TGM CCR-24CR1 Service Manual

R410a 60hz normal efficiency top-discharge outdoor series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R410A 60Hz Normal Efficiency
Top-discharge Outdoor Series
Part 1 General information
1. Model Names of Indoor/Outdoor Units
2. External Appearance
3. Features
Part 2 Indoor Units
1.Round-Way Cassette Type (Standard)
2.Duct Type
3.Ceiling & Floor Type
4.Air Handler unit
Part 3 Outdoor Units
1.Specification
2.Dimensions
3.Typical Installation
4.Wiring Diagrams
5.Electric Characteristics
6.Operation Limits
7. Exploded View
8.Sound Levels
9.Troubleshooting
1
Service Manual
5
5
6
8
9
10
27
48
74
85
86
87
88
89
91
91
92
94
95
