  • Page 1 USER MANUAL HDTV Monitor DSC-34W70N...
  • Page 2 RISK OF ELECTRIC SHOCK CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...

  • Page 3: Important Safeguards

    IMPORTANT SAFEGUARDS PLEASE READ ALL THESE INSTRUCTIONS REGARDING YOUR TELEVISION EQUIP- MENT AND RETAIN FOR FUTURE REFERENCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE TV RECEIVER. 1 Read all of these instructions. 2 Save these instructions for later use. 3 Unplug this television equipment from the wall outlet before cleaning.
  • Page 4 13 An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

  • Page 5: Table Of Contents

    CONTENTS PREPARATION •CONNECTING ANTENNA..............6 •NAME OF EACH PART .

  • Page 6: Connecting Antenna

    NOTE: Bad picture reception could often be caused by bad antenna connection. Be sure to check the antenna direction, its height, etc. In case of using single antenna cable VHF Antenna LTo Receive Cable Programs Plug CATV coaxial cable in the antenna socket (unit) at the back of the TV set, and then, press Antenna...

  • Page 7: Name Of Each Part

    NAME OF EACH Front and Side of TV set •The buttons installed on the front of the TV set is functioning as same as those on the Remote Control. 1. Timer Indicator Lights up red when you have set the HDTV Monitor’s automatic timers. 2.

  • Page 8: Side Panel Inputs

    Side panel inputs On the right side panel of the HDTV Monitor, you will find the Video 3 inputs and Headphone jack. These are provided to connect a camcorder or other video equipment without reaching around to the rear panel. HEADPHONE : provides a connection for headphones.

  • Page 9: Remote Control Buttons

    REMOTE CONTROL Remote Control • ( )Number in the blank serves as an address; it shows the page number containing a detailed information on the functions of each button. TV/VIDEO (Conversion button) (Conversion button) Direct Channel Selection Board Pressing the numbers on this board, you can select program channels of the screen directly.
  • Page 10 Under the Cover of Remote Control To use the buttons under the cover PIP SEARCH 18~26 Simultaneous window selection is possible through the buttons of this board, and various layouts of the windows can be selected according to the user’s need or desire. TV/CATV This button is used to convert reception modes between aerial and cable...

  • Page 11: To Watch Tv Program

    TO WATCH TV To Watch TV Program Buttons on the front of the TV set have the same functions as those of the REMOTE CONTROL. BPress two number buttons of the Remote Control to select a channel directly. The numbers should be in digits.
  • Page 12 1.Press the “TV POWER”button. •The TV screen will illuminate, and the power Mono indicator lamp will light up green. 2.Press the “CHANNEL” buttons. •Press the “CHANNELx/y” or number buttons to Mono select the channel you want. Ex) Ch 7 3.Adjust the Volume. •When the volume decreases.
  • Page 13 Automatic Memory of Channel LActual broadcasting channels can be set up in the “Memory” of the TV set through this function. With an automatic channel setup memory, desired channels can be selected easily with “CHANNELx/y” buttons. Such inconvenience as pressing channel numbers one by one is not necessary.
  • Page 14 4.Press “VOLUMEC/B” buttons. Automatic Channel Memory function (Auto Program) starts. •Checking from channel 2 to channel 69,(Cable1~125) Auto Program this function automatically memorizes only those Auto channels which are actually broadcasting. Programming •When “MENU” button is pressed during the setup Air 13 process, the setup operation quits.

  • Page 15: Select A Channel

    Add or Remove Channel from Memory LThis function is another way to include a channel when cannot be a channel memorized due to a low broadcasting signal. 1.Select a channel. •Select a channel by pressing number buttons. Mono Ex) Ch 13 2.Choose to add or erase from memory.

  • Page 16: Adjusting Screen Size

    1.Press “TV/CATV” button. When pressed once •The reception mode shifts from “AIR” to “CABLE”. Cable 12 Cable 12 When pressed twice 2.Select a channel. •Select a channel by pressing either number buttons 0 - 9 or 100. •When the channel number is bigger than 100, use the following example: Ex) If the number is 125, press number buttons: Press “WIDE”...
  • Page 17 Watching Video Programs 1.Connect the video cable to the VIDEO socket at the back or the side of TV set, and press “TV/VIDEO” button on the remote control. •The screen changes to video mode as follows: Video1 •Whenever this button is pressed, the screen shifts in sequence : TV Video3 2.When this button is pressed, the screen changes to “DTV”...

  • Page 18: Adjusting Two Program Windows

    1.Press “PIP” button once. •Single PIP appears on the screen. Mono 2.Press “PIP” button once more. •The operating program window becomes the main Mono window and moves to the left side of the screen; an auxiliary window appears on the right side at the same time.

  • Page 19: Various Functions Of Simultaneous Window Mode

    VARIOUS FUNCTIONS Various Functions of Simultaneous Window Mode LSelect and enjoy programs you want to watch by using various functions of Simultaneous Window mode. OF SIMULTANEOUS WINDOW MODE 1.Press “MENU” button. •Then the screen appears as follows: Picture Move Sel. Exit 2.Select “Funtion”...
  • Page 20 4.Press “VOLUMEC/B” buttons, and select the window mode you want. •When the “VOLUMEC/B” buttons are pressed, the screen shifts in the following order: Single PIP Picture Twin picture Single PIP Picture Mono Multi-Picture(4) Mono •The MENU mode disappears in 15 seconds automatically when there is no “MENU” button operation, and you can enjoy the selected Simultaneous Window programs.
  • Page 21 Selecting Simultaneous Windows LYou can enjoy two window programs at the same time. Along with the main window program, you can have another TV channel program or a Video program simultaneously. In addition, you can have the sound of the auxiliary window program through headphones.
  • Page 22 4.Press “PIP” button again. •PIP mode changes to twin windows. Mono Mono 5.Press “PIP” button again, and the auxiliary window disappears. •Whenever the “PIP” button is pressed, the screen Mono mode changes cyclically as follows: Mono Mono...
  • Page 23 Searching Functions of Memorized Channels through 4 Windows Mode LMemorized channels could be checked easily by selecting 4 windows mode. 1.Press “SEARCH” button. •Four windows appear on the screen. Memorized channels are connected one-by- one to each window in sequence; thus it is easy to check the contents of the programs on air .
  • Page 24 1.Press “POSITION” button. •Display auxiliary windows on the screen by pressing “PIP” buttons. •Press “POSITION” button. Every time it is pressed, the locations of auxiliary windows change as follows: •The search sign “B” in 4 Windows mode shifts its location as follows: Mono •In Twin Windows mode, the “POSITION”...
  • Page 25 Window Mode SWAP Press “SWAP” button. •View the auxiliary window by pressing “PIP” button. •Press “SWAP” button. Every time it is pressed, the mode of the main and that of the auxiliary windows will swap locations as follows: Mono This function also operates in Twin Windows mode. •When the system is in Twin Windows mode 1 (4 : 3), the Twin Windows will appear as follows: Mono...
  • Page 26 Changing Window Modes is also Possible in Multi-Windows Search. •The window with “B” sign not only becomes the new main window, but also the auxiliary window. Mono Mono Making Pause Auxiliary Windows. •This function makes the auxiliary window programs pause temporarily. •When “STILL”...

  • Page 27: Adjusting Volume Of An Auxiliary Window

    ADJUSTING VOLUME Adjustable Headphone Volume Levels LSound of either the main window or an auxiliary window is available through headphones. LVolume control of an auxiliary window is possible only with headphones. LSound of an auxiliary window program is available only through headphones.

  • Page 28: Open Function Menu

    1. Press “MENU” button. •The screen appears as shown: Picture Move Sel. Exit 2. Select “Sound” menu by using “VOLUMEC C /B B ” buttons. •Move the cursor to the “Sound” menu by using “VOLUMEC/B” buttons. •Press “Channelx” button. Sound Move Sel.

  • Page 29: Adjusting The Picture

    ADJUSTING Adjusting Picture Quality LUsers do not need to handle many operation units in adjusting the picture on the screen. Just make one of the selections already built in by the company’s experts. THE PICTURE 1. Press “AUTO PICTURE” button. •The following pictures appear on the screen in sequence, and the picture adjustment state is changed.

  • Page 30: Picture Noise Reduction

    1. Press “MENU” button. •The screen appears as follows : Picture Move Sel. Exit 2. Select “Picture” by using “CHANNELx x ” button. •Move the cursor to the “Picture” menu by using Picture “CHANNEL x” button. Brightness Contrast Sharpness Color Tint 32:32 Picture NR...
  • Page 31 Adjusting the Picture Screen to Your Preference LAccording to the user’s preference, brightness, contrast, sharpness, color, and tint can be adjusted for each of Video1, Video 2, Video3, DVD, and TV mode. Brightness: •Adjusts the degree of brightness or darkness of the whole screen. Contrast: •Adjusts (controls) the degree of brightness between the objects and...
  • Page 32 3. Adjust “Tint” by using “VOLUMEC C /B B ” buttons. •Press “VOLUMEC” button, and the green tint Picture Brightness increases. Contrast •Press “VOLUMEB” button, and the red tint Sharpness Color increases. Tint 32:32 Picture NR Move Adj. Prev. •To adjust other functions such as brightness, etc., select the function you want by using “CHANNELx/y”...

  • Page 33: Customizing The Audio

    ADJUSTING THE Customizing the Audio “Balance” LThis function balances the volume between left and right speakers. L“Balance” adjusting screen appears as follows: Sound Mode Mono Balance 32:32 Headphone Vol Center Vol Equalizer Move Adj. Prev. L“VOLUME UPB” keeps the volume of the right speaker as it is, but decreases the volume of the left one.
  • Page 34 4. Select Range of Sound by using “VOLUMEC C /B B ” buttons. •“CHANNELx” strengthens the selected range of Equalizer sound. •“CHANNELy” weakens the range of sound. •Signal bar (-) moves up and down showing the selected sound range. Adj. Move Prev.
  • Page 35 Receiving Stereo or SAP Mode Programs LWhen transmission signal is low or broadcasting condition is not good, sound might be cut off temporarily. This type of malfunctioning is not caused by the TV set. In this case, press “MTS” button, and shift the mode into “Mono”...

  • Page 36: Automatic Power On/Off

    1. Press “MENU” button. •The screen appears as shown : Picture Move Sel. Exit 2. Select “Function” by using “VOLUMEC C /B B ” buttons. •Move the cursor to the “Function” menu by using “VOLUMEC/B” buttons. •Press “CHANNELx” button. Function Move Sel.
  • Page 37 4. Set up the Curent Time. •Press “VOLUMEC/B” buttons, and the screen Timer Clock AM 1:00 appears as shown in the left figure: On Time •Press “CHANNELx/y” buttons, and the letters - - : - - Off Time “AM 1:00” will turn in blue. - - : - - •Set up the present time by using “VOLUMEC/B”...
  • Page 38 1. Press “MENU” button. •Then, the screen will appear as follows : Picture Move Sel. Exit 2. Select “Function” by using “VOLUMEC C /B B ” buttons. •Move the cursor to the “Function” menu by using “VOLUMEC/B” buttons. •Press “CHANNELx” button. Function Move Sel.
  • Page 39 4. Select “On Time” to turn the TV set “On”. •Press “CHANNELx/y” buttons, and the screen Timer appears as follows: Clock AM 1:00 On Time - - : - - Off Time - - : - - Move Adj. Prev. •Press “VOLUMEC/B”...
  • Page 40 7. Set up the “Off Timer”. •Press “CHANNELx/y” buttons, and the letters “AM Timer Timer Clock AM 1:00 - - : - -” will turn blue. On Time •Set up “Off Timer” by using “VOLUMEC/B” buttons. AM 11:00 Off Time •Keep pressing the “VOLUMEC/B”...

  • Page 41: Special Functions

    SPECIAL FUNCTIONS Selecting the On-Screen Language LThe language of the program on the screen can be changed to one of the following On-Screen languages : English, French, and Spanish. 1.Press “MENU” button. •The main menu will appear as shown in this example: Picture Move...
  • Page 42 4.Select the language using “VOLUMEC C /B B ” buttons. •Press this button, and the On-Screen language changes in the following order : English Francais Español Function Timer Caption Language English Child Lock Move Adj. Prev. Funciones Cronómetro Subtítulo CC Idioma Español Bloq.

  • Page 43: Fine Tuning Channels

    Fine Tuning Channels 1.Press “MENU” button. •The main menu will appear. Picture Move Sel. Exit 2.Select “Set Up”. •Move the cursor to the “Set Up” menu using “VOLUMEC/B” buttons. •Press “CHANNELx” button to select set up, and Set Up the sub menu will appear. Move Sel.
  • Page 44 4.Select “Fine” to fine tune. •Highlight “Fine”. •Press “VOLUMEC/B” buttons to fine the channel. •Keep pressing “VOLUMEC/B” buttons until the channel is as clear as possible. Ch Edit •To fine tune another channel, first, select the Channel Air 11 Add/Erase channel, then repeat the steps above.
  • Page 45 Setting up “Caption” Function L “Caption” is a display of words that can substitute for the audio of the TV. This function provides a narration plus a written version of dialogue and sound effects. “Text” is not usually related to the action on- screen, often providing information such as news or weather.
  • Page 46 4.Select an appropriate mode. •Press “VOLUME B” button, and the mode will Function change in the following order: Timer Caption Language English Child Lock Move Adj. Prev. 5.Press “MENU” button twice. •Press this button once, and the menu window will appear. •Press it again, and you will get the previous status of the menu window.
  • Page 47 Setting up “Child Lock” Function LUsers can lock channels by entering with a 4-digit password. LWhen “Child Lock” is set up, the channels locked are not available on the screen. 1.Press “MENU” button. •The main menu will appear. Picture Move Sel.

  • Page 48: Enter Your Password

    4.Enter your password. •Use the number buttons(0-9) to enter your Parental Control password. Note, if this is the your time using the “Parental Control” menu, be certain to remember it, Enter The Password after entering your password, or keep a written #### copy stored as you would with any confidential info.
  • Page 49 •The “No Rating” item toggles between “Unblock” and “Block”. This item determines whether or not to block the programs which are not rated by “Movie Ratings” and “TV Guidelines”. Use “VOLC/B” buttons to change the settings. Parental Control Parental Lock : On TV Guidelines Movie Ratings No Ratings :...

  • Page 50: Pro Logic Settings

    When you enable the noise sequencer, it will continue in all channels until you disable it. For the best surround quality, DAEWOO recommends that you adjust the sound equally among between all speakers. For example, the volume of the front speakers should match the volume of the rear speakers.
  • Page 51 Tilt Picture 1. Press “MENU” button. • The main menu will appear. Picture Move Sel. Exit 2. Select “Special”. • Move the cursor to the “Special” menu using “VOLUMEC/B” buttons. • Press “CHANNELx” button. Special Move Sel. Exit 3. Select “Tilt” •...
  • Page 52 1.Press “MENU” button. •The main menu will appear. Picture Move Sel. Exit 2.Select “Special”. •Move the cursor to the “Special” menu using “VOLUMEC/B” buttons. •Press “CHANNELV” button to select “Special”, Special and the sub menu will appear. Move Sel. Exit 3.Select “DTV”.

  • Page 53: Rear Panel Connections

    CONNECTING Audio Set Rear Panel Connections VIDEO INPUT 1 VIDEO INPUT S-VIDEO MONITOR SURROUND OUTPUT OUTPUT VIDEO VIDEO AUDIO AUDIO ANTENNA VIDEO AUDIO VIDEO AUDIO DTV INPUT DVD INPUT EQUIPMENTS HD Component VIDEO INPUT 1 VIDEO INPUT S-VIDEO MONITOR OUTPUT VIDEO VIDEO AUDIO...
  • Page 54 To connect a digital video disc (DVD), follow the diagram below. VIDEO INPUT 1 VIDEO INPUT S-VIDEO VIDEO AUDIO ANTENNA VIDEO AUDIO DTV INPUT HD component To connect a HD component, follow the diagram below. HD Component Output MONITOR SURROUND OUTPUT OUTPUT VIDEO...
  • Page 55 Camcorder The Video3 inputs on the side of the HDTV Monitor make it easier to connect a camcorder. To do this, follow the diagram below. Speakers To connect standard speakers with amplifier, follow the diagram below. VIDEO INPUT 1 S-VIDEO VIDEO AUDIO ANTENNA...

  • Page 56: Programming The Remote Control

    The HDTV Monitor is remote control is pre-programmed to operate your HDTV Monitor. However, you can also program the HDTV Monitor’s remote control to operate other components, such as Cable TV BOX, or VCR. 1. Confirm that the external component is plugged in and turned off. 2.

  • Page 57: Component Codes

    COMPONENT Cable TV Box Brand Code ANTRONIX ARCHER CABLE STAR CENTURION CENTURY CITIZEN COLOR VOICE COMBANO COMTRONICS DIAMOND EAGLE EASTERN ELECTRICORD GEMINI GOLDEN CHANNEL HAMLIN HITACHI HOSPITALITY JERROLD M-NET MACOM MAGNAVOX MEMOREX MOVIE TIME PANASONIC PARAGON PHILIPS PIONEER CODES 004 006 007 041 POST NEWS WEEK 044 048 055 PRUCER...
  • Page 58 CALIFORNIA AUDIO 123 CANON 027 030 032 CAPEHART CRAIG 005 038 108 CURTIS MATHES 030 032 155 159 DAEWOO 001 007 009 012 060 061 086 088 090 094 095 096 DAYTRON 013 023 037 040 DENON 124 141 144...

  • Page 59: Troubleshooting

    TROUBLESHOOTING Neither picture nor sound: Picture is OK, but no sound: •Is power code plugged in? •Check if “Volume Down” is •Check if the “Volume Control” •Adjust the volume with •Press power button on the front of •If the red power light is on, press the remote control power button.

  • Page 60: Specifications

    General BROADCASTING HDTV Ready NTSC System Sound System Dolby Pro Logic, R(8W)/L(8W)/Center(5W) Screen Size 34”(diagonal), 16:9 Aspect ratio Display Format DTV : 1080i @ 33.75KHz NTSC/DVD :480p @ 31.5KHz Power Source AC 120V 60Hz Power Consumption 210watts Dimension 41”W x 26.2”H x 24.6”D (1042x666x625mm) Weight 178.6lbs(81Kg) Inputs/Outputs...
  • Page 61 P/N:48586120E105-R1...
