CLE-500.2
THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF
EQUIPMENT. TO MINIMIZE RISK, YOU MUST FOLLOW THESE RULES:
1.Inspect equipment before each workout. Check that all nuts, bolts, screws and
pop pins are in place and fully tightened. Also, before use, check cylinders for leaking.
Replace all worn parts immediately. Never use machine if any parts are
damaged or missing. Fallure to follow these rules may result in serious injury.
2.Keep clear of the cylinder and all moving parts when the machine is in use.
3.Exercise with care. Perform your exercises at a smooth moderate pace; never
perform jerky or uncoordinated movements that may cause injury.
4.It is recommended that you should workout with a training partner.
5.Do not allow children or minors to play on or around this equipment.
6.If unsure of proper use of equipment, call your local distributor.
7.WARNING: Consult your physician before starting your exercise program. For your
own safety do not begin any exercise program without proper instruction.
OWNER'S MANUAL
The Surgeon General
has determined that lack
of physical activity is
detrimental to your health.
TM
Trademark of United States Fitness Produots Council

Advertisement

loading
Need help?

Need help?

Do you have a question about the CLE-500.2 and is the answer not in the manual?

Questions and answers

Summary of Contents for SteelFlex CLE-500.2

  • Page 1 5.Do not allow children or minors to play on or around this equipment. 6.If unsure of proper use of equipment, call your local distributor. 7.WARNING: Consult your physician before starting your exercise program. For your own safety do not begin any exercise program without proper instruction. CLE-500.2 OWNER'S MANUAL...
  • Page 2 CLE-500 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION (A1)HEX BOLT M8X25L PARTIAL THREAD QTY.4 (A2)ROUND ALLEN HEAD M8x40L PARTIAL THREAD QTY.2 (A3)HEX BOLT M8X60L PARTIAL THREAD QTY.2 (A4)ROUND ALLEN HEAD M10x45L PARTIAL THREAD QTY.2 (A5)HEX BOLT M10X60L PARTIAL THREAD QTY.4 (A6)HEX BOLT M10X100L PARTIAL THREAD QTY.2 (A7)HEX BOLT 3/8"x3"L PARTIAL THREAD QTY.1 inch 1"...
  • Page 3: Hardware Illustration

    CLE-500 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION (B1)NYLON LOCK NUT M8 QTY.2 (C5)M10(I.D.)FLAT WASHER Ø19X2T QTY.4 (B2)NYLON LOCK NUT M10 QTY.8 (C6)M10(I.D.)FLAT WASHER Ø25X2T QTY.4 (B3)NYLON LOCK NUT 3/8" QTY.1 (C7)M10(I.D.)FLAT WASHER Ø27X2T QTY.4 (C1)3/8" ROUDN END CAP WASHER QTY.4 (C8)3/8"(I.D.)FLAT WASHER Ø20X1.6T QTY.2 (C2)M8 SPRING WASHER QTY.6 (C3)M8(I.D.)FLAT WASHER Ø18X1.5T QTY.4 (C9)1/2"...
  • Page 4 CLE-500 ASSEMBLY INSTRUCTIONS HARDWARE ILLUSTRATION D1. Ø5/8"XØ10.5 X 25L STEEL BUSHING(8110-047)-----------[2PCS] D2. Ø1" Flat END CAP(8341-033)-----------------------------------[4PCS] D3. 1"X2" END CAP (9211-009)-------------------------------------[1PCS]  50 ROUND END CAP (9211-087)---------------------------[1PCS]  45 ROUND END CAP (9211-091)---------------------------[1PCS]  60 ROUND END CAP (9211-092)---------------------------[1PCS] D7. 30X60 END CAP(9211-139)--------------------------------------[1PCS] D8.
  • Page 5 CLE-500 ASSEMBLY INSTRUCTIONS PARTS ILLUSTRATION SHEET A1[1PCS] B1[1PCS] C[1PCS] D[1PCS] G[1PCS] F[1PCS] E[1PCS] 6640-008 6640-007 Direction Direction J[2PCS] K[1PCS] I[1PCS] H[1PCS] 8386-101 8830-017 5584-K008 5584-K007 40X80X2TX600 40X80X2TX600 453.5 O[4PCS] N[1PCS] M[1PCS] 9161-049 9121-065 9111-064 CLE500.2-092012 Page...
  • Page 6 CLE-500 ASSEMBLY INSTRUCTIONS Above shows STEP 1 assembled and completed CLE500.2-092012 Page...
  • Page 7 CLE-500 ASSEMBLY INSTRUCTIONS Figure 1 Above shows STEP 2 assembled and completed M8 WASHERØ24 M8X16L ROUND BOLT Ø1/2"X144L SHAFT M8 WASHERØ24 M8X16L ROUND BOLT Figure 1 CLE500.2-062015 Page...
  • Page 8 CLE-500 ASSEMBLY INSTRUCTIONS *:NEED TO LOOSEH BOTH ALLEN HEAD BOLT IN ORDER TO REMOVE SHAFT Above shows STEP 3 assembled and completed M8X16L ROUND BOLT X2 M8 WASHERØ18 X2 BEARING 6201ZZNR Ø12X69L SHAFT CLE500.2-092012 Page...
  • Page 9 CLE-500 ASSEMBLY INSTRUCTIONS Above shows STEP 4 assembled and completed CLE500.2-092012 Page...
  • Page 10 CLE-500 ASSEMBLY INSTRUCTIONS Above shows STEP 5 assembled and completed CLE500.2-092012 Page...
