Lynx L6-2 Linear Interior/Exterior LED Light Bar Wiring and
For best results, we suggest this interior light bar
be installed by a professional emergency vehicle
technician. The user/installer of this light is
responsible for the proper mount and
installation of the light. Please
Tactical Dynamics
with any concerns and keep this
document in a safe location for future reference.
Instructions for Traditional Mount
Cable harness should exit to the right when
•
mounted
Don't run wires near engine hot spots or in the
•
path of airbag deployment
Position interior light bar in vehicle before drilling
•
Mark mounting holes
•
Drill 5/8"mounting holes and a centered hole
•
Use grommets where appropriate
•
Endcap Mounting Instructions for Lynx L62
Drill a 5/8" hole for passage of wires
•
Pass the cable harness through the light's endcap
•
Remove screws to take off endcap
•
Place grommet in hole
•
Feed cable through light
•
Mount with included hardware
•
