RELAY OUTPUT

The meter is designed with a relay for connection to an external indicating or controlling device.
When CO readings go over the upper limit the relay closes. The relay will open again when CO
2
readings fall below the lower limit. The relay output port requires a 2.5mm STEREO phone jack
plug. The relay is: 1A 30VDC/0.5A 125VAC.
1. AC adaptor input (5VDC)
2. Alarm Relay output
3. Phone plug wiring
SETUP
(Alarm level, Temperature scale, Real Time clock)
Hold the SET button, in the normal mode, for more than 1 second to enter the setup mode.
P1. CO ALARM: GOOD LEVEL
1 2
When entering the setup mode, P1.
again to go into P1.
be blinking on the display.
Press the ▲or MIN/MAX▼ button to increase or decrease the value. Each press adjusts in 100ppm
increments. The alarm range is 0 to 700ppm.
When the value has been set, press the SET button to confirm the GOOD limit and to proceed to
P1. for setting the upper NORMAL limit. Press the ESC button to exit without saving the setting.
2
P1. CO ALARM: NORMAL LEVEL
2 2
P1. is used for setting the CO
2
blinking on the display.
Press the ▲or MIN/MAX▼ button to increase or decrease the value. Each press adjusts in 100ppm
increments. The alarm range is 700 to 1000ppm.
When the value has been set, press the SET button to confirm the NORMAL limit and to proceed to
P1. for setting the upper POOR limit. Press the ESC button to exit without saving the setting.
3
www.ponpe.com
and "CO2" are displayed on the LCD. Press the SET button
0
for setting the CO upper limit for the GOOD level. The current
1
2
upper limit for the NORMAL level. The current
2
4
3
set value will
set value will be
CO200-EU-EN v1.2 08/13
