BRICK Atlas DLB2302B-NS Assembly Instruction

FOR DLB2302B-NS/CH/DR- NIGHTSTAND ,CHEST & DRESSER
STEP 1
Pull the drawer and take out the Leg carton ( A ).
Leg
STEP 2
Assemble the Leg (A) as shown.
Night Stand
Remark : Turn the Night Stand
to upside down position as shown.
ASSEMBLY INSTRUCTION
Hardware Pack
A
STEP 1
1
2
3
A
Soft Surface
Dresser
Hardware Pack
A
STEP 1
Leg
4
5
Remark : Turn the Dresser
to upside down position as shown.
Soft Surface
Hardware Pack
A
Leg
Chest
Remark : Turn the Chest
to upside down position as shown.
A
Soft Surface
No Part List
BUN FOOT
A
No Hardware List
JCBC Bolt m6x40mm Blk
1
Spring Washer 1/4" Blk
2
Flat Washer 1/4"IDx13mmOD Blk
3
Allen Key m4x65mm Blk
4
Wood Dowel 8mmx30mm
5
STEP 1
Qty
4 pcs
Qty
4 pcs
4 pcs
4 pcs
1 pc
4 pcs
