  • Page 1 AMOS SERIES Garage Door Openers USER MANUAL...
  • Page 3 WARNING : Please read this instruction manual carefully before the installation. This manual is exclusively for qualified install ation personnel. TMT Automation Inc. is not responsible for improper installation and failure to comply with local electrical and building regulations. Keep all the components of garage opener system and this manual for further consultation.
  • Page 4: Description Of The Automation

    2. PRODUCT DESCRIPTION 2.1 APPLICATIONS Garage door opener is applied for residential automation of up and over doors and sectional doors and has to be operated with electricity and it’s forbidden to be operated by back-up batteries for normal use.Back-up batteries are only allowed for emergent operation when there is a power failure, and the carriage can be released by pulling the cord to move the door manually.
  • Page 5 3. Installation 3.1 Inventory of a garage door opener C Rail Front hold Rear Pulley Support Front Pulley Release Rope Tensioner Door Bracket Ceiling Bracket Header bracket Bent Arm Straight Arm Bracket Bracket Hardware Inventory Door Bracket Locator Ceiling Support Bracket Blocker x1 Locking Screws...
  • Page 6: Rail Assembly

    3.2 Rail assembly Assemble the front and middle rail with the junction, and make sure is located at the middle of the protruding point. Assemble the back and middle rail with another junction, and make sure is located at the middle of the protruding point.
  • Page 7 3.3 Attach the rail to the motor 1. Connect the (3) Rear pulley support to the output shaft of the motor. 2. Fasten the rail on the motor with (9) Motor hold bracket and the (25) Hex nuts. 3. Fasten the (10) Ceiling hold bracket and (13) Ceiling bracket at the rear side between the motor and the rear blocker with Hex bolt (21) and Hex nuts (24).
  • Page 8: Connect Door Arm To Trolley

    3.5 Connect release section to the garage door WARNING Connect the (7) Release rope on the (8) Outer trolley assy To prevent possible SERIOUS INJURY or DEATH from a falling Secure handle with overhand knot garage door: ENGAGED and heat seal rope. •...
  • Page 9 3.6 Final steps before system learning 1. Install the (18) Blocker on the door open position. 2. Attached the warning sign to the (7) release rope. 3. Connect the power to the motor. Make sure the electric plug and socket are well connected. WARNING Blocker To prevent possible SERIOUS INJURY or DEATH from...
  • Page 10: Accessories Connection

    4.2 Door position for start-up phase 1. Connect the plug.If necessary, use a commercial adaptor if the plug on the AMOS Series unit does not correspond to the socket available.As soon as the system is powered, you should check the LED in the display. Make sure the LED display is ON.
  • Page 11 4.3 Transmitter memorizing and erasing process A. Transmitter Memorizing: Press “RF Learn” button for 3 seconds, and the Display will show “CS”; then press the transmitter A button within 10 seconds; the“CS” will blink three times and show “CS”. After 10 seconds without any movement, “CS”...
  • Page 12 3 SEC Step.1 Step.2 Step.3 Step.4 B. Restore Default Setting: Press “RF” and “DOWN” buttons for 3 seconds, and the LED display shows “CL” to recover the default settings. Default Setting 3 SEC C. Motor current auto-detection The LED display shows the current consumption of the motor During the system learning procedure, the control panel will automatically detect the current consumption from each motor, indicate the resistance level of the gate whiling the motor operation.
  • Page 13 4.5 Programmable function indication led LED Display Programmable Functions LED Display Programmable Functions Start transmitter learning mode. Operation testing Cleaned all studied transmitter. System Learning Fail. Set up Open Limit. System Learning Completely. Set up Close Limit. System setting clear 4.6 How to set the parameter: Step 1: Press the“Set”...
  • Page 14 4.7 Programmable function setting LED Display Definition Function Value Description Deceleration Point 1.The default setting is "1-3" (% full operation) Main Operation Key Function off 1.The default setting is "2-1" A Key B Key C Key D Key Function off 1.The default setting is "3-2"...
  • Page 15 LED Display Definition Function Value Description Overcurrent setting of open 2A as overcurrent value of open limit 1. The default setting is "C-3" limit 3A as overcurrent value of open limit 4A as overcurrent value of open limit 5A as overcurrent value of open limit 6A as overcurrent value of open limit 7A as overcurrent value of open limit 8A as overcurrent value of open limit...
  • Page 16: Specification

    5.2 Installation of Photocell The safety photocells are security devices for control automatic gates. Consist of one transmitter and one receiver based in waterproof covers; it is triggered while breaking the path of the beams. SPECIFICATION: Detection Method Through Beam Sensing Range MAX~15m Input Voltage...
  • Page 17 6. Specification Garage Door Opener AMOS80 AMOS120 Volt AC 220V / 110V ; AC 220V / 110V ; 50Hz~60Hz 50Hz~60Hz Motor volt DC24V DC24V Power 120W Force 800N 1200N Remote frequency 433.92MHZ 433.92MHZ Max door area 10-12m² 14-16m² Temperature range C ~ +50 C ~ +50 Rail length...
  • Page 18 What you need when installing: • Wi-Fi: The home Wi-Fi reception has to be stable, and the login username and password of your home Wi-Fi are required. • Smart Devices: One of the devices is required, an IPhone 5 or later, a device using iOS8.0 or later, or Android 4.2 or later.
  • Page 19 STEP 5:Set Pin code for the first connection. Pin STEP 6:Connect to an accessible wireless network code will be needed for authorization and advanced setting. None English SSID can not be shown on this page connect to avaliable Wi-Fi Press Set and start 60 sec countdown LED Status: The Red LED will blink when LED Status: The LED turn Green when the...
  • Page 20 8. Accessories TM3 Transmitter Frequency 433.92Mhz Coding Rolling code Buttons 4 buttons Power Supply 3V with one CR2032 button type lithium battery Operating Temperature -20°C~+50°C Dimension 37*67.5*12 (mm) FL2 Flashing Light Voltage 24V DC Operating Temperature -20°C~+50°C Installation Horizontally or vertically installed Dimension 74*167*58.4 (mm) H2 Photocells...

This manual is also suitable for:

Amos80Amos120
