Summary of Contents for Goodix GR5515
- Page 1 GR5515 Starter Kit User Guide Version: 2.0 Release Date: 2024-09-09 Shenzhen Goodix Technology Co., Ltd.
-
Page 2: Trademarks And Permissions
Copyright © 2024 Shenzhen Goodix Technology Co., Ltd. All rights reserved. Any excerption, backup, modification, translation, transmission or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Shenzhen Goodix Technology Co., Ltd. is prohibited. -
Page 3: Preface
This document introduces the GR5515 Starter Kit (GR5515 SK), the hardware layout, the circuit schematics, hardware functional modules, and RF and current tests of the GR5515 Starter Kit Board (GR5515 SK Board), to help you get started with the GR5515 Starter Kit Board quickly in developing Bluetooth Low Energy (Bluetooth LE) products and applications with GR551x System-on-Chips (SoCs). -
Page 4: Table Of Contents
10.1 RF Performance Test............................17 10.2 Current Consumption Test..........................18 11 SK Board Dimensions............................21 12 FAQ................................. 22 12.1 Why Do I Fail to Connect to and Download Firmware to GR5515 SK Board via J-Link?........22 Copyright © 2024 Shenzhen Goodix Technology Co., Ltd. -
Page 5: Introduction
The GR5515 Starter Kit (GR5515 SK) is a development platform based on GR551x System-on-Chips (SoCs) (supporting Bluetooth 5.1). It contains a GR5515 Starter Kit Board (GR5515 SK Board), a schematic diagram, and a user guide. The GR5515 SK allows you to get familiar with GR551x-related development tools, quickly develop product prototype, and verify related functions. -
Page 6: Features
• SEGGER J-Link OB that supports debugging • UART-to-USB connector • Micro USB connector, which connects a GR5515 SK Board to a PC • 1.44-inch color thin film transistor (TFT) display • On-board QSPI Flash Copyright © 2024 Shenzhen Goodix Technology Co., Ltd. -
Page 7: Quick Start Guide
Quick Start Guide 2 Quick Start Guide 2.1 Preparation Perform the following tasks before getting started with a GR5515 SK Board. Note: SDK_Folder is the root directory of GR551x SDK. • Hardware preparation Table 2-1 Hardware preparation Name Description Cable Micro USB 2.0 cable... -
Page 8: Example Running
Before using a GR5515 SK Board, follow the steps below to configure power supply and establish connection: Connect the GR5515 SK Board to a PC with a Micro USB 2.0 cable. The Micro USB connector J49 is used for power supply and programming through J-Link. - Page 9 Quick Start Guide Install GRToolbox App on a mobile phone (Android), and enable Bluetooth on the phone. Run the GRToolbox to start scanning and establish connection with the GR5515 SK Board. Copyright © 2024 Shenzhen Goodix Technology Co., Ltd.
-
Page 10: Hardware Overview
Hardware Overview 3 Hardware Overview 3.1 Hardware Layout The top view and the bottom view of a GR5515 SK Board are shown in Figure 3-1 Figure 3-2 respectively. The board mainly integrates an interface microcontroller unit (MCU), a power module, Arduino Uno shield connectors, buttons and LEDs, a LCD connector, a Bluetooth LE RF module, and an on-board QSPI Flash. -
Page 11: Block Diagram
Figure 3-2 Hardware layout of GR5515 SK Board (bottom view) Note: "GPIO_2", "GPIO_9", and "GPIO_8" in Figure 3-2 should be "AON_2", "GPIO_8", and "GPIO_9", respectively. 3.2 Block Diagram The following block diagram of a GR5515 SK Board shows connections between modules. Copyright © 2024 Shenzhen Goodix Technology Co., Ltd. - Page 12 (S5) Buons Antenna 3.3 V Data power + 5 V Interface MCU GR5515 Matching network UART communicaon Osc. J-Link OSC. 32 MHz 32.768 kHz Figure 3-3 Block diagram of GR5515 SK Board Copyright © 2024 Shenzhen Goodix Technology Co., Ltd.
-
Page 13: Interface Mcu
3 MHz. 4.3 Software Download Port of Interface MCU The J-Link port, J43, on the GR5515 SK Board is used for SEGGER J-Link OB firmware download for interface MCU. Note: GR5515 SK Boards have been factory-programmed with J-Link OB firmware. No programming is required for users. -
Page 14: Power Supply
Power Supply 5 Power Supply The GR5515 SK Board provides three power supply modes: power supply via USB connection, power supply from external sources, and from lithium battery. Power supply via USB Power supply from connecon external sources Figure 5-1 Power supply (top view) - Page 15 You can switch S6, to select the power supply mode (from lithium battery or the 3.3 V power output by the on-board LDO). Reverse voltage protection is provided for power supply via USB connection and from external sources through a pair of diodes (D100 and D105). Copyright © 2024 Shenzhen Goodix Technology Co., Ltd.
- Page 16 Power Supply Figure 5-3 Voltage protection diodes for power supply via USB connection/from external sources Copyright © 2024 Shenzhen Goodix Technology Co., Ltd.
-
Page 17: Arduino Uno Shield Connectors
Arduino Uno Shield Connectors 6 Arduino Uno Shield Connectors The GR5515 SK Board provides standard Arduino Uno shield connectors, and the connector locations on the board comply with Arduino standards. You can connect peripherals, such as G-sensor and heart rate sensor, through Arduino Uno shield connectors. -
Page 18: Buttons And Leds
Buttons and LEDs 7 Buttons and LEDs The GR5515 SK Board integrates six buttons and three LEDs, which map to corresponding pins on a GR551x SoC as follows: Table 7-1 Corresponding pins to buttons/LEDs Button/LED GPIO Pin Description Note Button1... -
Page 19: Lcd Connector
8 LCD Connector The GR5515 SK Board integrates a color TFT LCD (1.44 inch, 128 x 128 dpi) and a 3-wire serial peripheral interface (SPI), to help you develop and demonstrate products with display function. In addition, the LCD is pluggable. You can replace it with different-size displays supporting the same type of connection interfaces, to meet the requirements in different application scenarios. -
Page 20: On-Board Qspi Flash
On-board QSPI Flash 9 On-board QSPI Flash The GR5515 SK Board integrates a 32 MB QSPI Flash, to expand Flash memory and store application data. Figure 9-1 Expanded QSPI Flash schematic diagram Note: • QSPI Flash pins, buttons (UP, LEFT, RIGHT, DOWN), and Arduino Uno shield connector pins (GPIO_8 and GPIO_9) are multiplexed. -
Page 21: Performance Test
10.1 RF Performance Test The GR5515 SK Board reserves a small RF connector (J50), which can be connected to a spectrum analyzer or a Bluetooth LE tester (for example, TLF3000) to test the RF performance of the GR5515 SK Board. -
Page 22: Current Consumption Test
10.2 Current Consumption Test You can test the current consumption of the GR551x SoC on the GR5515 SK Board with a test instrument. On the board, VBAT powers VBATH, VBATL, and VBAT-RF of the GR551x SoC through the jumper pin connector J10. Therefore, you can connect a test instrument to J10 to test the current. - Page 23 When instantaneous current runs through the 10-ohm resistor, certain voltage drop occurs at the two probes. The voltage drop is in direct proportion to current. Therefore, the oscilloscope display shows a current change Copyright © 2024 Shenzhen Goodix Technology Co., Ltd.
- Page 24 10-3. During a Bluetooth LE event, the power analyzer automatically stores and displays current curve changes in real time. You can zoom in the curves to see current consumption details. For more information, see operational instructions of the corresponding power analyzer. Copyright © 2024 Shenzhen Goodix Technology Co., Ltd.
-
Page 25: Board Dimensions
SK Board Dimensions 11 SK Board Dimensions Dimensions of the GR5515 SK Board are 101.1 mm x 95.25 mm, with details shown in the figure below. 96.52 mm 12.64 mm 101.1 mm Figure 11-1 GR5515 SK Board dimensions (top view) -
Page 26: Faq
12.1 Why Do I Fail to Connect to and Download Firmware to GR5515 SK Board via J-Link? • Description When I download a firmware file to GR5515 SK Board through Keil/GProgrammer, I fail to connect to and download firmware to GR5515 SK Board via J-Link. • Analysis...
