Page 1 Operator’s Manual Utility Track Loader SM100 / SM120 Machine Type This Operator‘s Manual includes the AEM Safety Manual Material Number 5100064108 / 3300031444 Version Date 07/2024 Language [en-US]...
Page 2 Imprint Publisher and copyright holder: Wacker Neuson America Corporation N92W15000 Anthony Ave Menomonee Falls, WI 53051, USA www.wackerneuson.us Original instructions All rights reserved, in particular the copyright, the right of reproduction and the right of distribution applicable worldwide. This document may be used by the recipient only for the designated purpose. It may in no way be duplicated or translated in any other language, in whole or in part, without prior permission in writing from the manufacturer.
Page 3 California Proposition 65 Warning WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other repro- ductive harm. WARNING Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproduc- tive harm.
Page 4 EC Declaration of Conformity Manufacturer Wacker Neuson America Corporation, N92W15000 Anthony Avenue, Menomonee Falls, Wisconsin, 53051 USA Product Product SM100 Product Category Mini Compact Tracked Loader Product function Loading, excavating, and transporting material Item Number 1000530600 Power in kW at nominal speed min-1 18.4 / 2700 Measured sound power level 101 dB(A)
Page 5 UKCA Declaration of Conformity Manufacturer Wacker Neuson America Corporation, N92W15000 Anthony Avenue, Menomonee Falls, Wisconsin, 53051 USA Product Product SM100 Product Category Mini Compact Tracked Loader Product function Loading, excavating, and transporting material Item Number 1000530600 Power in kW at nominal speed min-1 18.4 / 2700 Measured sound power level 101 dB(A)
Page 6 This page is intentionally left blank.
Page 7: Table Of Contents
Towing the Machine .......................... 43 Lifting the Machine .......................... 44 Operation Risk of Injury or Death ......................... 47 Inspecting the Work Area........................ 48 Break-in Period ............................ 48 [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 8 General Daily Checks .......................... 87 Operating the Hood.......................... 87 Lubrication Plan ........................... 88 Engine Oil Viscosity .......................... 89 Checking and Adding Engine Coolant .................... 90 Operator’s Manual | 5100064108 / 3300031444 | SM100 / SM120 | 07/2024 | [en-US] viii...
Page 9 11.6 Drive System............................ 127 11.7 Controls.............................. 127 11.8 Forces .............................. 128 11.9 Weights and Ground Pressure...................... 128 11.10 Vibration ............................. 128 11.11 Noise Values ............................ 128 [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 10 Yanmar Limited Warranty ........................ 136 12.5 Yanmar Power Technology Co., Ltd. Emission Control System Warranty—USA Only ..... 138 Compact Tool Carrier AEM Safety Manual Index ................................ 166 Operator’s Manual | 5100064108 / 3300031444 | SM100 / SM120 | 07/2024 | [en-US]...
Page 11: Foreword
Engine nameplate The engine nameplate identifies the model, displacement, and engine num- ber. The location of the engine nameplate is shown below. Fig. 2: Engine nameplate location [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 12: Machine Documentation
The information contained in this manual is based on machines manufac- tured up until the time of publication. The manufacturer reserves the right to change any portion of this information without notice. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 13: Manufacturer's Approval
Electro-hydraulic Failure mode identifier Permissible exposure limits Personal protective equipment Rated operating capacity Slow moving vehicle Suspect parameter number Standard (hydraulics) ULSD Ultra low sulfur diesel [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 14: Maintenance Items
Hydraulic oil filter 1000463685 Fuel cap 1000340135 Hydraulic oil 5000164672 Hydraulic tank cap 1000340157 Tracks, wide (SM100) 1000513592 Hydraulic tank screen 1000340159 Tracks, wide (SM120) 1000455009 Grease 1000367563 Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 15: Usage
• Operating the machine outside of factory specifications • Operating the machine in a manner inconsistent with all warnings found on the machine and in the operator’s manual [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 16: Residual Risks
• Personal injury from improper lifting techniques • Crushing hazards from improper operation (feet, legs, or arms extending outside of the operator work station) and for other persons in the work zone Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 17: Safety
• Familiarize yourself with the location and proper use of all controls and safety devices. • Know the rules for the jobsite. • Contact Wacker Neuson for additional training if necessary. When operating this machine: [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 18 Be aware of: – Obstacles in the operating and traveling area – Any necessary barriers separating the jobsite from public roads Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 19 • Look out for hazards such as high-voltage lines, underground cables, buried utility lines (electrical, gas, water, communication, sewer), etc., during excavation work. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 20 (for example, ropes and chains). This applies, for example, to lifting and lowering pipes, shaft rings or containers. Wear the following PPE while operating this machine: Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 21: Safety Guidelines For Attachments
• Lower the attachment to the ground before exiting the machine. Installation and removal of attachments • Follow attachment mounting instructions in this operator‘s manual. • Before uncoupling or coupling an attachment with the hydraulic coupler: [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 22: Safety Guidelines For Maintenance
• Spare parts must comply with the technical requirements specified by Wacker Neuson. Contact your Wacker Neuson dealer for assistance. • Replace worn or damaged components. • Replace all missing and hard-to-read labels. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 23: Safety Guidelines For The Engine Control Unit (Ecu)
• Regularly inspect the machine’s electrical components. Immediately re- pair any defects such as loose connections, damaged or corroded con- nectors, or cracked or scorched cables. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 24: Safety Guidelines When Using Internal Combustion Engines
If the machine is no longer used according to its designated use, ensure it is decommissioned or put out of operation and disposed of according to appli- cable regulations. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 25 • Follow all applicable safety regulations during machine disposal. • Machine disposal must be performed in accordance with state-of-the-art standards that apply at the time of disposal. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 26: Vehicle Description
When using these attachments, observe the legal regulations of your country and equip the machine with all the safety equipment re- quired. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 27: Machine Overview
Attachment (options available) Auxiliary hydraulic couplers Tracks Hydraulic oil fill Lift arm Lift arm support device Hood Operator platform Operator presence pedal Tie-down points Lifting points — — [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 28: Labels Overview-Ansi
1000366250 DANGER PELIGRO DANGER 5" 1000398281 1000461827 1000398268 1000398268 WARNING ADVERTENCIA AVERTISSEMENT 1000398268 1000398268 1000540615 1000461833 1000397078 WARNING ADVERTENCIA AVERTISSEMENT Fig. 5: Left, right, back, and front Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 29 WARNING Cancer and Reproductive Harm www.P65Warnings.ca.gov ADVERTENCIA Cáncer y daño reproductivo www.P65Warnings.ca.gov AVERTISSEMENT Cancer ou malformations congénitales www.P65Warnings.ca.gov 5100045462 Fig. 6: Engine bay and operator console area [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 30: Labels Overview-Iso
Vehicle Description 4.4 Labels Overview—ISO Labels Overview—ISO 1000366250 5" 1000398281 1000398268 1000398268 1000398268 1000398268 1000540615 1000461833 1000397078 Fig. 7: Left, right, back, and front Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 31 453kg (1000LB) (1200LB) SM 120 SM 100 ISO 14397 ISO 14397 1000474444 1000463295 1000461824 1000516850 1000463167 1000503651 STOP 1000516849 Fig. 8: Engine bay and operator console area [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 32: Safety Labels
Read and understand the supplied operator’s manual before operating the machine. Failure to do so increases the risk of injury to yourself or others. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 33 High pressure contents can cause injury. WARNING Hot surface and explosion hazards Dangerous heat and contents under pressure. WARNING Explosion hazard Read and understand the operator’s manual. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 34 Hot surface hazard Keep body, loose objects, and clothing away from the surface. WARNING WARNING ADVERTENCIA Injury hazard AVERTISSEMENT Do not stand within 2 m (6.6 ft) of the machine. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 35 1000516850 WARNING Entanglement hazard Avoid all moving parts while the engine is running. WARNING Crushing hazard Keep body, loose objects, and clothing away from the surface. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 36 Carry load low while traveling. WARNING WARNING ADVERTENCIA Injury hazard AVERTISSEMENT Do not carry passengers anywhere on the machine. Do not use the machine as a person lift. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 37: Information Labels
Cancer ou malformations www.P65Warnings.ca.gov congénitales www.P65Warnings.ca.gov 5100045462 NOTICE Ultra low sulfur fuel only NOTICE Lifting point—model SM100 NOTICE Lifting point—model SM120 Information Labels Hydraulic oil fill 1000366250 [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 38 Industry Canada ICES-002 Compliance Label: CAN ICES-2/NMB-2 1000397078 Push in the auxiliary hydraulic connector for 5 seconds to release the pres- 5" sure in the auxiliary hydraulic circuit. 1000398281 Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 39 1000461824 Manual auxiliary control 1000463167 Auxiliary hydraulic flow and ride control (optional) 1000503651 Ignition and rated operating capacity—model SM100 453kg (1000LB) SM 100 ISO 14397 1000463295 [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 40 Ignition and rated operating capacity—model SM120 544kg (1200LB) SM 120 ISO 14397 1000474444 Guaranteed sound power level Read and understand the operator’s manual before operating the machine. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 41: Transportation
► The specified angles (± 5°) must be observed. ► The fastening equipment must be designed for the specified forces. ► Apply the specified forces to tighten the fastening equipment. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 42 At the rear of the machine, each side can be secured to the same side of the transport vehicle as illustrated in the graphics. Make note of the following specifications: Fig. 10: Front and rear tie-down points Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 43: Towing The Machine
► Towing the machine can cause excessive, uneven track wear. ► The manufacturer’s warranty shall not apply to accidents or damage caused by towing. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 44: Lifting The Machine
Lifting points that are cracked or otherwise damaged may fail when lifting the machine. ► Inspect the lifting points on the machine before connecting any lifting de- vices. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 45 • Pay attention to load distribution when attaching the lifting gear. Note the center of gravity. • Make sure no one is in or on the machine. • Stay clear of a raised load. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 46 Fasten the machine at the crane eyelets with tested lifting gear of suffi- cient dimensions. Carefully raise the machine, slowly position it over the unloading posi- tion, and carefully lower it. Fig. 13: Lifting points Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 47: Operation
Before starting setup or repair work (for example, installing or removing a hy- draulic attachment), release the pressure in the sections of the system and pressure lines that are to be opened. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 48: Inspecting The Work Area
New machines require a break-in period to ensure maximum efficiency. Dur- ing the break-in period, the machine’s moving parts stabilize. This machine has a 6-hour break-in period. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 49: Operation Checklists
– An operator standing on the platform – The operator presence pedal engaged – The parking brake disengaged • Check the parking brake for proper operation. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 50: Adjusting The Operator Platform
Loosening the operator platform Loosen the nut (2) against the operator platform weldment. Loosen the flange nut (1) to pull the bumper spring away from the chassis weldment. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 51: Machine Controls-Standard
5 Left handrail Ground drive joystick control 7 Auxiliary hydraulics switch Auxiliary hydraulic control lever 9 Workgroup joystick control 10 Right handrail 11 Hand throttle 12 12V adapter [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 52: Machine Controls-Eh Aux
► Check before starting the engine that any tools or shop rags used during maintenance have been removed from the area. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 53 Wacker Neuson dealer or service center for assis- 100046182 4 tance before operating the engine. Fig. 18: Throttle [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 54: Control Interlock System
If any of these interlocks do not function properly, contact your Wacker Neu- son dealer for service. Do not modify the system. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 55 To disengage the interlock, engage the operator presence pedal before op- erating the auxiliary. For further information on continuous flow operation, see Auxiliary Override on page [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 56: Operating The Machine In Extreme Weather Temperatures
• Make sure the battery is fully charged. • Check to see if the battery connections and the connections to the starter and engine block are clean. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 57 – Holding the auxiliary lever in place when an attachment stops mov- • Avoid driving for excessive amounts of time. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 58: Instrument Display
Operation 6.11 Instrument Display 6.11 Instrument Display The instrument display informs the operator of the operating states, required maintenance, or possible machine malfunctions. Fig. 22: Instrument display Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 59 Down arrow (instrument display) — Instrument display — Right arrow (instrument display) Hydraulic oil temperature Hydraulic oil pressure Engine stop Yellow Engine warning Air filter restriction Engine oil pressure [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 60: Instrument Display Symbols And Functions
Unable to disengage parking brake—auxiliary Unable to disengage parking brake—operator not present Unable to disengage parking brake—engine off Operating hours to next maintenance Operator unsafe shutdown warning Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 61: Instrument Display Pages And Subpages
Use the selector button and to next menu page/set button to navigate the display’s pages and subpages. For further information, see Instrument Dis- play on page Note: Subpage 2.3 is available on the SM120 only. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 62: Machine Status
Subpages 0.3 through 0.5—Diagnostic trouble codes Engine control unit and display error codes are shown on these subpages. For further information, see Diagnostic Trouble Codes on page 121. Fig. 28: Subpage 0.3 Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 63: Machine Options
Use the next menu button (1) and the selector button (2) at the bottom of the instrument display to scroll through the subpages. These subpages allow the user to: Fig. 33: Display arrows [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 64: Instrument Display Settings
While in auxiliary override mode, the parking brake is engaged, and the hy- draulic oil flow for an attachment is continuous. Fig. 37: Page 4.0 Standard controls To engage auxiliary override mode, perform the following: Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 65: Work Lights
• Center the switch to turn off all the lights. • Press the bottom of the switch to turn on all the front (1) and rear (2) work lights. Fig. 40: Work lights switch [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 66: Ground Drive And Loader Controls
(lift arm and attachment tilt). Note: Use the handrails when operating the controls. Fig. 43: Moving the right joystick back to raise the lift arm Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 67 Fig. 46: Moving the right joystick to the right to roll the attachment outward Ground drive control joystick functions The ground drive joystick controls all of the ground drive functions. Note: Use the handrails when operating the controls. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 68 (beyond the maximum lift arm down position) The tilt func- tion can be used while the float function is active. To disengage float, move the workgroup joystick to raise the lift arm. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 69: Cold System Restriction
► Keep the lift arm low to the ground. ► Maintain control of the machine by adjusting the travel and movements speeds for the operating conditions. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 70 • Do not drive the machine in reverse over a curb with no load or the lift arm raised. • If repeatedly driving over a curb is necessary, build a dirt ramp to make the ascent/descent more gradual. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 71: Machine Tip Over
• Ensure the mounting pad on the attachment is clear of any debris to al- low to proper mounting of the attachment. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 72 Fig. 54: Tilting the coupler back 10. Set the lock levers (4) down to the locked position. 11. Check the coupler to ensure the attachment is secure. Fig. 55: Lock levers down Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 73 Move the machine in reverse away from the attachment. Note: Tilting the attachment back reduces the force to set the lock levers in the locked and unlocked positions. Fig. 58: Lock levers, guide, and mount [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 74: Auxiliary Hydraulic Connections
Push the female connector attachment onto the male auxiliary hy- draulic connector (top) (2). Push the case drain connector attachment (if present) onto the case drain line connector (middle) (3). Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 75: Manual Auxiliary Controls
Using Continuous Flow Hydraulics This feature allows the operator to turn on full hydraulic flow in either direc- tion while requiring no additional input from the operator. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 76: Filling And Dumping The Bucket
► Dump the load with the machine on a level surface. Filling the bucket Lower the lift arm. Tilt the bucket so it is flat on the ground. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 77: Recommended Fuels-Diesel And Biodiesel
The rec- ommended fuel complies with the U.S. EPA and ARB protection guidelines. Use the same diesel fuel that is used in cars. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 78: Refueling The Machine
► To prevent static electricity buildup when transferring the fuel from the pump to the container, place the fuel container on the ground. Hold the hose nozzle firmly against the side of the container while filling it. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 79: Lift Arm Manual Override
Procedure Stand on the operator platform and engage the operator presence pedal. Turn the ignition key to position 1. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 80: Lift Arm Support Device
Step onto the platform and start the engine. Slowly lower the lift arm to the ground. Stop the engine and step off the platform. Fig. 70: Install pin Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 81: Parking The Machine
Turn the ignition key to the OFF position to stop the engine. Step off the operator platform. Chock the tracks. Make sure the parking brake pins are engaged (at least one). [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 82: Factory-Installed Options
Stop the engine and turn the key to position 1. 453kg (1000LB) Press the ride control button. Turn the key to position 0. SM 100 ISO 14397 100046329 5 Fig. 74: Ignition key position 0 Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 83: Maintenance
• After cleaning, examine all fuel, lubricant and hydraulic oil lines for leaks, chafe marks, and damage. • Do not use the attachment or work equipment as lifting platforms for per- sons. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 84: Maintenance Label
I Check the functions and fluid levels, filling up and draining. II Check parts for wear, seals, hoses, and threaded fittings. III Check for damage, corrosion, or dirt. Replace if necessary. IV Lubricate daily after operation. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 85 [} 105] replace as needed. Check the tracks (damage, tension, profile). [} 107] Check the undercarriage for loose bolts and nuts. [} 105] — Drain the water separator. [} 98] [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 86 1) This maintenance task should be performed by a qualified technician. Contact an authorized YANMAR industrial engine dealer or distributor for assistance. 2) This maintenance task should be performed by a qualified technician. Contact an authorized Wacker Neuson dealer or service center for as- sistance. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 87: General Daily Checks
Push down firmly to engage the rubber latches. Install the lock (if applicable). Fig. 76: Hood lock eye [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 88: Lubrication Plan
Torques on page 129. Lubrication Plan Fig. 78: Lubrication points Lubricate the specified lubrication points once a day. For the recommended grease to order, see Maintenance Items on page Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 89: Engine Oil Viscosity
► Take steps to avoid inhaling or ingesting used liquids. ► Wash skin thoroughly after exposure to used liquids. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 90: Checking And Adding Engine Coolant
► Wear eye protection when handling the engine coolant. ► Tighten the radiator cap securely after checking the radiator. Steam can escape during engine operation if the cap is loose. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 91: Checking And Filling The Hydraulic Oil
Damage to the hydraulic system can occur if the hydraulic oil is drained and not refilled properly. When draining and refilling the hydraulic system, see Replacing the Hy- draulic Oil and Filter on page 111. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 92: Testing The Control Interlock System
To enable the ground drive, loader lift and tilt, and auxiliary hydraulics, the operator must complete all of the following actions: Stand on the operator platform and engage the operator presence pedal. Start the engine. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 93 Turn the key switch to position 2 to start the engine. ð The starter should not engage. Repeat steps 4 and 5 with the auxiliary hydraulic control lever pulled backward. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 94: Checking For Leaks
ð Check for broken, loose, or missing parts, such as nuts, bolts, and brackets. ð Inspect all hydraulic hoses for signs of wear or cracks and replace if needed. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 95: Checking The Engine Oil
When Every 10 hours or daily Requirements • Machine parked on a level surface • Machine shut down and cool to the touch [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 96: Checking The Exhaust System
A leaky exhaust system adversely affects machine operation. Symptoms in- clude increased noise and visible soot deposits. Leaking exhaust can also ignite surrounding materials and pipe insulation, causing a fire. Procedure Open the hood. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 97: Checking The Continuous Flow Shutoff System
Repeat steps 3 and 4 with the auxiliary hydraulic control lever pulled fully backward. If the continuous flow system does not function properly, contact an autho- rized Wacker Neuson dealer or service center for assistance. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 98: Draining And Cleaning The Water Separator
Raise the lift arm and secure the lift arm support device. For further in- formation, see Lift Arm Support Device on page Fig. 88: Water separator location (battery and hood hidden for clarity) Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 99 Prime the fuel system by turning the key switch to the ON position (po- sition 1) for 10 to 15 seconds. 10. Check for any fuel leaks. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 100: Cleaning The Machine
Regular cleaning is essential for keeping the machine in serviceable condi- tion. It is important to remove dust and dirt from the machine as soon as possible after work has been completed. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 101: Changing The Engine Oil And Filter
Environment Use a suitable container to collect, store, and dispose of drained fluids and lubricants in accordance with current environmental protection regulations. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 102 Remove the three bolts (4) securing the cover plate (5). Place a suitable container under the oil filter to catch used oil. Fig. 94: Bolts and cover plate Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 103: Checking And Adjusting The Drive Belts
► Shut off the engine before carrying out work in the engine compartment. ► Shut off the power supply. ► Let the engine cool down. When • After the first 50 hours • Every 250 hours [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 104 After adjusting the tension, run the engine for at least 5 minutes. Check the tension again using the specifications for a used V-belt. Fig. 100: Clearance between V-belt and pulley groove Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 105: Checking The Undercarriage
Inspecting Hoses and Hard Lines When Every 50 hours Procedure Inspect hoses and lines periodically (at least weekly) for signs of wear. Ob- serve the following: [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 106: Servicing The Air Cleaner
• Machine parked on a level surface • Machine shut down and cool to the touch • Damp cloth Overview The air cleaner is located in the engine compartment. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 107: Checking And Adjusting Track Tension
Every 50 hours Requirements • Machine parked on a level surface • Machine shut down • Plastic sheet to protect work surface • Floor jack and jack stands [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 108 Slowly turn the valve counterclockwise to release the grease into a suitable container. ð The grease flows out of the groove of the valve. Tighten the valve until it is snug. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 109: Checking And Cleaning The Radiator Fins
Lift Arm Support Device on page Use a low pressure water stream to clean dirt from the surface of the Fig. 106: Radiator and front panel radiator. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 110: Replacing The Fuel Filter
Interrupt the fuel supply by turning the fuel valve (1) 180° to the CLOSED (up) position on the water separator (2). Fig. 107: Water separator location Remove the side panel next to the fuel filter. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 111: Replacing The Hydraulic Oil And Filter
• Machine parked on a flat, level surface • All hydraulic cylinders retracted (lift arm down, coupler rolled in) • Machine shut down • Replacement oil • Replacement filter [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 112 Loosen the hose clamp (8) and carefully remove the hose from the oil cooler. Once all the hydraulic oil has drained, install the hose and secure it with the clamp. Fig. 112: Hose and clamp Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 113 Remove the panel from the machine. Place a suitable container under the filter to catch any fluid. Fig. 115: Rear access panel [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 114: Replacing The Hydraulic Tank Filler Cap
Install the new hydraulic tank filler cap. Rotate the access plate back into place. Install the retaining bolt. Tighten the pivot bolt. Fig. 118: Hydraulic tank filler cap Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 115: Maintaining The Battery
YANMAR before using the equipment in such an environment or the warranty is voided. When • Every 50 hours—check the battery for damage; check cables and con- nections, and recharge [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 116: Engine-Jump-Starting
CAUTION Personal injury hazard Electrical arcing can cause severe personal injury. ► Do not allow positive and negative cable ends to touch. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 117 Ensure all controls are in neutral and that the key switch is off. Use a machine with a battery of the same voltage as is used with your engine system. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 118 10. Disconnect the positive cable clamp. 11. When using light or high amperage draw accessories, idle the engine for a period of 20 minutes to bring the battery to charge state. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 119: Fuse And Relay Box Layout
K151 Aux. letdown K157 ECU main K169 Starter safety interlock K186 Aux. electric “K” K902 Main ignition Fuses F002 Starter solenoid F003 Glow plugs F004 Main ignition [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 120 F033 12V outlet / work lights F034 Parking brake / workgroup / fuel pump / miscella- neous Diode V001 Parking brake-workgroup ISO V003 ECU supply ISO Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 121: Troubleshooting
(SAE J1843) 15 Accelerator Pedal Position Sensor "A" : Not available (SAE J1843) 4 Accelerator Pedal Position Sensor "B" : Shorted to low source [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 122 4 Cold Start Device : Circuit fault A 3 Cold Start Device : Circuit fault B 2 Cold Start Device : Intermittent fault 4 Oil Pressure Switch : Shorted to low source Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 123 7F9E8 522728 12 E-ECU internal fault : Engine Map Data Version Error 7F9EA 522730 12 Immobilizer : CAN Communication fault 8 Immobilizer : Pulse Communication fault 1202 2 Immobilizer: System fault 1) Yanmar original diagnostic trouble code [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 124: Shutdown
• Use a stabilizer with a biocide to restrict or prevent bacteria and fungus growth. • Add the correct amount of stabilizer per the manufacturer’s recommen- dations. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 125: Machine Disposal And Decommissioning
• Dispose of all non-hazardous components that cannot be recycled. • Dispose of waste fuel, oil, and grease in accordance with local environ- mental protection regulations. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 126: Technical Data
3.22 (3.41) Coolant type — 50/50 ethylene glycol / water (OAT, ASTM D6210) Coolant capacity L (qt) 6.88 (7.25) Fuel Tank capacity L (gal) 53.5 (14.1) Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 127: Electrical System
Hydraulic pilot Pattern Workgroup type ISO manual lever Engine speed Electronic dial Service brake Hydrostatic trans Parking brake Spring applied pressure release (SAPR) Parking brake control Automatic/switchable [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 128: Forces
(rubber) tracks service weight ≤ 4,500 kg (9,921 lb) 11.11 Noise Values Overview of Noise Parameters dB(A) Vehicle with engine 3TNV80FT Average sound power level LwA 100.8 Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 129: Tightening Torques
M27 x 2.0 1,100 (811) 1,550 (1,143) 1,800 (1,328) 920 (679) 1,300 (959) M30 x 2.0 1,500 (1,106) 2,150 (1,586) 2,500 (1,844) 1,300 (959) 1,850 (1,364) [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 130 137.0 ± 9.8 226.0 ± 9.8 kgf m 1 .1 ± 0.1 2.6 ± 0.3 5.0 ± 0.5 9.0 ± 1.0 14.0 ± 1.5 23.0 ± 2.0 Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 131: Dimensions
Technical Data Dimensions 11.13 11.13 Dimensions Fig. 123: Machine dimensions [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 132 Bucket width mm (in.) 914.4 (36) 1,070 (42) Overall height mm (in.) 1,478 (58.2) Track width mm (in.) 230 (9.1) 280 (11) Maximum rollback at ground degrees Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 133: Emission Control Systems Information And Warranty-Diesel
• Removing or altering of any part of the air intake, fuel, or exhaust sys- tems. • Altering or defeating the speed-adjusting mechanism causing the engine to operate outside its design parameters. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 134: Limited Defect Warranty For Exhaust Emission Control System
EPA regulations. All defective parts replaced under this warranty become property of Wacker Neuson. System Covered Components Exhaust system Flex section of the exhaust pipe Tail pipe Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 135 You must take your Wacker Neuson engine/equipment along with proof of original purchase date, at your expense, to the authorized Wacker Neuson dealer/service center during their normal business hours. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 136: Yanmar Limited Warranty
Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 137 YANMAR Operation Manual, unauthorized alterations or modifications, ordinary wear and tear, and rust or [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 138: Yanmar Power Technology Co., Ltd. Emission Control System Warranty-Usa Only
2023, 2024, or 2025 model year industrial compression-ignition engine. California-certified, new off-road compression- ignition engines must be designed, built and equipped to meet the State's Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 139 This warranty is transferable to each subsequent purchaser for the duration of the warranty period. YANMAR recommends that repair or replacement of any warranted part will be performed at an authorized YANMAR dealer. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 140 Since emissions related parts may vary slightly between models, certain models may not contain all of these parts and other models may contain the functional equivalents. Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 141 Keep a log of the number of hours the en- gine is operated for both emergency use and non-emergency use. Also, note the reason for the operation. [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 142 Final Word to the User ......47 Acknowledgment We wish to acknowledge the contributions of the members of AEM’s Compact Loader/Compact Excavator Council to the preparation of this Safety Manual.
Page 143: Foreword
Foreword This safety manual is intended to point out some of the basic safety situations that may be encountered Read and during the normal operation and maintenance of your Understand machine and to suggest possible ways of dealing with Manuals Before Operating these conditions.
Page 144: A Word To The User/Operator
A Word to the User/Operator It is YOUR responsibility to read and understand the Remember that YOU are the key to safety. Good safety manual and the manufacturer’s manuals before safety practices not only protect you but also protect operating this machine. This safety manual takes you the people around you.
Page 145: One-Call First
One-Call First service. Always inspect the jobsite for evidence of unmarked utilities and contact others if necessary. Plan Your Work Call Before You Dig Be aware of the lead time for marking in your area. This Dial 811 (USA only) time may vary from state to state and county to county.
Page 146 Follow a Safety Program Be Alert! For Safe Operation Know where to get assistance. Know how to use a first You must be a qualified and authorized operator for safe aid kit and fire extinguisher/fire suppression system. operation of your machine. You must clearly understand the written instructions supplied by the manufacturer, Be Aware! be trained—including actual operation of the compact...
Page 147 Follow a Safety Program Some Rules You Must Work By Know — Know the capacity and operating characteristics of Weight of your compact tool carrier. Do not overload it. Load — Never modify or remove any part of the equipment (except for service—then make sure it is replaced).
Page 148: Prepare For Safe Operation
Prepare for Safe Operation Check the Machine Before you begin your workday inspect your compact Maintain tool carrier and have all systems in good operational Machine condition. Do not operate the machine until all problems are corrected. — Perform daily and periodic service procedures as instructed by the equipment manufacturer.
Page 149 Prepare for Safe Operation Know the Work Area Before you operate the compact tool carrier, learn as Walk much as possible about the work area. Walk around Around the the worksite and inspect the surfaces you will travel on Worksite when using the compact tool carrier.
Page 150 Prepare for Safe Operation Plan Your Work Before you operate, plan how and where you will travel, Avoid Ruts turn and pick up, lift and place loads. and Ditches Choose a smooth level route to prevent possible tipover or loss of load. If possible, avoid crossing: —...
Page 151: Start Safely
Start Safely Start the Machine Before starting the compact tool carrier and operating Keep the machine, walk completely around the compact tool Bystanders carrier and check that it is clear of personnel. Away — Clean your footwear and wipe your hands before using the compact tool carrier.
Page 152: Operate Safely
Start Safely Check Attachment and Coupler Installation When changing buckets or installing attachments follow Read and the manufacturer’s instructions for proper maintenance Understand and coupling. Make sure all connectors are securely Manuals fastened. Tighten all bolts, nuts and screws to torques recommended.
Page 153 Operate Safely Remember These Rules: (continued) — Never leave the compact tool carrier unattended with- out lowering the lift arms, placing the attachment flat — Always make sure the work area is clear of other on the ground and safely shutting down the machine machines and personnel.
Page 154 Operate Safely Transporting Loads After engaging the load, tilt the load back to position it Carry Load for travel. Keep the load level when lifting. Lift the load only high enough to clear obstacles that may be in the path of the compact tool carrier. Carry the load as close to the machine as possible to: —...
Page 155 Operate Safely Traveling on Slopes and Inclines You must exercise additional care if operating on slopes Do Not Travel or inclines. Driving on slopes and inclines can be with Lift Arms dangerous and result in a tipover or loss of load. Raised WARNING! Do not travel on slopes or inclines with lift arms elevated.
Page 156 Operate Safely Follow these important practices when lifting loads: — The load must be centered when lifting. The likelihood for the compact tool carrier to tip is greatly Operate Controls increased if the load is not centered before lifting. Smoothly —...
Page 157: Shut Down Safely
Operate Safely Watch Out For Hazardous Working Conditions If necessary when working under hazardous conditions, use a second person to warn of dangers. Make certain Be alert for hazards. Know where you are at all times. they do not get too close to the loader. Watch for branches, cables and doorways.
Page 158: Load And Unload Your Machine
Load and Unload Your Machine Loading and Unloading the Compact Tool Carrier When transporting the compact tool carrier, follow the manufacturer’s recommendations for loading and unloading. Precautions — Keep bystanders out of the loading and unloading area. Load and — Load and unload on a level surface. Unload Safely —...
Page 159 Perform Maintenance Safely WARNING! Prevent death or serious injury from manufacturer’s manuals or consult your equipment entanglement. Do not wear loose clothing dealer for proper procedures. or accessories. Stay away from all rotating Keep pockets free of all objects that could fall out—and components when the engine is running.
Page 160 Perform Maintenance Safely Use Proper Ventilation Make sure the hoists or jacks you use are in good repair. Never use jacks with cracked, bent, or twisted parts. If it is necessary to run an engine in an enclosed area, Never use frayed, twisted or pinched cables. Never use remove the exhaust fumes from the area with an bent or distorted hooks.
Page 161 Perform Maintenance Safely Hydraulic System Hazards When venting or filling the hydraulic system, loosen the filler cap slowly and remove it gradually. The hydraulic system is under pressure whenever the Never reset any relief valve in the hydraulic system to a engine is running and may hold pressure even after the pressure higher than recommended by the manufacturer.
Page 162 Perform Maintenance Safely Avoid Explosion — Observe the polarity of the batteries and connections. — Make the final cable connection to the engine or the WARNING! Avoid possible serious injury from furthest ground point away from the battery. Never explosion. Lead-acid batteries produce extremely make the final connection at the starter or dead explosive gases especially when being charged.
Page 163 Perform Maintenance Safely WARNING! Explosive separation of a tire and/or rim WARNING! Explosive separation of a tire and/or rim parts can cause serious injury or death. Always follow parts can cause serious injury or death. Always use the manufacturer’s recommendations or see your a safety cage or cable restraints when inﬂating a tire supplier.
Page 164 Perform Maintenance Safely Check tracks, rollers and idlers for: — Damaged or worn tracks. — Correct tension according to manufacturer’s Check for instructions. Track Damage — Proper lubrication – track rollers and idlers. Refer to the manufacturer’s manuals. Track Adjustment Follow Track tension is important for good performance, Maintenance...
Page 165: Final Word To The User
Your knowledge of these safety operating a Compact Tool Carrier easier and safer precautions and your application to the basic rules for you. This manual is one in a series on the safe operation of machinery, published by AEM. FORM CTC–0803...
Page 166 56 Hot temperatures, operation in ........ 57 Cold weather Hydraulic coupler cold system restriction........ 69 attachment installation and removal .... 21 Connecting hydraulic hoses ........ 74 Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 167 .......... 21 training.............. 17 Overhead electric lines .......... 19 Parking brake ............ 51, 52 Parts replacing ............. 22 Performing maintenance and repairs ...... 83 [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 168 77 tightening torques.......... 129 track tension ............. 108 Starting and stopping .......... 48 Storage .............. 48 Testing attachment system .......... 73 control interlock system........ 54 Operator’s Manual | SM100 / SM120 | 5100064108 / 3300031444 | 07/2024 | [en-US]...
Page 169 Index [en-US] | 07/2024 | 5100064108 / 3300031444 | SM100 / SM120 | Operator’s Manual...
Page 172 Wacker Neuson America Corporation N92W15000 Anthony Ave Menomonee Falls, WI USA-53051 Tel.: +01 262 255-0500 EMail: info@wackerneuson.com www.wackerneuson.us Material Number: 5100064108 / 3300031444 Language: [en-US]...

This manual is also suitable for:

Sm100 1000423340 1000494879 1000530600 1000473871 1000506633 ... Show all

AEM SM120 Operator's Manual

Table of Contents

Acknowledgment

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AEM SM120

Summary of Contents for AEM SM120

This manual is also suitable for:

Table of Contents
