• Important Safeguards
• Installation
• Use and Care
Certain ranges come equipped with special features. Determine from a study of
your range which of the instructions given in this booklet pertain to your range.
This booklet gives valuable instructions covering the installation, adjustment and
use of your range.
HOW TO OBTAIN SERVICE AND/OR PARTS
When your range does not operate in accordance with the instructions in the
manual, you should contact the dealer in the immediate vicinity for service. Or,
the purchaser may contact the service organization noted on the warranty.
Electric
Range
Read and Save These Instructions
IMPORTANT – Save for local electrical inspector's use.
Electric Ranges with
Induction Surface

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WEM665W and is the answer not in the manual?

Questions and answers

Related Manuals for Summit WEM665W

Summary of Contents for Summit WEM665W

  • Page 1 Electric Ranges with Induction Surface This manual contains information for: • Important Safeguards • Installation • Use and Care Certain ranges come equipped with special features. Determine from a study of your range which of the instructions given in this booklet pertain to your range. This booklet gives valuable instructions covering the installation, adjustment and use of your range.

  • Page 2: Table Of Contents

    Range Record in the space provided below the Model No. and Serial No. of this appliance. These numbers are found on the serial plate located below the lift-up cooktop. Model No._________________________ Type Number _____________________ Serial No. ________________________ Purchase Date_____________________ Record these numbers for future use. IMPORTANT: Keep a copy of your bill of sale.
  • Page 3 READ THE IMPORTANT SAFEGUARDS AND ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. Remove all tape and packaging wrap before using the oven. If any glue remains, touch the residue with the sticky side of the tape already removed. Or, use a cloth soaked with rubbing alcohol.

  • Page 4: Important Safeguards

    IMPORTANT SAFEGUARDS, Continued • Do not store items of interest to children in the cabinets above a range or on the backguard of a range. Children climbing on the range to reach the items could be seriously injured. • Do not allow children to climb or play around the range. The weight of a child on an open oven door may cause the range to tip, resulting in serious burns or other injury.
  • Page 5 IMPORTANT SAFEGUARDS, Continued • Never modify or alter the construction of the range such as removal of leveling legs, panels, wire covers, anti-tip brackets or any other permanent part of the product. • Stand to the side of the oven when opening the oven door. Slowly open the door to allow hot air or steam to escape before removing or replacing food.
  • Page 6 IMPORTANT SAFEGUARDS, Continued • Do not heat unopened food containers. Build-up of pressure may cause the container to burst and result in injury. The following situations could cause bodily injury or property damage. • Disconnect the range from electrical supply before attempting to service or move it.

  • Page 7: Energy Saving Ideas

    IMPORTANT SAFEGUARDS, Continued • Use care when touching glass top. The glass cooking surface will retain heat after the controls have been turned off. Make sure all surfaces have cooled before touching or cleaning. • Do not cook on a broken glass top. If the top glass surface should break, cleaning solutions and spillovers may penetrate the broken glass and create a risk of electric shock.

  • Page 8: Installation Instructions

    INSTALLATION INSTRUCTIONS Be sure appliance is properly installed and grounded by a qualified technician. It is the responsibility of the technician to make certain that your range is properly installed. Situations caused by improper installation are not covered under the warranty. Any expenses incurred due to such situations will not be paid by the manufacturer of the appliance.

  • Page 9: Backguard Installation Instructions

    BACKGUARD INSTALLATION INSTRUCTIONS Electric Ranges (This feature may not be available on all appliances.) 1. Move the main top forward. (Lift up and pull forward slightly.) For glass top models, rear holding brackets will have to be briefly unscrewed then reattached when backguard installation is complete.

  • Page 10: Cord Connected Appliances

    CORD CONNECTED APPLIANCES We recommend that you have the electrical hookup of your range done by a qualified electrician. Have the electrician show you where your range disconnect is located. If you fail to wire your range in accordance with governing codes, you may create a hazardous condition.
  • Page 11 THREE-WIRE CORD CONNECTION 1. Remove the top nuts on the junction block studs. 2. Tighten the back nuts. 3. Install the three-wire cord and strain relief provided on the cord set through the hole in the power cord bracket. 4. Connect the red and black leads to the outer terminals and the white lead to the center terminal.
  • Page 12 THREE-WIRE CONDUIT CONNECTION NOTE: The power cord bracket will have to be reversed for conduit installations. Detach the bracket and flip its orientation. Reattach the bracket to the range so the conduit will pass through the smaller hole. 1. Remove the top nuts on the junction block studs.

  • Page 13: Cabinet Preparation

    CABINET PREPARATIONS Free-Standing Ranges “A” - 30 inches minimum clearance between the top of the cooking surface and the bottom of an unprotected wood or metal cabinet; or “A” - 24 inches minimum when bottom of wood or metal cabinet is protected by not less than 1/4 inch “Flame Retardant”...
  • Page 14 OVEN OPERATION OPERATIONAL CHECK Check all connections to see that they are tight and have not become loosened during transit. The oven bake element should heat up within a minute when the temperature control is set in the bake area of the dial. The broil element can be checked with dial in broil mode.

  • Page 15: Control Panel

    OPERATING YOUR COOKTOP For Models with Black Cooktops 1. 1500W Boost 2000W Cooking Zone 2. 2000W Boost 3000W Cooking Zone 3. 2000W Boost 3000W Cooking Zone 4. 1500W Boost 2000W Cooking Zone 5. Glass plate 6. Control panel Control Panel 1.
  • Page 16 For Models with White Cooktops 1. 1500W Cooking Zone 2. 2000W Cooking Zone 3. 2000W Cooking Zone 4. 1500W Cooking Zone 5. Glass plate 6. Control panel Control Panel 1. Cooking Zone selection button 2. Stop & Go control button 3.
  • Page 17 Choose the Right Cookware (Induction Models) • Only use cookware with a base suitable for induction cooking. Look for the induction symbol on the packaging or on the bottom of the pan. • You can check whether your cookware is suitable by carrying out a magnet test.
  • Page 18 Always lift pans off the hob – do not slide, or they may scratch the glass. Suggested Pan dimensions for induction hob The cooking zones are, up to a limit, automatically adapted to the diameter of the pan. However, the bottom of this pan is suggested to have a minimum of diameter according to the corresponding cooking zone.
  • Page 19 For Touch/Slider Control Models To Start Cooking After the cooktop is connected to a power source, the cooktop will beep once, all the indicator lights will illuminate for one second, then go out. To then start cooking, follow these steps: 1.
  • Page 20 Using Booster Function (Induction Cooktop) Some of the induction cooktop models have one or several cooking zones which has 'Booster' function. You can use the 'Booster' function to boost power of the relevant cooking zone for a maximum power rating for 5 minutes. Using the Booster Function when a Cooking Zone is Working 1) Active the cooking zone you want to use booster function.
  • Page 21 To Unlock the Controls Make sure the electric cooktop is turned on. for 3 seconds, the buzzer will Touch and hold the 'Child Lock' control button beep once and “Lo” indicator on the timer will disappears. The 'Child Lock' is now inactive. You can now start using your electric cooktop.
  • Page 22 Using the Timer Note: Timer function is for touch/slider control models only. Minute display shows the number of minutes Timer control When the cooktop is turned on, you can use the timer in two different ways: • You can use it as a “minute minder” alert, which can be set for up to 99 minutes. In this case, the timer will not turn any cooking zone off when the set time is up.
  • Page 23 NOTE: By continuously touching the timer control button, the slider works in this sequence: “Single Digit-Tens Digit -Confirm Setting-Single Digit-…” When the minute minder is set, it will begin to count down immediately and show the remaining time in the display. The buzzer will beep for 30 seconds, and the timer indicator display shows “- -“...
  • Page 24 NOTES: • The red dot next to the power level indicator will illuminate for those zones set with a timer. • After adjusting, the setting in timer indicator will flashing for 5 seconds and then stop flashing, then the setting be confirmed. •...
  • Page 25 Auto Shutdown Another safety feature for touch/slider control cooktop is auto shutdown. This occurs whenever you forget to switch off a cooking zone. The default shutdown times as below table: Power level Default working timer (hour) Overheat Protection A temperature sensor inside the cooktop monitors its internal temperature. When an excessive temperature is detected, the cooktop will automatically turn off.
  • Page 26 For Stir-Frying 1. Choose a ceramic compatible flat-based wok or a large frying pan. 2. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large quantities, cook the food in several smaller batches. 3. Preheat the pan briefly and add two tablespoons of oil. 4.
  • Page 27 CLEANING AND MAINTENANCE CAUTION: Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from ELECTRICITY supply and ensure the appliances is completely cool. Cleaning the Cooktop Surface • Clean spillages from the cooktop surface as soon as possible after use. Always ensure the surface is cool enough before cleaning.
  • Page 28 Boil over melts and hot/sugary spills on the glass Remove these immediately with a fish slice, palette knife, or razor blade scraper suitable for ceramic glass of cooktop, but beware of hot cooking zone surfaces: 1. Switch off the power supply. 2.
  • Page 29 CLEANING THE RANGE Always keep cleaning materials and chemicals in a safe place and away from children. Know what you are using. Make sure all parts of the range are COOL before cleaning. Be sure to replace the parts correctly. Using Commercial Oven Cleaners Commercial oven cleaners may be used on porcelain lined ovens;...
  • Page 30 USER SERVICING • Do not repair or replace any part of the appliance unless specifically recommended in this manual. All other servicing should be referred to a qualified technician. • Disconnect the range from electrical supply before attempting to service or move it. •...

  • Page 31: Alignments And Adjustments

    ALIGNMENTS AND ADJUSTMENTS Oven Door Spring Adjustments The oven door springs are properly adjusted before leaving the factory. The springs should be adjusted to allow the door to remain open when pulled 90 degrees forward and yet pull the door tight against the oven front frame when closed. If adjustments should become necessary, remove the storage drawer and grasp spring with fingers, and pull downward.

  • Page 32: Removable Oven Door

    REMOVABLE OVEN DOOR On some models, the oven door is equipped with detachable hinges to make cleaning the oven interior easier. Perform the following steps to remove the door. Locate two hinge locking pins to use for door removal. You may use items such as nails or rivet pins approximately 0.080 - 0.105 inches diameter for this purpose.

  • Page 34: Troubleshooting

    TROUBLESHOOTING If you encounter any issues with your cooktop, consult the table below for a quick resolution before contacting our service team: CAUSE/RESOLUTION: ISSUE: Check whether there is a power outage. There is no power Check whether the appliance is properly connected to the to the appliance electricity.
