Ranger Split TIR LED Deck Light Wiring and Installation Guide
The Ranger Split TIR LED Deck Lights are weatherproofed for
exterior or interior installation. For best results, and to protect
the integrity of your
manufacturer warranty, we recommend these LED lights be
installed by an emergency vehicle technician. If you install
your emergency lights yourself, it is important to remember that
most installation failures are caused by improper wiring or
battery connections. The easiest way to eliminate this problem is
to repeat the steps mentioned below.
Ranger Split TIR LED Deck Light Emergency Light
Mounting Tips
Unbox Ranger Split TIR LED Deck Light and hardware
•
Locate the L mount brackets
•
Choose a location for your dash and deck light installation
•
Mark mounting holes (use masking tape to mark holes)
•
Drill marked mounting holes
•
Drill hole for wires
•
De-burr holes to protect wires and remove debris
•
Insert wires
•
Install Deck 2 Dual lights with hardware included with
•
purchase
Ranger Split TIR LED Deck Light Basic Wiring Instructions
To power the Ranger Split TIR LED Deck Lights, you will need
to locate the unit's red and black wires. The red wire connects to a
pre-existing switch source, and the black wire connects to a
negative ground source. After completing this step, you will be
able to power the light on.
