Summary of Contents for Tomahawk TOS38
- Page 1 PUSH SWEEPER Operation Manual MODEL NUMBER: TOS38 To reduce the risk of injury, the user must read and understand the Operator’s Manual before using this product. Save these instructions for future reference.
-
Page 2: Table Of Contents
Table of Contents 1. SAFETY INFORMATION 2. EQUIPMENT DATA 3. SPECIFICATIONS 4. QUICK ASSEMBLY GUIDE 5. OPERATION - Using the Sweeper - Checking the Equipment - Removing Debris 6. TROUBLESHOOTING 7. MAINTENANCE RECORD 8. REPLACEMENT PARTS 9. WARRANTY 10. PARTS MANUAL 11. - Page 3 Register Your Equipment Thank you for purchasing TOMAHAWK® equipment! Your product is covered by the TOMAHAWK® Warranty policy, but in order to activate your warranty, we need you to register your product. In addition to activating your equipment warranty, product registration will grant you access to important product updates, streamlined customer service and more.
-
Page 4: Safety Information
TOMAHAWK®. The information contained in this manual is based on machines in production at the time of publication. TOMAHAWK® reserves the right to change any portion of this information without notice. No part of this publication may be reproduced in any form or by any means, electronic or mechanical, including photocopying, without express written permission from TOMAHAWK®. - Page 5 1.1 Operating Safety 1.1.1 Observe all applicable local safety regulations, standards, and ordinances. 1.1.2 Individuals who operate the sweeper must be informed about the dangers related to use of the machine. 1.1.3 Do not operate the sweeper if you are under the influence of any substance (drugs, alcohol) which might impair vision, dexterity, or judgment.
-
Page 6: Equipment Data
2. EQUIPMENT DATA 2.1 Features 1. Push Handle 8. Wheel Cover 2. Waste Bin 9. Dust Filter 3. Waste Bin Handle 10. Angled Wheel 4. Arm Adjustment Knob 11. Handle Knob 5. Carrying Handle 12. Rolling Brush 6. Disc Brush 13. -
Page 7: Specifications
3. SPECIFICATIONS TOS38 SPECIFICATIONS Working Width 31 - 38 in. (78.7 - 96.5) Cleaning Area 12,467 ft (3799.9 m) Container Capacity 14.5 Gallons (54.8 Liters) Net Weight 60 lb. (27.2 kg) Package Size 36 x 31 x 16 in (91.4 x 78.7 x40.6 cm) -
Page 8: Quick Assembly Guide
4. QUICK ASSEMBLY GUIDE Raise the handles and open the hopper bin Lift the broom arms and begin unscrewing to find the sweeper’s two front brooms. the 3 screws attached underneath. Align the first broom to the holes in the arm Loosen the handles knobs then pull the and begin to fasten in place with the screws. -
Page 9: Operation
5. OPERATION 5.1. Using the Sweeper 5.1.1 The operator should use the sweeper under normal conditions and consider the surrounding environment when operating - be cautious of people around the sweeper and objects that may unintentionally sweep in an outward direction. 5.1.2 Depending upon the area the operator intends to sweep, you can adjust the height of the front and back brushes. -
Page 10: Removing Debris
5.3 Removing Debris 5.3.1 Hold your handle and lift it up to remove the garbage can 5.3.2 When the main brush is entangled with garbage, it should be reversed and removed in time. 5.3.3 Dump the garbage along the side of the garbage can. No knocking on the garbage can is allowed. - Page 11 6.5 Side Brush Not Moving Solution: Replace Brush and or band that rotates brush. 6.6 Debris Not Sweeping up into Hopper Solution: Replace roller brush 6.7 Brush Bristles Damaged Solution: Use a heat gun or blower dry to straighten bristles 6.8 The Machine is Difficult to Push Solution: The Roller brush may have a blockage.
-
Page 12: Maintenance Record
7. MAINTENANCE RECORD TOMAHAWK® tools are assembled with care and will provide years of service when properly maintained. Preventative maintenance and routine service are essential to the long life of your tool. Adhere to reading through this manual thoroughly. You will find that you can do some of the regular maintenance yourself. -
Page 13: Warranty
9. WARRANTY Your new TOMAHAWK® equipment is warranted to the original purchaser for a period of one-year. (12 months) from the original date of purchase. The TOMAHAWK® warranty is against defects in design, materials and workmanship. The following are not covered under the warranty: 1. -
Page 14: Parts Manual
TOS38 PUSH SWEEPER Parts Manual... - Page 15 PARTS LIST Part # Name Handle Sleeve Sealing Gluey Stripe Sponge Cap Sponge Locking Pin Self Tapping Screw St4.8*16 Screw Cap Half Round Head Square Neck Bolt M8*25 Dust-Proof Rear Cover Wheel Cover Baffle 1 Drive Belt Dust-Proof Rubber Self Tapping Screw ST4.8*32 Rolling Brush Self Tapping Screw ST4.8*22 Side Brush...
- Page 17 1 acre in less than 30 minutes with 0 ea . Great for year-round use, Tomahawk Foggers are also an excellent leaf blowing solution. No matter the season, keep your yard pest free and looking great! Item #: TMD14 3.7 GALLON TURBO...
- Page 18 3 Year Engine Warranty & 1 Year Product Warranty 3 Year Engine Warranty & 1 Year Product Warranty HAVE QUESTIONS? HAVE QUESTIONS? Contact us. We’re here to help! Contact us. We’re here to help! Email us at sales@tomahawk-power.com Email us at sales@tomahawk-power.com...
- Page 19 1 Year Product Warranty 3 Year Engine Warranty & 1 Year Product Warranty 1 Year Product Warranty * All coupons in this manual are valid only for orders placed on www.tomahawk-power.com, unless otherwise noted. Coupon codes ASSEMBLED IN THE ASSEMBLED IN THE may only be used once per customer and may not be combined with any other offer.
- Page 20 With same day shipping and faster delivery times, count on Tomahawk to keep you powered throughout the day! With long lasting parts and engines, Tomahawk equipment will be the star of your fleet for years to come. Visit www.tomahawk-power.com to get started today! TOMAHAWK®, LLC...
