1 .
-
Page 8: Flush Mount
BALLISTICS PRESSURE TRANSDUCER MODELS 165B02 AND 118A07 OPERATION MANUAL Selected Values for 77°F (25°C) Passage Passage Approx. fastest Flash Thermal Protection length resonance pulse rise time (inches) (kHz) (microseconds) Additional steps may be taken to provide protection from flash thermal effects. The sensor diaphragm may .050 be thermally insulated with DC-4 silicone grease or its .100... -
Page 9: Operation
BALLISTICS PRESSURE TRANSDUCER MODELS 165B02 AND 118A07 OPERATION MANUAL NOTE: Do not attempt to use a charge amplifier that has less than a 5 000 second time constant when in the long position. Several charge amplifiers are specially designed for use with ceramic accelerometers for higher frequency measurements. - Page 10 All specifications are at room temperature unless otherwise specified. 3425 Walden Avenue, Depew, NY 14043 In the interest of constant product improvement, we reserve the right to change specifications without notice. ® is a registered trademark of PCB Piezotronics, Inc.
- Page 11 PCB Piezotronics Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others DESCRIPTION without the written consent of PCB Piezotronics Inc. RELEASED TO DRAFTING 44213 ELECTRICAL CONNECTOR CO-AXIAL 10-32 UNF - 2A...
