- Page 1 ® Eureka Digital System User Manual October 2009 QR 775020 A0 ADS LLC 4940 Research Drive Huntsville, AL 35805 Telephone (256) 430-3366 / Fax (256) 430-6633 www.adsenv.com...
- Page 2 Notice of Proprietary Information The information contained herein represents the latest information available at the time of publication. ADS reserves the right to make any changes or modifications to the content of this document, without notice, to reflect the latest changes to the equipment. No part of this document may be reproduced...
-
Page 3: Table Of Contents
ADS Eureka Digital System User Manual Table of Contents Chapter 1 Introduction ..............1 System Features ...................3 Transmitters ...................3 Automatic Velocity Measurement ............3 In-Case Battery Charging ..............3 Advanced Analysis Software..............3 System Components and Options ............4 Optional Equipment and Software............4 ADS No-Hassle Warranty and Return Policy..........5 New Product Warranty ................5... - Page 4 ADS Eureka Digital System User Manual Chapter 5 Eureka Digital Software ..........21 Splash Screen .....................22 Main Screen ....................23 Main Menu....................24 File Menu .....................24 Run Menu.....................27 View Menu...................28 Delayed Recording Menu ..............30 Correlation Mode Menu...............33 Help Menu ...................33 Toolbar Buttons ..................34 Display Area ....................35...
-
Page 5: Chapter 1 Introduction
Introduction ® The ADS Eureka Digital System is the latest model in the proven Eureka family of high-performance leak noise correlators designed for locating leaks in buried water pipes. Combining advanced technology, operational flexibility, and simplicity, Eureka Digital offers a comprehensive solution for leak location, even under conditions ranging from substantial background noise to minimal leak noise. - Page 6 ADS Eureka Digital System User Manual 2-Transducer Method The 3-transducer method incorporates a third (yellow) sensor for measuring velocity. Employing this option increases the accuracy of locating the leak position. 3-Transducer Method...
-
Page 7: System Features
Automatic Velocity Measurement Every Eureka Digital can operate with three sensors without requiring a third transmitter. The third sensor connects directly to the receiver module. Three sensors provide the capability for measuring velocity, improving leak location accuracy and significantly reducing the opportunity for dry holes. -
Page 8: System Components And Options
ADS Eureka Digital System User Manual System Components and Options Two accelerometers Two digital transmitters Digital receiver module (incorporating third signal input) Choice of one of the following: Small handheld computer Ruggedized handheld computer ... -
Page 9: Ads No-Hassle Warranty And Return Policy
ADS. Product Returns If the customer is not satisfied with the performance of the Eureka Digital System, the customer may return the equipment within 30 days for a full... - Page 10 ADS Eureka Digital System User Manual refund, provided the condition of the equipment is in the same condition as sold, except for expected or normal wear and tear for the period of use.
-
Page 11: Chapter 2 Principles Of Leak Noise Correlation
ADS Eureka Digital System User Manual C H A P T E R 2 Principles of Leak Noise Correlation Leak noise correlation is used to detect leaks in pipes with a positive internal pressure, where leaks allow a loss of flow to the outside. The movement of fluid through the leak causes rapid pressure changes around the site of the leak, establishing a noise source at the leak. -
Page 12: Methods For Locating Leaks
ADS Eureka Digital System User Manual Methods for Locating Leaks Previous methods of leak location relied on an initial detection of a noise, which was then traced along ground level to identify the location of the maximum noise. This location was assumed to be directly above the location of the leak. - Page 13 ADS Eureka Digital System User Manual pipe under investigation, ensuring the greatest accuracy in locating the leak.
-
Page 14: Sensor Position
ADS Eureka Digital System User Manual Sensor Position Correlator operation relies on the location of the leak existing between the two sensors. However, two contexts can prevent this from occurring. The solution requires moving one sensor before a successful correlation can be performed. -
Page 15: Chapter 3 System Components
ADS Eureka Digital System User Manual C H A P T E R 3 System Components The standard Eureka Digital System consists of the following components: Red transmitter (including antenna) Blue transmitter (including antenna) Two accelerometers ... -
Page 16: Descriptions
ADS Eureka Digital System User Manual Descriptions The following sections provide brief descriptions of the Eureka Digital System components. Transmitter The transmitters (blue and red) operate in a similar manner, and each includes the following components: Radio transmitter ... - Page 17 ADS Eureka Digital System User Manual Pushbutton switch The pushbutton switch turns on and off the transmitter unit. Refer to Transmitter Control and Indicators below for more information. LEDs The LEDs display information about the transmitter. Refer to Transmitter Control and Indicators below for more information.
-
Page 18: Accelerometers
ADS Eureka Digital System User Manual LED Response While Charging Under normal circumstances, when the charger is plugged in, the LED bar graph will ramp up repetitively. This indicates that the battery is undergoing a fast or top-off charge. When the fast charge is complete and the battery is just receiving a trickle- charge, the bar graph will stop ramping up and all LEDs in the bar graph will be off, except the top red LED. -
Page 19: Receiver Unit
ADS Eureka Digital System User Manual Receiver Unit The receiver unit receives power from the USB port of the computer and, therefore, must be connected to the computer when in use. The unit receives signals from the transmitters. An accelerometer also can be... -
Page 20: Car Charge Cable
This option can be particularly useful when transporting the system to a remote location. Software CD This CD contains the Eureka Digital software for loading onto a suitable PC. Refer to Hardware and Software Setup on page 20 in Chapter 4, Getting Started, for more information. -
Page 21: Small Tablet Computer (Optional)
Ruggedized Tablet Computer (optional) A ruggedized computer is available for portable use with the Eureka Digital System. This portable, battery-powered computer is ruggedized for use in harsh environments and connects to the receiver unit, which may be carried in a holster. - Page 22 ADS Eureka Digital System User Manual Typical ruggedized touch screen computer...
-
Page 23: Chapter 4 Getting Started
C H A P T E R 4 Getting Started Eureka Digital Systems supplied as a complete system (including a PC) are set up and ready for use. For systems that are not ready for use, refer to the Hardware and Software Setup on page 20. -
Page 24: Hardware And Software Setup
800- x 600-pixel display resolution (ADS recommends 1024 x 768) Note: The Eureka Digital software should run effectively on most users PCs. However, ADS cannot guarantee that the software will operate free from errors on any computer that is not supplied by ADS for use with the Eureka Digital System. -
Page 25: Chapter 5 Eureka Digital Software
C H A P T E R 5 Eureka Digital Software ADS recommends reading this chapter to become familiar with the Eureka Digital Software. Launch the software from the Windows Start menu. A shortcut also may be created to launch the software directly from the... -
Page 26: Splash Screen
ADS Eureka Digital System User Manual Splash Screen The Eureka Digital splash screen displays for approximately 5 seconds, allowing the software to load. -
Page 27: Main Screen
ADS Eureka Digital System User Manual Main Screen The main window includes 4 areas: Main Menu Toolbar Display Area Control Area Main Screen without loaded data... -
Page 28: Main Menu
Selecting this option clears the current data and allows the user to set a new configuration as required. Open Selecting this option displays the Open dialog listing the data available for loading into Eureka Digital. To open the data, select the data and click on the Open button. - Page 29 ADS Eureka Digital System User Manual Open dialog When a data file is opened, a correlation is performed on the data. The user may drag and drop items to move them on the dialog as required. Holding down the Ctrl key while dragging and dropping creates a copy of the file.
- Page 30 ADS Eureka Digital System User Manual The following options are available: Cut Selecting this option cuts and places the selected item on a clipboard to be pasted. Copy Selecting this option copies the selected item. Delete Selecting this option deletes the selected item.
-
Page 31: Run Menu
ADS Eureka Digital System User Manual Typical Eureka Digital Test Report Exit Selecting this menu option closes the Eureka Digital Software. Run Menu The Run menu includes the following options:... -
Page 32: View Menu
ADS Eureka Digital System User Manual Start Selecting this option initiates the correlation process. Stop Selecting this option discontinues the current analysis. Analyze Selecting this menu re-analyzes a previous correlation result. It includes two options: Rapid Selecting the rapid option initiates re-correlation of the current data. This occurs quickly without playing the sounds and is followed by a display of the results. - Page 33 ADS Eureka Digital System User Manual Reverse Selecting this option swaps the red and blue transmitter positions. Toolbar This menu includes two options: Show and Hide. The option available depends on the current status of the toolbar. Selecting the available option either displays or hides the toolbar.
-
Page 34: Delayed Recording Menu
ADS Eureka Digital System User Manual Delayed Recording Menu This menu includes two options: Program Readback Program From this menu option, the user can set the transmitters to start recording after a designated delay and for a specific time. This is useful when it is not possible to maintain reception from the transmitters. - Page 35 ADS Eureka Digital System User Manual The user can unplug the transmitters and put them in the required location for recording. However, it is important to place the accelerometers correctly on the pipe. Note: Do not turn on the transmitter.
- Page 36 ADS Eureka Digital System User Manual The dialog shows the colored blocks corresponding to the transmitters connected to the y-cable. The dialog also displays the amount of data that is available. To initiate readback, click on the Next button. The dialog displays the readback progress. The red transmitter is read...
-
Page 37: Correlation Mode Menu
Three Transducers Select this option for leak location with automatic velocity measurement. ADS recommends this method. Three separate tabs are available, resulting in up to three correlations. The red, blue, and yellow transducers may be positioned in any order along the pipe. -
Page 38: Toolbar Buttons
ADS Eureka Digital System User Manual Toolbar Buttons The toolbar includes the following buttons: Button Function Description Open Opens the Open dialog (Refer to Open on page 24 for more information.) Saves the current data (Refer to Save on Save page 26 for more information.) -
Page 39: Display Area
ADS Eureka Digital System User Manual Display Area The display area includes the following information: Correlation Display Pipe Display Spectrum Display Tracker Correlation Display Correlation display After correlation is complete, the cursor displays above the best calculated peak. -
Page 40: Buttons
ADS Eureka Digital System User Manual Zoom Mode – This button indicates that Zoom Mode is selected. Click on the button to change to Peak Suppression Mode. Peak Suppression Mode – This button indicates that Peak Suppression Mode is selected. Click on the button to change to Zoom Mode. -
Page 41: Pipe Display
ADS Eureka Digital System User Manual This shows when a connection exists between the PC and the receiver. Pipe Display The pipe display shows the pipe and the transmitters in a schematic format, including the appropriate lengths of pipe and the pipe material. Set the pipe data using the pipe data tab. -
Page 42: Tracker
ADS Eureka Digital System User Manual Tracker The data tracker display develops throughout the correlation process. Over time, the line solidifies and changes color to indicate confidence in the correlation peak. Tracker Colors The colors of the dots represent the following: ... - Page 43 ADS Eureka Digital System User Manual Zoomed in Tracker display Select a specific area of the Tracker display with the mouse to perform a software correlation analysis for only the selected area. This can be beneficial in contexts such as high background noise or traffic areas for choosing a time period in which a correlation peak begins to form (e.g.,...
-
Page 44: Control Area
ADS Eureka Digital System User Manual Control Area The control area includes 3 tabs for managing the following: Pipe Filters Sound Pipe This option is designed for setting up the pipe network information. The top portion of the display shows the sections of pipe. -
Page 45: Quick Start
ADS Eureka Digital System User Manual Quick Start Enter the following for pipes made of one material with only one diameter, and then click Apply: Material Diameter Pipe length Add Pipe Note: Add pipe sections only when more than one pipe material or diameter exists. - Page 46 ADS Eureka Digital System User Manual Move Pipe Down To move a pipe down in the list, click on the pipe and then click on the down button as required. Moving a pipe down in the list moves it to the right in the main display.
- Page 47 ADS Eureka Digital System User Manual Restore Defaults Selecting this button restores the program defaults where changes have been made. Transducer Positions This section of the Pipe tab is for setting the transmitter information. Use each drop-down menu to select the appropriate transmitter color, from left to right, in the pipe network.
- Page 48 ADS Eureka Digital System User Manual Out-of-Bracket means the intentional leak exists at one of the sensor positions or beyond the length bracketed by the sensors, at either end. Between Sensors means the leak is reasonably close to the red or blue sensor, but within the bracketed length.
- Page 49 ADS Eureka Digital System User Manual The velocity value is then displayed and shown as calculated. The manufactured leak is then turned off, allowing for location of the unknown leak with improved accuracy. Note: Measuring velocity using this method does not account for more than one pipe material because it can only measure the average velocity over the given pipe length.
-
Page 50: Filters
ADS Eureka Digital System User Manual The outer pair of transducers displays. The user must select a second pair of transducers and ensure that the cursor is positioned correctly at the correlation peak (for both pairs of transducers selected). The calculated velocity and resulting (more accurate) leak position display. - Page 51 Auto filtering attempts to select the optimum filter settings. The Auto filter mode can often provide very good results. However, in certain cases, manual control of the filtering may be required. ADS does not recommend using Auto Filter with Hydrophones.
-
Page 52: Sound
ADS Eureka Digital System User Manual To apply filtering, click on the Apply button. To cancel the filter changes, click on the Reset button. Spectral Equalizer Selecting this option evenly distributes the power across the frequency spectrum to provide more equal weighting at every frequency. This often is a very effective tool for improving correlations. - Page 53 ADS Eureka Digital System User Manual...
-
Page 54: Chapter 6 Deployment
ADS Eureka Digital System User Manual C H A P T E R 6 Deployment This chapter contains general information on system deployment, such as selecting the appropriate type of transducer, installing the transducers, setting up the transmitters, and setting up the receiver unit. It also includes information regarding radio range, transducer distance, velocity, and filter settings. -
Page 55: Choosing The Transducer Type
ADS Eureka Digital System User Manual Choosing the Transducer Type Accelerometers (built-in or plug-in) are adequate for use under most conditions and offer simplicity and flexibility in deployment. Consider using hydrophones under the following conditions: Large diameter pipes (over 12 inches) ... -
Page 56: Attaching The Transducers
Note: ADS recommends removing the hydrant cap and allowing the hydrant to flow to clear out debris and stagnant water in the pipe prior to attaching the hydrophone hydrant cap assembly and re-pressurizing the hydrant for the survey. - Page 57 ADS Eureka Digital System User Manual 6. If no leakage exists, fully open the hydrant valve to completely charge (e.g., fill) the hydrant. Filling the hydrant applies pressure to the caps, including the hydrophone assembly, on the hydrant. 7. Slowly open the hydrophone bleed valve slightly to allow air to escape.
-
Page 58: Setting Up The Transmitters
ADS Eureka Digital System User Manual Setting up the Transmitters Set up a transmitter in the following way: 1. Attach the antenna. 2. Position the transmitter as required. 3. Turn on the transmitter by holding down the button for 2 seconds. -
Page 59: Setting Up The Receiver Unit
2. Connect the receiver to the computer via the USB cable 3. Launch the Eureka Digital software. The green LED should illuminate. If a problem exists with the USB connection or driver, the green LED will... -
Page 60: Radio Range
ADS Eureka Digital System User Manual Radio Range The manufacturer tests every system at a distance of 328 feet (100 m), line-of-sight at low power (25 mWatts), with a portable receiver antenna. Radio range increases considerably in the high power mode and when using a vehicle mount antenna. -
Page 61: Inter-Transducer Distance
ADS Eureka Digital System User Manual Inter-Transducer Distance An accurate inter-sensor distance is essential to locating leak positions accurately. The accuracy of a correlation result is a reflection of the accuracy of the distance measurement. Note: A user can record and save data without entering the inter- sensor distance. -
Page 62: Velocity
Typically, the sound velocity obtained automatically based on the pipe diameter and material entered by the user is adequate. However, ADS recommends always measuring the sound velocity in the pipe to reduce leak positioning errors. This can be done with either 2 or 3... -
Page 63: Filter Settings
Examining the data at another time or context provides a greater opportunity for applying the Frequency Analysis option to determine the optimal frequency band. Storing the data also allows the user to forward the files to ADS for further analysis, when necessary. -
Page 64: Chapter 7 Index
ADS Eureka Digital System User Manual C H A P T E R 7 Index Accelerometer, 12 General, 47 Accelerometers, 14 Getting Started, 19 Accelerometers, 52 Handle, 13 Add Pipe, 41 Hardware Requirements, 20 Adjust Sound, 28 Headphone Connector, 13... - Page 65 ADS Eureka Digital System User Manual Pipe Display, 37 Software Requirements, 20 Playback, 28 Sound, 48 Power Management, 20 Spectral Equalizer, 48 Principles of Leak Noise Spectrum Display, 37 Correlation, 7 Splash Screen, 22 Print, 26 Start, 28 Program, 30...
