- Page 1 22” BATTERY POWERED PUSH SWEEPER Operation Manual MODEL NUMBER: eTOS22 To reduce the risk of injury, the user must read and understand the Operator’s Manual before using this product. Save these instructions for future reference.
-
Page 2: Table Of Contents
1.2 Usage Safety 1.3 Battery Safety 1.4 Service Safety 2. EQUIPMENT PERFORMANCE 2.1 Battery Powered Push Sweeper Design 2.2 TOMAHAWK® Battery 2.3 Unpacking the Unit 2.4 Battery Powered Push Sweeper Parts 3. SPECIFICATIONS 4. EQUIPMENT ASSEMBLY 4.1 Integrating The Water Proof Cover 4.2 Integrating The Battery... - Page 3 Register Your Equipment Thank you for purchasing TOMAHAWK® equipment! Your product is covered by the TOMAHAWK® Warranty policy, but in order to activate your warranty, we need you to register your product. In addition to activating your equipment warranty, product registration will grant you access to important product updates, streamlined customer service and more.
-
Page 4: Safety Information
TOMAHAWK®. The information contained in this manual is based on machines in production at the time of publication. TOMAHAWK® reserves the right to change any portion of this information without notice. No part of this publication may be reproduced in any form or by any means, electronic or mechanical, including photocopying, without express written permission from TOMAHAWK®. -
Page 5: Operating Safety
Indicates a possibly dangerous situation. Where there is a risk of damaging the machine or its individual components. Indicates to read the Operation Manual. It is important that you read the operation manual before first use and keep it in a safe place for future reference. 1.1 Operating Safety Familiarity and proper training are required for the safe operation of equipment! Equipment operated improperly or by untrained personnel can be dangerous! Read... -
Page 6: Battery Safety
2. EQUIPMENT PERFORMANCE 2.1 22” Battery Powered Push Sweeper Design TOMAHAWK® Battery Powered Push Sweeper are 5X faster than a broom covering a wider path on every pass helping you cover more surface area so you can finish sweeping faster! Operation is easy, simply adjust the broom settings for lighter or deeper cleaning of any hard surface and push forward letting the powered two brush system effortlessly clean up against... -
Page 7: Tomahawk® Battery
2.2 TOMAHAWK® Battery TOMAHAWK® 18V Lithium-Ion 5 Ah batteries charge faster and work longer than standard batteries, giving you superior performance. With a fast charge time, spend more time working on the things that matter and less time waiting for a charge. -
Page 8: Specifications
3. SPECIFICATIONS eTOS22 SPECIFICATIONS Total Sweeping Width 22” (550mm) Container 6 gal (25 l) Working Efficiency 2500㎡/H Net /Gross Weight 17.8 lbs/20.7 lbs (8.1kg/9.4kg) Voltage Battery Run Time 3-4h Charging Time 22” * 9” * 24.2” (58 * 25 * 61.5cm) Packing Size 50 F°~122 F°... -
Page 9: Handle Assembly
4.3. Handle Assembly 4.3.1 Insert the sliding handle into the adjustable handle and push handle until it clicks into the locking position. FIGURE 3. FIGURE 3 4.3.2 Connect the sliding handle hole to the screw on the side of the sweeper body and tighten knob. -
Page 10: Waste Bin Assembly
5. OPERATION 5.1. Using the Sweeper 5.1.1 Press the top button to turn on the sweeper. FIGURE 6. 5.1.2 After turning on the machine to begin sweeping, push forward at a normal walking speed. Use on surfaces including workshops, driveways, walkways, store fronts, patios, garages, pool side. -
Page 11: Brush Adjustment
5.3 Brush Adjustment 5.3.1 The broom's adjustment knob is positioned on the front of the machine. Move to the left to raise and to the right to lower. FIGURE 8. Brush Adjustment Dial Brush Adjustment Dial Turn to the left Raise the brush. -
Page 12: Brush(Circular Broom) Replacement
Always charge the battery in an area between 0-40 C°, do not charge at around flammable liquid, gas or dust, or areas where there is a risk of explosion. WARNING 5.6 Brush(Circular Broom) Replacement 5.6.1 Set the adjusting wheel knob to the far right side. FIGURE 13. 5.6.2 Pull the inclined wheels strongly to remove them (FIGURE 14.). -
Page 13: Work Indicator Light
5.7 Work Indicator Light Solid Green Light: Works normally. Flashing Green Light: Overloaded or stalled, turn off the power to help troubleshoot. Solid Red Light :The battery is low, charge it as soon as possible. Flashing Red Light:The battery is too low to function, needs to be charged. FIGURE 21 6. -
Page 14: Troubleshooting
7. TROUBLESHOOTING Side brush blockage or Turn off the power and entangled foreign debris remove debris Brush Does Not Turn The brush is too low from the (Green LED light is flashing) Rotate the handle to adjust ground and the resistance is the height of the side brush high Brush Does Not Turn... -
Page 15: Maintenance Record
8. MAINTENANCE RECORD TOMAHAWK® tools are assembled with care and will provide years of service when properly maintained. Preventative maintenance and routine service are essential to the long life of your tool. Adhere to reading through this manual thoroughly. You will find that you can do some of the regular maintenance yourself. -
Page 16: Equipment Warranty
10. EQUIPMENT WARRANTY Your new TOMAHAWK® equipment is warranted to the original purchaser for a period of one-year (12 months) from the original date of purchase. The TOMAHAWK® warranty is against defects in design, materials and workmanship. The following are not covered under the warranty: 10.1.1 Damage caused by abuse, misuse, dropping or other similar damage caused by or as... -
Page 17: Parts Manual
22” BATTERY POWERED PUSH SWEEPER Parts Manual MODEL NUMBER: eTOS22... -
Page 19: Explosion Diagram
EXPLOSION DIAGRAM... - Page 20 PARTS Name Quantity Container Assembly Handle Handle Grip Turning Knob(Nut M8) Bolt M8x3 0 Sliding Handle Parts Stop Spring Wheel Cap Quick-Fastener 11.5 Wheel Bearing 6901 Turning Knob Left Circular Broom Right Circular Broom Toothed Bushing Left Inclined Wheel...
