- Page 1 P R O X Y P U F F C O I N N O V A T I O N S...
-
Page 2: Tips And Tricks
PROXY INSTRUCTION MANUAL WHAT’S INSIDE [ 01 ] HOW TO USE [ 02 - 04 ] HEAT SETTINGS [ 05 ] CLEANING [ 06 - 07 ] TROUBLESHOOTING [08 ] TIPS & TRICKS [ 09 ]... -
Page 3: What's New
3D Chamber Joystick Cap What’s Inside - Carry Case - Glass Pipe - Proxy Base - Loading Tool - Proxy 3D Chamber - Cotton Swabs - Joystick Cap - USB-C Cable - Oculus Carb Cap* *Included with Black Proxy only... - Page 4 The lights will glow indicating the battery level: Green (Full) Orange (Half) (Low) To turn the Proxy on/off, press & hold the button for 3 seconds. Use the loading tool to place extract on the bottom surface of the 3D Chamber.
- Page 5 How To Use Replace the Joystick Cap on top of 3D Chamber and press down until snug. Single-click button to toggle through each heat setting. White (Peak) (High) Green (Med) Blue (Low) Double-click to initiate heat cycle, press & hold to cancel. Pulsing light indicates device is heating up.
- Page 6 How To Use Device will flash & vibrate twice when ready. For best results, inhale gently while rotating the Joystick. Clean 3D Chamber after each use with a cotton swab. Wipe gently in a circular motion while chamber is warm.
- Page 7 You can also experiment further with other interchangeable pieces from the Proxy Collection. Peak [Power] - 560°F Delivering the most vapor and strength with less flavor. High [Strong] - 525°F Higher vapor production while maintaining flavor quality.
- Page 8 Cleaning Chamber Remove the Joystick with Jacket & Tether, then unscrew the 3D Chamber from base. Use a cotton swab to gently remove any residue with 90%+ isopropyl alcohol. Submerge the chamber in 90%+ isopropyl alcohol for 20 minutes. Air-dry completely before reattaching.
- Page 9 Glass Carefully remove glass from base. Once removed, submerge glass in 90%+ isopropyl alcohol for 20 minutes. After soaking, thoroughly rinse glass with water and let air-dry completely before reattaching to base. Visit Puffco.com/support for how-to videos and helpful tips.
-
Page 10: Error Codes
Troubleshooting Error Codes No chamber (white white white white) Remove and reinsert chamber. Chamber error (red white white) Remove and clean chamber before reinserting. Device overheating (red for 5 seconds) Allow device to cool before using. Low battery (red red red) Ensure device is fully charged before using. -
Page 11: Boost Mode
To activate, double-click to initiate heat cycle, then double- click again once desired temperature is reached. Boost Mode increases heat cycle duration by 15 seconds & temperature by 18°F. Please do not return your Proxy to the store. Keep your proof of purchase. @Puffco... - Page 12 IEC Compliance This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 13 IEC Compliance This appliance contains batteries that are non-replaceable. This appliance contains batteries that are only replaceable by skilled persons. When the battery is at end of life, the appliance shall be properly disposed of. After heatup, double click to activate boost mode. This extends the time and increases the temperature of your hit.
