INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
TREKKER FREE STANDING PELLET
APPLIANCE
MODEL(S):
TREKKER-MBK
TREKKER-PMH
TREKKER-TWL
Check building codes prior to installation.
• Installation MUST comply with local, regional, state
and national codes and regulations.
• Consult local building, fire officials or authorities
having jurisdiction about restrictions, installation
inspection, and permits.
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
For Units Post Serial # HF3156001
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
CAUTION
R
If the information in these instructions is
not followed exactly, a fire could result
causing
injury, or death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not over fire - If appliance or chimney connector
glows, you are over firing. Over firing will void
your warranty.
• Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room
as fireplace.
• Alert
children
high temperatures
• High temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other
flammable materials away.
Tested and approved for wood pellets only. Burning of
any other type of fuel voids your warranty.
NOTE: To obtain a French translation of this manual,
please contact your dealer or visit www.quadrafire.com
REMARQUE : Pour obtenir une traduction française de
ce manuel, s'il vous plaît contacter votre revendeur ou
visitez www.quadrafire.com
7080-802C
WARNING
property
damage,
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down. Hot
glass will cause burns.
and
adults
to
CAUTION
personal
hazards
of
08/21
Advertisement
Table of Contents
Related Manuals for Hearth and Home Technologies Quadra-Fire TREKKER-MBK
Summary of Contents for Hearth and Home Technologies Quadra-Fire TREKKER-MBK
- Page 1 Installation Manual Installation & Appliance Set-Up INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instructions is TREKKER FREE STANDING PELLET not followed exactly, a fire could result causing property...
-
Page 2: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. • NOTICE: Indicates practices which may cause damage to the appliance or to property. TABLE OF CONTENTS 1 Important Safety Information 5 Venting Systems A. Appliance Certification ......3 A. Through The Wall......17 B. BTU & Efficiency Specifications . -
Page 3: Important Safety Information
Important Safety Information A. Appliance Certification B. BTU & Efficiency Specifications EPA Certification Number: Number: 98-17 Model: Trekker Pellet Stove EPA Certified Emissions: 0.74 grams per hour Laboratory: OMNI Test Laboratories, Inc. *LHV Tested Efficiency: 83.2% Report No: 061-S-83-2, 0061PS094E **HHV Tested Efficiency: 77.9% Solid Fuel Room Heater, Pellet Fuel Type: Burning Type ***EPA BTU Output: 12,682 to 39,428 / hr. -
Page 4: Glass Specifications
C. Glass Specifications I. California - Prop65 This appliance is equipped with 5mm ceramic glass. WARNING Replace glass only with 5mm ceramic glass. Please contact your dealer for replacement glass. This product and the fuels used to operate this product (wood), and the products of combustion of such fuels, can expose you to D. -
Page 5: Getting Started
Getting Started A. Design, Installation & Location Considerations Since pellet exhaust can contain ash, soot or sparks, you must consider the location of: NOTICE: Check building codes prior to installation. • Windows • Air Intakes 1. Appliance Location • Air Conditioner • Installation MUST comply with local, regional, state and • Overhang, soffits, porch roofs, adjacent walls national codes and regulations. • Landscaping, vegetation • Consult insurance carrier, local building inspector, fire officials or authorities having jurisdiction over restrictions, • Horizontal or vertical vent termination installation inspection and permits. 2. Floor Support It is a good idea to plan your installation on paper, using The supporting floor under the appliance must be able to exact measurements for clearances and floor protection,... -
Page 6: Tools And Supplies Needed
WARNING C. Inspect Appliance and Components • Open the appliance and remove all the parts and articles packed inside the Component Pack. Inspect all the parts Risk of Fire! and glass for shipping damage. • Damaged parts could impair safe operation. • Do NOT install damaged, incomplete or • Report to your dealer any parts damaged in shipment. substitute components. • All labels have been removed from the glass door. • Plated surfaces have been wiped clean with a soft cloth, if applicable. WARNING • Read all the instructions before starting the installation. Follow these instructions carefully Hearth &... -
Page 7: Install Checklist
E. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual. __________________________________________________________________________ Customer: ______________________________________________________________________ Date Installed: _______________________________________________________________________ Lot/Address: ________________________________________________________________ Location of Appliance:... -
Page 8: Dimensions And Clearances
Dimensions and Clearances A. Appliance Dimensions 5-13/16 in 14-1/16 in 3-3/4in (147mm) (95mm) (357mm) 3-5/8 in 3-5/8 in 10-3/8 in 10-3/8 in (93mm) (93mm) (264mm) (264mm) 2-9/16 in (65mm) Figure 8.4 - Top View with Top Vent Adapter (TPVNT-3) and Offset Adapter (812-3570). Figure 8.1 - Top View 10-3/8 in 10-3/8 in (264mm) (264mm) 14 in (357mm) 3-3/4 in 4-1/8 in... - Page 9 28-3/4 in (730mm) 26-7/8 in (683mm) 27-1/8 in 27-1/8 in (688mm) (688mm) 25-3/8 in 25-3/8 in 19-9/16 in (646mm) (646mm) (497mm) 20 in (508mm) Figure 9.4 - Side View with Top Vent Adapter (TPVNT-6) and Figure 9.1 -Side View Offset Adapter (811-0720). 31-1/16 in (788mm) 29-3/16 in (741mm)
-
Page 10: Clearances To Combustibles (Us & Canada)
B. Clearances to Combustibles (US & Canada) Installations with: TPVNT-3 Top Vent Adapter with Heat Shield and Clean-out TPVNT-6 Top Vent Adapter with Clean-out 811-0720 (3” to 4”) Offset Adapter 812-3570 (3” to 6”) Offset Adapter Horizontal Through the Wall Inches Millimeters A Back Wall to Appliance... -
Page 11: Hearth Pad Requirements (Ul & Ulc)
C. Hearth Pad Requirements (UL & ULC) USA INSTALLATIONS: A non-combustible floor protection is recommended Use a non-combustible floor protector, extending beneath extending beneath the flue pipe when installed with appliance and to the front, sides and rear as indicated. horizontal venting or under the Top Vent Adapter with Measure front distance from the surface of the glass door. -
Page 12: Alcove
D. Alcove Figure 12.1 Minimum* Maximum Inches Millimeters Inches Millimeters Height 1092 Figure 12.2 Width 1016 Depth To Side Wall *All minimums listed are to a combustible surface. NOTE: • Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. • Illustrations/diagrams are not drawn to scale. • Actual installation may vary due to individual design preference. -
Page 13: Vent Information
Vent Information A. Venting Termination Minimum Requirements Electrical Service Inside Corner FIXED FIXED OPEN CLOSED CLOSED OPEN J or K Termination Cap Restricted Area Air Supply Inlet Gas Meter All minimum clearances are listed with an Outside Air Kit (OAK) installed, unless otherwise noted in table below. 12 in. -
Page 14: Avoiding Smoke And Odors
B. Avoiding Smoke and Odors Vent Configurations When installing a pellet appliance with a horizontal vent Negative Pressure, Shut-Down Electrical configuration the frequency of power outages should Power Failure be considered: To reduce the probability of back-drafting or burn-back • Power outages during operation will cause the appliance in the pellet appliance during power failure or shut down to immediately turn off and may create conditions where conditions, it must be able to draft naturally without exhaust... -
Page 15: Negative Pressure
C. Negative Pressure NOTICE: Hearth & Home Technologies assumes no responsibility for the improper performance of the WARNING chimney system caused by: • Inadequate draft due to environmental conditions Risk of Asphyxiation! • Down drafts Negative pressure can cause spillage of combustion • Tight sealing construction of the structure fumes and soot • Mechanical exhausting devices E. Chimney and Exhaust Connection Negative pressure results from the imbalance of air available for the appliance to operate properly. It can be strongest in 1. Chimney &... -
Page 16: Equivalent Feet Of Pipe
F. Equivalent Feet of Pipe WARNING The table below can help you calculate the equivalent feet of pipe which is a method used to determine pellet vent size Vent surfaces get HOT, can cause burns (Figure 16.1). if touched. Non-combustible shielding or guards may be required. Example of 3 Elbow - Rear Vent Termination Calculation Pellet # of Feet Multiplied Equivalent Components 2 ft. Venting Elbows Feet Equivalent Component Pipe Feet 90° Elbow or 3 ft. -
Page 17: Venting Systems
Venting Systems A. Through The Wall 45 Degree Horizontal termination cap must be a minimum of 6 inches. (152mm) from the wall. Approved for mobile home Illustration shows venting going in both directions. Choose which one is best for your installation. installations. Must use 3 or 4 inch (76-102mm) “L” or “PL” Listed pellet venting or Listed double wall pipe and a 6 in. -
Page 18: Vertical Into Existing Class A Chimney
B. Vertical into Existing Class A Chimney C. Through The Wall & Vertical - Exterior We recommend a minimum of 60 inches (1524mm) vertical, however above the eave is preferred. Rain All three installations are approved for mobile home installations. Must use 3 or 4 inch (76 to 102mm) “L” or “PL” Listed pellet venting or Listed double wall pipe and 12 in Flashing Quadra-Fire Outside Air Kit in mobile homes. Single wall... -
Page 19: Masonry
E. Masonry Fireclay Flue Liner Concrete Cap with airspace Flashing 1 in [25mm] clearance 1 in [25mm] clearnance with firestop 3 in [76mm] min to 6 in combustible material [152mm] Sheathing Clean-out cover Airtight clean-out door Non-combustible Hearth Pad Figure 19.1 F. -
Page 20: Appliance Set-Up
Appliance Set-Up A. Leg Leveling System B. Outside Air Kit Instructions 1. Thread Allen bolts through nuts until flush (Figure 20.1). CAUTION The Allen bolts and nuts are included in the component pack inside the appliance firebox. Never draw outside combustion air from: 2. Slide assembled nuts and bolts into slots on legs with • Wall, floor or ceiling cavity the nuts on the bottom (Figure 20.2). Use a 5/32 in. -
Page 21: Top Vent Adapter Installation
C. Top Vent Adapter Installation 3 to 3 inch (76-76mm) Top Vent Adapter 3 to 6 inch (76-152mm) Top Vent Offset Adapter Installing the Top Vent Adapter 1. Put a layer of high temperature silicone on the 3 inch (76mm) exhaust outlet. Do not put silicone inside of pipe (Figure 21.1). -
Page 22: Optional Log Set Placement Instructions
E. Optional Log Set Placement Instructions 2 PIECE LOG SET INSTALLATION 1. Place the left log as shown. There are 2 indentations in the bottom of the log to fit over the screw heads in the firebox (Figures 22.1 and 22.2). Right Log 2. Place the right log in front of the 2 screw heads in the firebox (Figures 22.3 and 22.4). CAUTION Logs are FRAGILE. Use extreme care when handling or Log rests in front of screws cleaning logs. Figure 22.3 Left Log Log fits over screws Figure 22.1 Figure 22.4... -
Page 23: Thermostat Installation And Operation
F. Thermostat Installation and Operation The kit comes with a programmable wall thermostat and 25’ of thermostat wire. If you need to run more than 25’ make sure you use a continuous strand of 18 to 22 gauge thermostat wire. For optimum performance your thermostat should be: • Mounted on an inside wall, approximately 5’ above the floor • Do not locate where there is poor air circulation such as in a corner, alcove, behind doors, bookcase or other objects Appliance • Located away from drafts, direct sunlight, above a lamp, television, radiator, a wall next to a window, or direct heat Figure 23.2 from the appliance NOTE: Ensure bare wire ends are held ALL the way into • Avoid damp environments as this can lead to corrosion... -
Page 24: Mobile Home Installation
Mobile Home Installation You must use a Quadra-Fire Outside Air Kit for CAUTION installation in a mobile home. 1. An outside air inlet must be provided for the combustion THE STRUCTURAL INTEGRITY OF THE MOBILE air and must remain clear of leaves, debris, ice and/or HOME FLOOR, WALL AND CEILING/ROOF MUST snow. It must be unrestricted while the appliance is in BE MAINTAINED use to prevent room air starvation which causes smoke... -
Page 25: Reference Materials
Reference Materials A. Service and Maintenance Log Date of Service Performed By Description of Service 7080-802C 08/21... - Page 26 Date of Service Performed By Description of Service 7080-802C 08/21...
-
Page 27: Accessories List
812-1180 IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Stocked Hearth and Home Technologies does not sell directly to consumers. Provide model number Exhaust Probe SRV7000-669 and serial number when requesting service parts from your dealer or distributor. - Page 28 CONTACT INFORMATION Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL •...
