SERVICE MANUAL
VP/GD930

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VP930 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nilfisk-Advance VP930 Series

  • Page 1 SERVICE MANUAL VP/GD930...
  • Page 2 Index A. Safety issues B. Technical data C. Construction D. Service / repair Spare parts Electrical diagrams...
  • Page 3 Preface In this manual you will find A fault in the equipment Technical information sheets are a supplement to the spare the essentials you need to can have a number of causes. parts list until a follow-on publi- know when repairing dry vacu- cation.
  • Page 4: Safety Issues

    Safety issues Observe national safety directives and regulations For your own safety. for the electrical engineer- ing trade, in particular: IEC 60335-2-69 EN 60335-2-69 DIN VDE 105 part 1: operation of electrical power installations. DIN VDE 0701/0702: repair, modification and Repairs should only be testing of electrical installa- made by someone who has...
  • Page 5: Technical Data

    Technical data VP/GD 930 - all variants For JP Version Unit VP930 ECO VP930 GD930 GD930 S2 Rated power 1000 1000 Protection grade (moist, dust) IP20 IP20 IP20 IP20 Protection class (electrical) Airflow Suction power (end of tube) Working sound level (2m) dB(A) Sound Pressure Level (IEC 60335-2-69) dB(A)
  • Page 6 Construction Unless otherwise stated use a screwdriver with a TX20-bit for Carrying handle assembly and disassembly. Power sockets On-Off button Dual speed button Latches for opening top On/off switches Power sockets Hepa filter in top...
  • Page 7: Service & Repair

    Service / repair 1. Replace PCBA s 2. Replace Motor 3. Replace Switches & Power Socket 10 4. Spare Parts 5. Wiring Diagrams...
  • Page 8 PCBA WARNING: The lower section of the machine contains live components. Contact with live components leads to serious or even fatal injuries. Always disconnect the mains plug before disassembly. Unscrew the bottom cover (fig.1). Paying attention to which wire that go to which connector on the PCBA (antistatic and/or speed) disconnect the PCBA (antistatic and/or speed) (fig.2 - 4).
  • Page 9 Motor WARNING: The lower section of the machine contains live components. Contact with live components leads to serious or even fatal injuries. Always disconnect the mains plug before disassembly. Unscrew the bottom cover as shown in Section D.1. Unscrew the motor cover (fig.1). Disconnect the motor wires (fig.2).
  • Page 10: Power Socket

    Switches WARNING: The lower section of the machine contains live components. Contact with live components leads to serious or even fatal injuries. Always disconnect the mains plug before disassembly. Unscrew the bottom cover as shown in Section D.1. Disconnect the wires for the app- ropriate switch and the replace the switch (fig.1).
  • Page 11 Spare parts Top and container...
  • Page 12 Spare parts Motor, filter and electrics...
  • Page 13 Electrical diagrammes Diagram no. 107420619 for following models: 107420633, 107420771, 107420659...
  • Page 14 Electrical diagrammes Diagram no. 107420780 for following models: 107420622, 107420627, 107420628, 107420629, 107420634.
  • Page 15 Electrical diagrammes Diagram no. 107420836 for following models: 107420772, 107420779, 107420773, 107420774...
  • Page 16 Electrical diagrammes Diagram no. 107420837 for following models: 107420770, 107420777, 107420778...
  • Page 17 Electrical diagrammes Diagram no. 107420838 for following models: 107420776...
  • Page 18 Electrical diagrammes Diagram no. 107420839 for following models: 107420775...
