Summary of Contents for Puffco PEAK PRO

  • Page 1 P E A K P R O I N S T R U C T I O N M A N U A L...
  • Page 2 Please read the entire instruction booklet before using your device to ensure you’re getting the most out of your Peak Pro. You will avoid damaging your device, or interrupting your experience if you do it now vs. later. See Puffco.com/Support for...

  • Page 3: Table Of Contents

    THE PUFFCO PEAK PRO This guide will show you how to use your Peak Pro including preparation, cleaning, and app connectivity. What’s inside / p 3 - 4 What’s new / p 5 Quick start / p 6 - 10...

  • Page 4: What's Inside / P

    F: Carb Cap* B: Dual Tools (5) G: Chamber C: AC Adapter H: Glass* D: USB-C Cable I: Peak Pro Base E: Carb Cap Tether J: Carrying Case *Each glass piece is hand blown and may vary slightly in size.

  • Page 6: What's New / P

    WHAT’S NEW: Bluetooth App Wireless Charging Enabled (Dock sold separately) USB-C charging Intelligent Temperature Control Large Capacity Customizable Chamber LED lights...

  • Page 7: Quick Start / P

    QUICK START: Fully charge the device before first use. The lights will pulse white while charging. The Peak Pro Power Dock can wirelessly charge your device. (sold separately) Fill glass with water just above the air-holes. Do not fill glass while attached to base.
  • Page 8 Align inlet hole on the front of the glass with chamber. Carefully push the front of glass into the base, then push the back down. To unlock / lock the device, hold down the button for 3 seconds. (Preserves battery between uses)
  • Page 9 Single click to toggle through heat settings. Blue (Low) - Green (Medium) (High) - White (Peak) Use loading tool or a Puffco Dual Tool to place contents on the bottom surface of the bowl (not the sides).
  • Page 10 Attach tether here Place carb cap on top of chamber. Press down until snug. Use the included carb cap tether to keep it safe during use. Double click to initiate heat-up. Press and hold button anytime to exit. Pulsing light indicates heat-up mode is active.
  • Page 11 Device will vibrate and lights will flash 3 times when ready. Inhaling gently will produce the best results. *See p. 11 for boost mode. Use a cotton swab or Dual Tool to clean the chamber after each use. Wipe gently in a circular motion.

  • Page 12: Temperature Settings / P

    TEMPERATURE SETTINGS: HOW TO CHOOSE A SETTING 1. Ensure device is on. 2. Click once to cycle through each heat level. 3. Double click to initiate heat-up. COLOR TEMP. NEED TEMPS PEAK - 600 HIGH - 550 MED - 500 LOW - 450 These are the default color and temperature settings.
  • Page 13 HEAT SETTING PROFILES: Each heat setting has an intended purpose and results depending on the experience you’re looking for. There is no wrong answer when selecting a setting, experiment to find what works best for you and your consumption needs. PEAK (ADVANCED) This setting is intended for the user looking for maximum vapor production and the...

  • Page 14: Cleaning Your Device / P

    CLEANING: CHAMBER Unscrew the chamber from the base. Do not handle if hot. 2. Light Cleaning: Use a cotton swab to gently remove any residue with 90%+ isopropyl alcohol. Deep Cleaning: Submerge the chamber in 90%+ Iso for 20 minutes. Never use water (iso only).
  • Page 15 - Do not blow or exhale hard into the glass. This will force water into the base. - Do not store device with water in the glass, unless you have the Puffco Travel Glass. - Strong inhales may cause spillage and damage to your chamber.

  • Page 16: Advanced Features / P

    READY MODE (APP): *The Peak Pro Power Dock and mobile app are required to activate ready mode. Once the Peak Pro is paired with a mobile device, enable “Ready Mode” found in the Peak Pro app settings. Your device will now automatically initiate the selected heat profile when lifted from Peak Pro Power Dock.

  • Page 17: App Integration / P

    APP INTEGRATION: The Peak Pro app integration has a wealth of new features that allow you to customize your experience, unlock special features, and more. Search this link on your phone: App//@puffco.com Starting from the off position - hold the button for 6 seconds to sync your Peak Pro with your app.

  • Page 18: Peak Protection / P

    COMPLIANCE: Puffco Peak Pro FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 19 interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interferencve by one or more of the following measures: - Reorient or relocate the receiving antenna.
  • Page 20 (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.” © 2020 Puff Corp. All rights reserved, “Puffco”, the Puffco Logo and “Peak” are registered trademarks of Puff Corp. Printed in China.
