UAFX Orion Tape Delay Manual
Updated 1 year ago
This article contains complete operating instructions for the UAFX Orion Tape Delay pedal from
Universal Audio.
In this article
A Letter From Bill Putnam, Jr.
Orion Quick Start
Orion Tape Echo Overview
Orion Power
Orion Connections
Orion Connections
Orion Controls
Orion Specifications
Orion Safety
A Letter From Bill Putnam, Jr.
Congratulations on your new UAFX pedal. We know that buying any new piece of gear requires
an investment of time and money, and we aim to make your investment pay off!
https://help.uaudio.com/hc/en-us/articles/17411210977044-UAFX-Orion-Tape-Delay-Manual
UAFX Orion Tape Delay Manual – Universal Audio Support Home
1/10
Advertisement
Related Manuals for Universal Audio UAFX Orion Tape Delay
Summary of Contents for Universal Audio UAFX Orion Tape Delay
- Page 1 UAFX Orion Tape Delay Manual – Universal Audio Support Home Browse help topics UAFX Orion Tape Delay Manual Updated 1 year ago This article contains complete operating instructions for the UAFX Orion Tape Delay pedal from Universal Audio. In this article A Letter From Bill Putnam, Jr.
- Page 2 11.09.2024, 09:27 UAFX Orion Tape Delay Manual – Universal Audio Support Home At UA, we are dedicated to the idea of building “instant classics” — the type of music and audio gear that delivers album-worthy sounds to inspire you for decades.
-
Page 3: Key Features
11.09.2024, 09:28 UAFX Orion Tape Delay Manual – Universal Audio Support Home Orion Tape Echo Overview Orion Tape Echo gives you the magical, hazy delay effects of vintage ’70s Maestro Echoplex EP-III tape delays, in a compact pedal.* Thanks to the same award-winning algorithms from our Starlight Echo Station, Orion gives you the rich, three-dimensional effects of a thoroughly emulated vintage tape echo —... - Page 4 11.09.2024, 09:28 UAFX Orion Tape Delay Manual – Universal Audio Support Home Orion Connections To learn how to wire your UAFX pedals, go here. Orion Controls The following controls are available on Orion. Delay Sets the tape echo rate, from 80-700 milliseconds. Because Orion is a tape-based delay, the echo pitches vary as you adjust this control.
- Page 5 11.09.2024, 09:28 UAFX Orion Tape Delay Manual – Universal Audio Support Home Tape Use this switch to select the tape character for Orion’s delay repeats: Mint, Worn, or Old. Details Mint A new old stock “closet classic” machine with new old stock tape and snappy compander compression circuit on the record head.
-
Page 6: Bypass Mode
11.09.2024, 09:28 UAFX Orion Tape Delay Manual – Universal Audio Support Home The Rec Level control adjusts how hot the input signal is recorded to the tape. At higher levels, the tape will saturate and distort. Bypass Mode You can switch between Trails or True bypass modes using the slider switch on the back of the pedal. ... - Page 7 11.09.2024, 09:28 UAFX Orion Tape Delay Manual – Universal Audio Support Home True Preamp is on dry signal when pedal is on Orange Trails Preamp is always on dry signal, whether pedal is on or bypassed Footswitch The footswitch toggles the effect on/off. The LED lights to indicate when the effect is active.
- Page 8 11.09.2024, 09:28 UAFX Orion Tape Delay Manual – Universal Audio Support Home USB Type-C For registration and firmware updates via computer Dimensions Height: 2.29 inches, 5.81 cm (with knobs and protrusions) Width: 2.58 inches, 6.55 cm Depth: 4.75 inches, 12.07 cm Weight (unboxed) 0.66 lbs...
- Page 9 11.09.2024, 09:28 UAFX Orion Tape Delay Manual – Universal Audio Support Home Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat source such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
- Page 10 11.09.2024, 09:28 UAFX Orion Tape Delay Manual – Universal Audio Support Home https://help.uaudio.com/hc/en-us/articles/17411210977044-UAFX-Orion-Tape-Delay-Manual 10/10...
