- Page 1 USER MANUAL HYPERMOL Full Spectrum 1000W 1-877-540-5588 IL-HMOL-1000 iluminarlighting.com sales@iluminarlighting.com...
- Page 2 Please read this manual thoroughly prior to installing or operating the ILUMINAR HYPERMOL • Observe all safety precautions (see page 10), seek the services of a qualified electrician, installation professional, or call ILUMINAR Lighting technicians for assistance. • DO NOT handle or touch the fixture while in use.
- Page 3 MODEL VOLTAGE WATTS IL-HMOL-1000 100-277V 1000W IL-HMOL-1000 1000W LED SPECTRUM TECHNICAL SPECS MOUNTING & COVERAGE Rated Voltage 120-277V AC 2660 μmol/s Efficacy 2.71 μmol/J Min Power Factor >90% < 20% 3,400 Dimmable 0-10V Controllable Ambient Temperature 0 - 35°C / 32 - 95°F Minimum Mounting Height 6”...
- Page 4 HARDWARE ACCESSORIES The HYPERMOL can be hung from rope ratchets or can be mounted to a rack. Before you begin installation, check that you have all the necessary parts to begin. IN THE 1 Controller Cable 1 HYPERMOL Fixture 1 Cable...
-
Page 6: Hanging Installation
The ratchets should be installed closest to the LED (and not the ceiling). A: Remove slack to raise fixture. B: Give slack to lower fixture. © Copyright 2024, ILUMINAR Lighting Subject to change without notice. - Page 7 Controller Cable AC INPUT Power Supply CAUTION when handling your ILUMINAR Fixture. The LED array should NOT come in contact with sharp objects. DO NOT touch diodes or apply direct force to the diodes as this can/will cause permanent damage.
- Page 8 CABLE LOGIC CONNECTIONS With our ILUMINAR Lighting Professional Systems, our new LED lighting fixtures allow growers to connect multiple fixtures using a single power cable. This cabling solution forms a fixture-to-fixture connection to the power source. Our grow light cables and grow light accessories eliminate the need for the typical mess of LED lighting cables, which have various fixtures with multiple cables running to several power sockets.
- Page 10 Do NOT use sulfur vaporizers. GUARANTEE At ILUMINAR, we stand behind our products and our technology as well as our customers. All ILUMINAR LED fixtures are backed by our 5-Year Guarantee. Please visit our website iluminarlighting.com/warranty for more information.
