Hearth and Home Technologies Quadra-Fire 27I-ACC Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
2700 INSERT ACC WOOD INSERT
Automatic Combustion Control (ACC)
Model(s):
27I-ACC
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfi re and generate
poisonous gases (i.e. carbon monoxide).
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies recommends NFI certifi ed profession-
als, or technicians supervised by an NFI certifi ed
professional.
1
All manuals and user guides at all-guides.com
Owner's Manual
Operation & Care
Tested and
Portland
O-T L
Oregon USA
Listed by
C
US
OMNI-Test Laboratories, Inc.
7046-191C
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re - If heater or chimney con-
nector glows, you are overfi ring. Overfi ring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fi replace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
fl ammable materials.
•
Keep clothing, furniture, draperies and other fl ammable
materials away.
NOTE
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafi re.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez www.quadrafi re.com
April 30, 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quadra-Fire 27I-ACC and is the answer not in the manual?

Questions and answers

Related Manuals for Hearth and Home Technologies Quadra-Fire 27I-ACC

Summary of Contents for Hearth and Home Technologies Quadra-Fire 27I-ACC

  • Page 1 All manuals and user guides at all-guides.com Owner’s Manual Operation & Care INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. Contact your dealer with questions on installation, operation, or service. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instruc-...

  • Page 2: Congratulations

    All manuals and user guides at all-guides.com 27I-ACC and Welcome to the Quadra-Fire Family A. Congratulations tion of our stoves, inserts and fi replaces. And yet we are Hearth & Home Technologies welcomes you to our tradition old-fashioned when it comes to craftsmanship. Each unit of excellence! In choosing a Quadra-Fire appliance, you is meticulously fabricated and gold and nickel surfaces are have our assurance of commitment to quality, durability, and...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com 27I-ACC Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury. •...

  • Page 4: Warranty

    All manuals and user guides at all-guides.com 27I-ACC C. Warranty Hearth & Home Technologies Inc. LIMITED LIFETIME WARRANTY Hearth & Home Technologies Inc., on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance...
  • Page 5 All manuals and user guides at all-guides.com 27I-ACC WARRANTY CONDITIONS: ‡ 7KLV ZDUUDQW\ RQO\ FRYHUV ++7 DSSOLDQFHV WKDW DUH SXUFKDVHG WKURXJK DQ ++7 DXWKRUL]HG GHDOHU RU GLVWULEXWRU $ OLVW RI ++7 DXWKRUL]HG GHDOHUV LV DYDLODEOH RQ WKH ++7 EUDQGHG ZHEVLWHV ‡...

  • Page 6: Quick Start Guide

    All manuals and user guides at all-guides.com 27I-ACC D. Quick Start Guide Note: These are generic drawings and may not represent your specifi c model. 10 Pieces of Newspaper, 10-20 Pieces of Dry Kindling ITEMS NEEDED FOR FIRST FIRE: and a Few Pieces of Dry Split Wood. OPEN AIR CONTROLS ADD NEWSPAPER LOAD WOOD...

  • Page 7: Listing And Code Approvals

    All manuals and user guides at all-guides.com 27I-ACC Listing and Code Approvals C. Mobile Home Approved A. Insert Certifi cation • This appliance is approved for mobile home installa- 2700-I (ACC) Insert Model: tions when not installed in a sleeping room and when OMNI Test Laboratories, Inc.

  • Page 8: Operating Instructions

    All manuals and user guides at all-guides.com 27I-ACC User Guide Operating Instructions WARNING HOT SURFACES! Glass and other surfaces are hot during operation AND cool down. Hot glass will cause burns. • DO NOT touch glass until it is cooled •...

  • Page 9: Fire Safety

    All manuals and user guides at all-guides.com 27I-ACC B. Fire Safety To provide reasonable fi re safety, the following should be given • Contact your local chimney professional and have your serious consideration: stove and stove pipe inspected for any damage. •...

  • Page 10: Burning Process

    All manuals and user guides at all-guides.com 27I-ACC 2. Second Stage F. Burning Process In recent years there has been an increasing concern about In the secondary stage wood gives off fl ammable gases which air quality. Much of the blame for poor air quality has been burn above the fuel with bright fl...

  • Page 11: Automatic Combustion Control (Acc)

    All manuals and user guides at all-guides.com 27I-ACC G. Automatic Combustion Control (ACC) Typically, when you build a fi re, you open the air controls fully and monitor the fi re to prevent it from going into an overfi re situation and/or burning your wood up too quickly before you Burn Rate shut down the air controls to the desired burn rate.

  • Page 12: Burn Rates And Operating Effi Ciency

    All manuals and user guides at all-guides.com 27I-ACC 3. Burn Rate Air Control 4. Medium-Low Burn Rate - 10,000 to 15,000 BTU/hr* • The air supply enters at the upper front of the fi rebox, • Raise the Burn Rate Air Control up to the bottom of the near the top of the glass door.

  • Page 13: Correct Baffl E & Blanket Placement

    All manuals and user guides at all-guides.com 27I-ACC J. Correct Baffl e & Blanket Placement INCORRECT POSITIONS WARNING Fire Risk Improper baffl e placement may cause: • Overheating of fi rebox • Overheating the chimney Baffl e must be placed properly (see instructions) Replace baffl...

  • Page 14: Building A Fire

    All manuals and user guides at all-guides.com 27I-ACC K. Building A Fire 10. When ready to reload, It is best to fully open both the Burn Rate Air and Start-up Air Controls before reloading. • This livens up the coalbed and reduces excessive WARNING emissions (opacity/smoke).

  • Page 15: Wood Fuel

    All manuals and user guides at all-guides.com 27I-ACC L. Wood Fuel WARNING Fire Risk. WARNING Do NOT burn wet or green wood. • Store wood in dry location. • Fire Risk. Stack wood so both ends are exposed to air. •...

  • Page 16: Operating The Blower Control Box With Snap Disc

    All manuals and user guides at all-guides.com 27I-ACC M. Operating the Blower Control Box with Snap Disc 1. The blower will turn on/off automatically when MANUAL: Over-rides the set to AUTO. Figure 16.1. internal Snap Disc 2. When set to MANUAL, the fan will turn on/off only when you turn it on or off.

  • Page 17: Clear Space

    All manuals and user guides at all-guides.com 27I-ACC Q. Opacity (Smoke) O. Clear Space Opacity is the measure of how cleanly your appliance is • Do NOT place combustible objects within 4 ft (1.2 m) of burning. the front of appliance. Figure 17.1. Opacity is measured in percent: •...

  • Page 18: Maintenance And Service

    All manuals and user guides at all-guides.com 27I-ACC Maintenance and Service When properly maintained, your fi replace will give you many years Creosote - Formation and Need for Removal of trouble-free service. Contact your dealer to answer questions • When wood is burned slowly, it produces tar and other regarding proper operation, troubleshooting and service for your organic vapors, which combine with expelled moisture to appliance.

  • Page 19: Glass Cleaning

    All manuals and user guides at all-guides.com 27I-ACC E. Glass Cleaning F. Inspect Firebrick Frequency: As desired Frequency: After each ash removal • • By: Homeowner By: Homeowner • • Replace the fi rebrick if they become crumbly and/or if there •...

  • Page 20: Quick Reference Maintenance Guide

    All manuals and user guides at all-guides.com 27I-ACC Start the fi rst inspection after the fi rst 2 months of use, or if G. Quick Reference Maintenance Guide performance changes, and adjust your schedule according- ly. Maintenance is required for safe operation and must be CAUTION! Allow the appliance to completely cool performed to maintain your warranty.

  • Page 21: Troubleshooting Guide

    All manuals and user guides at all-guides.com 27I-ACC Troubleshooting Guide With proper installation, operation, and maintenance your wood stove will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualifi ed service person in the diagnosis of a problem and the corrective action to be taken.

  • Page 22: Service Parts Replacement

    All manuals and user guides at all-guides.com 27I-ACC Service Parts Replacement A. Glass Replacement - Door Assembly B. Blower Replacement (Replace with 5mm ceramic glass only) 1. Using a 5/32 Allen wrench, remove 4 blower housing Ensure that the fi re is out and the appliance is cool to mounting bolts and slide assembly out.

  • Page 23: Snap Disc Replacement

    All manuals and user guides at all-guides.com 27I-ACC C. Snap Disc Replacement D. Door Handle Assembly 1. The snap disc bracket assembly is located on top of the 1. Install washer on door handle shaft. blower housing in the center. Figure 23.1. 2.

  • Page 24: Baffl E & Ceramic Blanket Removal

    All manuals and user guides at all-guides.com 27I-ACC E. Baffl e & Ceramic Blanket Removal 1. Remove all ash from the fi rebox, and extinguish all hot embers before disposal into a metal container. 2. It is easier to remove both baffl e boards and ceramic blanket after the tube channel assembly has been partially disassembled and the right side lowered.

  • Page 25: Tube Channel Assembly Replacement

    All manuals and user guides at all-guides.com 27I-ACC F. Tube Channel Assembly Replacement Removing Tube Channel Assembly 1. Remove the 3 bottom bricks fi rst and then remove the 3 Bend Back Tabs right side bricks. 2. Remove the baffl e protection channel by bending back Baffle Protection the tabs using needle nose pliers located at the right and Channel...

  • Page 26: Reference Materials

    All manuals and user guides at all-guides.com 27I-ACC Reference Materials A. Service & Maintenance Log Date of Service Performed By Description of Service 7046-191C April 30, 2015...

  • Page 27: Service Parts & Accessories

    All manuals and user guides at all-guides.com 27I-ACC B. Service Parts & Accessories 27i ACC Service Parts Wood Stove Insert Beginning Manufacturing Date: Nov. 2009 Advanced Combustion Control Ending Manufacturing Date: Active Part number list on following page. 04/15 April 30, 2015 7046-191C...
  • Page 28 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 29 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 30 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 31 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 32 All manuals and user guides at all-guides.com CONTACT INFORMATION Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi...
