PLASMA TELEVISION USER MANUAL D T S - 4 2 Proper use guarantees product life. Before using the product, be advised that you read this user manual well and try to operate it.
Page 2
CAUTION: This symbol is lntended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The symbol is intended to alert the user to the presence of important operating and maintenance(servicing) instructions in the lierature accompanying the appliance.
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a damp cloth. 7. Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions.
Page 4
CCF Technology makes the picture clearer by controlling of the brightness among three different color filters. • MGDI (Meta Genuine Digital Image) Engine MGDI is the image enhancement technology of Daewoo Electronics, which provides more clear, splendid, and delicated images. This User Manual presents safety precautions and how to use the product.
Page 5
F C C R F I N T E R F E R E N C E S T T E M E N T F C C R F I N T E R F E R E N C E S T T E M E N T NOTE : This equipment has been tested and found to comply with the limits for a...
Safety Precautions Always obey all During a lightning storm, or when it is left unattended and unused for a long period safety messages. of time, unplug it from the wall outlet. It can result in fire. • All the safety and operating instructions should be read before the...
Page 7
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. Spilled liquids may cause electric shock or fire. Do not disassemble batteries, and do not leave around in case children swallow them.
Page 8
Safety Precautions Always obey all When moving your TV, remove the power plug, antenna, and cables, and be sure to safety messages. move it by using two people.. Failure to follow this instruction can result in • All the safety and electric shock or personal injury.
Page 9
The plasma television panel consists of fine cells. Although the panels are produced with more than 99.9 percent active cells, there may be some cells that do not produce light or remain lit. Do not allow a still picture to be displayed for an extended period, as this can cause a permanent ghost image to remain on the Wide Plasma...
Checking Accessories Supplied Accessories Remote Control Component Cable A/V Cable Note Check to be sure that the following items are packed with your Plasma panel. Ferrite Core 1 UNIT Place the small ferrite cores in the speaker cables close to the speaker terminals of 1UNIT the PDP unit.
Wall Mounting Unit Note The following items are optional accessories. Refer purchasing optional accessories from Daewoo Electronics Local retailer or the retailer from where you purchased the unit. DTS-42SP - Speaker Main Unit Dimension : 100(W) x 628(H) x 83(D) mm 39.37(W) x 24.72(H) x 3.27(D) inch...
Front Panel, Back Panel, Remote Control Items having same names on Plasma television and the remote control would function in exactly the same way. Front Rear DVI-D INPUT DVI-D PC INPUT(15 pin INPUT D-sub) Panel Controls ON/OFF STAND BY/OPERATE • Power control sensor •...
Remote Control The number in ( ) indicates the page in which the function of each button is explained in detail. TV/VIDEO(DVD)/SAT/CATV Channel number (0~9) Use to select channel directly 0~9 Display button Indicates the current state and resolution. TV/VIDEO Use this function to make video input selection.
• As the device is turned off, press the flickering device selection button of the remote control once. Then the lamp of the button will be turned off. • Now, the setting-up of the device can be controlled by Daewoo PDP remote control. VCR (STANDARD : 004)
Indoor Antenna Connection 1. Connect the feeder cable of the antenna to the combining adapter. WHEN THE IMAGE IS NOT CLEAR Unclear screen image and bad reception may be a cause of wrong antenna connection. Be sure to check its direction and place when installing. 2.
Page 18
CTV Antenna Connection TV Antenna installation may be found in most. When a coaxial cable is used Plug the coaxial cable to the antenna socket, and fix it firmly. It is recommended to use the provided coaxial cable. When a feeder cable is used Provided coaxial cable ANT/CABLE 1 ANT/CABLE 1...
To Watch TV - The buttons on the keypad in the PDP unit, which have the same name as those on the remote controller, perform the same function as the remote controller. Press the “ON/OFF” button of the PDP unit. •Power button of the remote control and the keypad on the PDP unit would be operated only when the "AC Power"...
Press the “ON/OFF” button. • Press the “ON/OFF” button of the PDP set. ON/OFF • The main power lamp turns on in red color. • Press the "POWER" button of the remote control or any button POWER in the keypad of the main body. •...
Automatic Channel Memory - This is the function for the TV to memorize the broadcasting channels. If the Auto Setup is done, you can simply find out channels with “ CH ” buttons and so need not to select channels by pressing each channel number. Press the “Menu”...
Page 23
Select the [Auto Search]. • Select the “Auto Search” with the “ CH ” button. MENU Press the “VOL ” button. Auto Search is completed. • If auto search is completed, first momorized channel appears on the screen. Check by pressing the “ CH ” button. Picture Sound Screen...
Additional Channel Memory Additional Channel Memory • This is method for additionally memorizing channels not memorized due to weak broadcasting signal. • This function is available even in the [Menu] - [Channel] - [ADD/ERASE]. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION...
Page 25
Select the Channel to erase. • Select the Channel to erase with the “ CH ” button. • You may select the Channel by pressing the number button. MENU Ex) “13” channel Press the “ADD/ERASE” button. • After selecting the channel to want to ADD/ ERASE •...
Fine Tune - If you are unable to get a good picture or sound because of a poor signal reception, it is possible to adjust it with the Fine Tune feature.. Select the [Channel] with the “Menu” button and the “ VOL ” button. •...
Page 27
Select “Air/Cable” in [Ch Mode]. • This function is used for selecting “Air TV” and “Cable TV” • The screen is changed to “Air MENU TV” and “Cable TV” whenever pressing the “ VOL ” button. Select Fine Tune Note: Fine Tune •...
Watching Digital Broadcasts Watching Digital Broadcasts • To watch digital broadcasts: - Purchase a separate digital Broadcasting Receiver(SET-TOP BOX) - Connect the PDP to a Digital Broadcasting Receiver as shown right. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW...
Input Select • Select [Component 1 or Component 2] by MULTIMEDIA pressing the “Multimedia” button of the Remote Control or the "INPUT SELECT" Key in KeyPad of the pdp set. • Each time you press the “Multimedia” button, different input modes appear. The sequence is as follows: Select a Desired Channel and Function NOTES:...
Watching Cable Broadcasts Watching Cable Broadcasts • To watch cable broadcasts, subscribe to your local Cable TV Broadcasting, and then connect a cable Broadcasting Receiver TV to the PDP as shown right. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY...
Page 31
Input Select • Select [Video 1 or Video 2] by pressing TV/VIDEO the TV/VIDEO button of the Remote Control or the "INPUT SELECT" Key in KeyPad of the pdp set. • Each time you press the “TV/VIDEO” button, different input modes appear. The sequence is as follows: Select a Desired Channel and Function NOTES:...
Watching Satellite Broadcasts Watching Satellite Broadcasts • To watch satellite broadcasting, subscribe to Digital Satellite Broadcasting, then connect satellite Broadcasting Receiver to the PDP as shown right. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE...
Page 33
Input Select • Select [Video 1 or Video 2] by pressing TV/VIDEO the TV/VIDEO button of the Remote Control or the "INPUT SELECT" Key in KeyPad of the pdp set. • Each time you press “TV/VIDEO” button, a different input mode appears. The sequence is as follows: Select a Desired Channel and Function Video1...
Watching a DVD Image Watching a DVD Image • Component Input is set to 480i and 480p mode. • Connect the cable from the DVD Video Output (Y, Pb/Cb, Pr/Cr) to the Component Input at the back of PDP, and connect the cable from DVD Audio output (Left, Right)
Page 35
Input Select • Select [Component 1 or Component 2, MULTIMEDIA Video1, Video2] by pressing the “MULTIMEDIA” or “TV/VIDEO” button of the Remote Control or the "INPUT TV/VIDEO SELECT" Key in KeyPad of the PDP set. • Each time you press the “MULTIMEDIA” or “TV/VIDEO”...
Watching a VCR Image Watching a VCR Image • Video can use either the video terminal or the S-video terminal. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE MODE STILL ADD/...
Page 37
Input Select • Select [Video 1 or Video 2] by pressing TV/VIDEO the “TV/VIDEO” button of Remote Control or the "INPUT SELECT" Key in KeyPad of the pdp set. • Each time you press the “TV/VIDEO” button, a different input mode appears. The sequence is as follows: Video1 Select a Desired Title and Function...
Watching a Camcorder/Game Console Image Watching a Camcorder/Game Console Image • Enjoy images recorded by camcorder or the game console after connecting to the PDP. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE...
Page 39
Input Select • Select [Video 1 or Video 2] by pressing TV/VIDEO the “TV/VIDEO” button of the Remote Control or the "INPUT SELECT" Key in KeyPad of the pdp set. • Each time you press the “TV/VIDEO” button, a different input mode appears. The sequence is as follows: Video1 Select Function...
Connecting PC(15pin D-sub) Connecting PC • This product supports resolution of VGA, SVGA, XGA, and SXGA. • Before connecting a PC to the PDP, be sure to adjust the resolution of POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW...
Page 41
Press the Power Buttons. • Turn on the PDP and the PC. Input Select MULTIMEDIA Enjoy Dynamic Ultra Screen TV by Using PC’s Keyboard or Mouse. NOTES: 1) The resolution of the PC TV is best at 640 x 480 (VGA). 2) If there is a [Vertical Frequency]setting menu in the [Display] Menu of the PC, adjust the frequency to 60Hz.
Connecting PC(DVI) Connecting PC • This product supports resolution of VGA, SVGA, XGA, SXGA. • Before connecting a PC to the PDP, be sure to adjust the resolution of PC. • This product is supported by Plug and Play only at DVI. POWER VIDEO/ CATV...
Page 43
Press the Power Buttons. • Turn on the PDP and the PC. Input Select MULTIMEDIA Enjoy Dynamic Ultra Screen TV by Using PC’s Keyboard or Mouse. NOTES: 1) The resolution of the PC monitor is best at 640 x 480 (VGA). 2) If there is a [Vertical Frequency]setting menu in the [Display] Menu of the PC, adjust the frequency to 60Hz.
Page 44
PC and DVI Input Resolution Available in PDP • Depending on graphic card, problems like no signal detected or line noises can happen. If these problems happen, contact the graphic card company for help. Resolution H Freq. (KHz) 640x400 640x480 720x400 800x600 1024x768...
Selecting Picture Mode • Press the [PICTURE MODE] on the PICTURE Remote Control. MODE • While pressing the [PICTURE MODE] for the first time, the current PICTURE MODE will be displayed. Each Press of the Button Will Select One of Four Picture Modes. PICTURE MODE Normal...
Customizing Picture Customizing Picture • You can adjust the color tone and brightness to your preference. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE MODE STILL ADD/ ERASE SLEEP Press the MENU Button.
Page 47
Select User Mode Adjustments • While you are in [Picture Mode – User], press the “ buttons to select a specific adjustment item. MENU Picture Condition Adjustments MENU NOTES: 1) While you are in the PC or DVI INPUT mode, you can only adjust brightness, contrast, sharpness and color temperature.
Adjusting Screen Size Adjusting Screen Size • You can adjust screen size or aspect ratio as desired. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE MODE STILL ADD/ ERASE SLEEP Press the “SCREEN SIZE”...
Page 49
Press the MENU Button. • Press the [MENU] button on the Remote Control. MENU Select [Screen]. • Press the Channel “ [Screen]. MENU Select the [Screen Size]. • Enter the sub menu by pressing “ VOL ” button. • Press the Volume “ VOL ” buttons to select [Screen Size]. MENU Mode Normal...
Adjusting Screen Size(PC, DVI) Adjusting Screen Position and Size • You can adjust the screen position and size as desired. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE MODE STILL ADD/...
Page 51
Press the Volume “ VOL ” button. • Press the Volume “ VOL ” button to enter the sub menu of [Screen]. • While you are in [Screen] mode, press the “ CH button to select a desired item, and then, adjust the MENU value by pressing the “...
Enlarging Screen Size Enlarging Screen Size • You can view enlarged size of the screen with this function POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE MODE STILL ADD/ ERASE SLEEP Press the “ZOOM+”...
Page 53
Move the Screen Position. • While you are in the ‘Zoom’ mode, press the “ CH “ VOL ” buttons to move screen stepwise up/down and left/right, respectively. MENU NOTES: 1) When the screen is enlarged, the pixel of the screen can become thick and dim.
Watching a STILL Image Watching a Still Image • You can view still images with this function. However, displaying the same images such as still images for a long time may cause image sticking. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION...
Select "SOUND MODE". • Press the "SOUND MODE" on the SOUND Remote Control. MODE • Current sound mode will be displayed. Every Press of the Button Changes Modes. SOUND MODE Normal Movie * Normal : Suitable for watching any motion picture * Movie : Select this mode to simulate being at a movie theater * Music...
Customizing Sound Mode Customizing Sound Mode • This feature allows the user to adjust at his preference. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE MODE STILL ADD/ ERASE SLEEP Press the MENU Button.
Page 57
Select the Effect Mode. • Select [Effect] by pressing the “ CH ” buttons, then select ON/OFF by pressing the “ VOL ” button. • [Effect]: Used to emphasize stereo effect. MENU Select the Sound Mode. • Select the Sound Mode by pressing the “ CH then adjust it by pressing the “...
Selecting INPUT SIGNAL INPUT SIGNAL • Used to select INPUT signal of external device connected to the PDP. Press the INPUT SELECT Button. • Press the “TV/VIDEO” and “MULTIMEDIA” button on the TV/VIDEO Remote Control or the PDP Display to select desired input signal.
Page 59
• “TV/VIDEO” button Video1 • “MULTIMEDIA” button Component1 NOTES: 1) If an external device is not connected or INPUT signal is not applied, Warning Message (“No Signal”) would be displayed. 2) In this case, check if external device is connected and/or terminal connection is properly done.
Indicates the mode and frequency of the current INPUT signal. NOTES: 1) DAEWOO PLASMA can receive NTSC, PAL, SECAM, etc. 2) “1920 x 1080” displayed in the INPUT signal is not the resolution of the TV. The displayed resolution is sent by Digital Broadcastion Receiver.
Page 61
MENU Background, Language and Key pad Lock Settings Press the MENU Button. • The MENU screen will be displayed as below. MENU Press the “ CH ” Button. • Select [Features] by Pressing the MENU Select the menu Background. • Select the MENU [Background] by pressing the “ VOL ” button.
Page 62
MENU Background, Language and Key pad Lock Settings POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE MODE STILL ADD/ ERASE SLEEP Select LANGUAGE by using the “ CH ” Button. •...
MGDI (Meta Genuine Digital Image) MGDI is the image enhancement technology of Daewoo Electronics, which provides more clear, Press the MENU Button. • The MENU screen will be displayed as below. MENU Select Features • Select [Features] by the “...
Auto Power Setting POWER/STANDBY Indicator Front panel LED lights • When the AC power is on : Green. • When the AC power is in the standby mode : Red. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.F/SLOW F.R/SLOW PLAY STOP...
Closed Caption Setting • Press the “CAPTION” button on the Remote Control. • Whenever pressing the “CAPTION” button, caption mode is changed as follow. CAPTION Text4 Closed Caption Setting in the Menu. • Press the Menu Button. • The MENU screen will be displayed as below.
Page 66
Closed Caption Setting Caption Box Setting • Black : Background of the caption box is black. • Transparent : Background of the caption box is Transparent. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU CAPTION MUTE F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND...
Press the MENU Button. • The MENU screen will be displayed as below. MENU Select Features MENU Select Time Setting • Enter the sub menu by using the “ VOL ” button. • Select the [Time setting] by pressing the “ •...
Page 68
Time Setting Clock(current time) Setting • The “Current time” must be set up ahead of setting up other time memories. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE MODE STILL ADD/...
Press the MENU Button. • The MENU screen will be displayed as below. MENU Press the “ CH ” Button. • Select [Features] by pressing the “ MENU Select ISM. • Enter the sub menu by using the “ VOL ” button. •...
Image Sticking Minimization(ISM) POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE MODE STILL ADD/ ERASE SLEEP Select Functions. • Every press of the by the “ ON/OFF. MENU NOTES: Pixel Shift : The whole screen shifts up/down, Low Bright : When displaying a still picture or a...
Press the MENU Button. • The MENU screen will be displayed as below. MENU Select Features • Select [Features] by pressing the “ MENU Select the Parental Lock • Enter the sub menu by using the • Select the [Parental Lock] by pressing the “ button.
Page 72
Parental Lock Setting New Password setting New Password setting menu is displayed at first use. Set New Password for using Parental Lock menu. POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE...
Page 73
• Rating of movie is setup even in movie, videotape and other media objects MENU including TV program. • The “ CH ” and “ VOL ”button select items and the “ ” button sets MENU up or cancels each item.
Page 74
Parental Lock Setting POWER VIDEO/ CATV DISPLAY TV/VIDEO MULTIMEDIA MENU MUTE CAPTION F.R/SLOW PLAY F.F/SLOW STOP PAUSE PREV OPEN/CLOSE NEXT PICTURE SOUND MODE MODE STILL ADD/ ERASE SLEEP “Change Password”. • In the initial purchase of TV set, password is set to blank.
Press the MENU Button. • The MENU screen will be displayed as below. MENU Select Features • Select [Features] by the “ MENU Initialize Setting Mode Normal Brightness Picture Contrast Sound Color Tint Screen Sharpness Color Temp. Normal Features Channel Move Select Exit...
Page 76
Initialize Setting INITIALIZATION • Enter the sub menu by using the “ VOL ” button. • Select the [Initialize] by pressing the “ button, then press the “ VOL ” button. • A confirmation message will be displayed. MENU • To perform initialization, press the “VOL ” button after selecting [YES] by pressing the “...
Press the “SLEEP” Button. • Press the “SLEEP” button on the Remote Control. • Pressing the “SLEEP” button first time will display the SLEEP current setting for SLEEP TIMER. • To cancel the SLEEP TIMER, press the “SLEEP” button to select ‘OFF’. Sleep Sleep Sleep...
Before Requesting Service Before requesting for service, check the following points once again. • Remote control does not function properly. • Check for any obstacle between the Remote Control and the Display. • Check for dead batteries and incorrect battery orientation. •...
Immediately wash it with clean water, and dry it in a shadow place, then call for service from the nearest Daewoo Service Center. Never plug the Power Cord since there is risk of electric shock and SPECIFICATIONS damage of the product.
