Index Warnings Kit contents Speci cations Installation tools Before installation Manual release Installation Control panel Transmitter System learning LED indication Parameters Photocell Photocell mode...
***Do make sure the door has been fully opened and stopped before any person or vehicle to enter or exit the door area. TMT Automation Inc. is not responsible for any damage or injury to person or vehicle that enter or exit without door been stopped at fully open position.
Remote Push button Speci cation Model Power DC 24V Temperature 0°C~50°C Watt 120W Normal force 200N Max Pull Force 650N Door axle 35mm Max Drum Rotations 4 (approx. 3000mm) 6M x 3M=18M Max Door Area <60db Noise test Model P801U...
Installation tools Pen / Pencil Socket wrench Electric screwdriver Screwdriver Ladder Rope Door stand (not shown) Active wrench Long socket Before installation Please check the door status before installation. a. Make sure the door runs smoothly. b. Make sure the door is well maintained. c.
Installation Check the door must travel Put the weight bars equally apart smoothly and be easy to on the bottom rail of the door and operate by hand. fasten them with the small screws and nuts in (6) Installation kit. Secure a rope over the door Ensure the door axle U-Bolt and not at the bottom,...
Page 8
Refit the door mounting bracket Clamp the opener on the door axle to the wall. and door bracket in the marked If the door bracket needs to be position using the clamp assembly relocated due to opener width. supplied. Remove all ropes and the support Check the operation of the door in stand.
Transmitter ***If you have more than 1 remote to memory, follow the above procedure within the CS period.*** Transmitter Memorizing Press “RF Learn” button for 3 seconds, and the display will show “CS”; then press the transmitter button A within 10 seconds; the “CS” will blink three times and show “CS”. After 10 seconds without any movement, “CS”...
System learning ***Before start the system learning procedure, do make sure the motor installation direction, default is F1-1 on the right .*** System Learning a. LED display show “N-L” when didn’t system learning yet. b. Press “RF” & “SET” button together for 3 seconds and the LED display show ‘’OL’’...
Page 12
d. LED display show ‘’CL’’ to set CLOSE limit, press ‘’DOWN’’ to close the door to the desire close position, and press ‘’SET’’ button to con rm the CLOSE limit. e. LED display show ‘’GE’’ to do the automatic testing run, press ‘’SET’’ to start, and the door will open and close automatically.
NOTICE Please follow bellow instructions, while encountering power outage and power restored. • Please press the remote button and the system will calibrate automatically. The system will go through the grating in order to locate itself and continue opening or closing. •...
Parameters Parameter setting Step 1: Press “SET “ for 3 seconds, the display will show the function code. Step 2: Choosing the setting by “UP” and “DOWN “, after having chosen the indicated item, press “SET “and enter the setting of this function. The second digit will be shown on the right of the display, indicating the related function ( please refer below chart for details ).
Page 15
LED display De nition Parameter Table Description No function F4-0 Open/Stop/Close/Stop F4-1 Default setting is F4-0 LED light F4-2 C button F4-5 function is EXT button F4-3 controlled by FK F4-4 Condominium mode (Open only) Ventilation mode F4-5 No function F5-0 Open/Stop/Close/Stop F5-1...
Page 16
LED display De nition Parameter Table Description Stop when over-current while Default setting is FA-2 FA-1 opening and closing. The buzzer rings for 5 seconds. The system will close Over-current auto-closing when reaction encountering Stop when over-current while opening. Buzzer rings for 5s and stop. over-current untill FA-2 Stop and reverse to open when...
Page 17
LED display De nition Parameter Table Description FI-1 1.0 Second Ramp FI-2 1.5 Second Ramp FI-3 2.0 Second Ramp FI-4 2.5 Second Ramp Default setting is FI-4 FI-5 Soft start 3.0 Second Ramp FI-6 3.5 Second Ramp FI-7 4.0 Second Ramp FI-8 4.5 Second Ramp FI-9...
Response time 100MS Emitting element Infrared LED/ Wave Length:940nm Operation indicator RX:Red LED On (beam broken) / Off (beam aligned) TX:Red LED On Dimentions 63x63x30mm Output method Relay output Current consumption max Beam aligned:RX<25ma\TX<30ma Beam broken:RX <10ma\TX <30ma IP44 Water proof...
Page 19
Photocell connection Power LED inicator Lens N.O. N.C. Terminal block N.C. TX. Connect the DC+ of the TX to the +24V. N.O. Connect GND of the TX to GND. RX. Connect the DC+ of the RX to the +24V. Connect the GND of the RX to GND. Connect the N.C.
Photocell mode F6-1 Gate status Action when photocell is triggered No e ect Fully closed Open and close not allowed and waiting for the next commend. Fully open Reload auto-closing time when the obstacle is removed. Open and close not allowed and waiting for the next commend. Stop in the middle Reload auto-closing time when the obstacle is removed.
Page 21
F6-4 Gate status Action when photocell is triggered Fully closed No e ect Fully open Open and Close not allowed and waiting for the next commend. Reload auto-closing time when the obstacle is removed. Stop in the middle Close not allowed and waiting for the next commend. Reload auto-closing time when the obstacle is removed.
