INSTRUCTION MANUAL
Heat pump controller
L U X T R O N I K
This instruction manual is part of the scope of supply and must be handed over to the user of the plant.
Please keep safely and show to authorized service-technicians, if necessary.
830100bGB160111
SWV 2.20
- Subject to Technical Modifi cations -
Heating and
Cooling Systems
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the LUXTRONIK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alpha-InnoTec LUXTRONIK

Summary of Contents for Alpha-InnoTec LUXTRONIK

  • Page 1 Alpha-InnoTec GmbH Heating and Industriestrasse 3, D-95359 Kasendorf Cooling Systems Tel.: 0049 (0)9228 99060 Fax.: 0049 (0)9228 990629 www.alpha-innotec.com e-mail:info@alpha-innotec.de INSTRUCTION MANUAL Heat pump controller L U X T R O N I K This instruction manual is part of the scope of supply and must be handed over to the user of the plant.
  • Page 2 TABLE OF CONTENTS page LANGUAGE SELECTION: Language German SAFETY RECOMMENDATIONS ⌧ English - Important! Please observe! - French Norvegian GENERAL Czech Application/working mode Italian Scope of supply, accessories ASSEMBLY Wall controller Control circuit board Accessories / sensors Built-in type controller/operating element 10 OPERATING BY ENDUSER The descriptions of all menu screens of the controller The operating device...

  • Page 3: Safety Recommendations

    SAFETY RECOMMENDATIONS The installation and execution of electric works must be carried out by a competent person, taking into account the relevant IEE* safety regulations. * German association of electricians When doing interventions in the device not stated in the technical documentation, the guarantee expires! When doing electric works, switch off all electric circuits.

  • Page 4: Scope Of Supply / Accessories

    GENERAL Scope of Supply / Accessories Application Scope of supply wall controller The heat pump controller may be operated exclu- sively with heat pumps released by the manufac- turer. Controller, including control circuit board with clamping devices ; casing and operating element with “turn-tip- It is intended to be used exclusively for the settings of a controller”...

  • Page 5: Wall Fastening

    ASSEMBLY WALL CONTROLLER Front view: Please unscrew both casing screws only slightly, then take off of the casing. Attention: Switch off power supply voltage before! Rear view: WALL FASTENING 1) Arrange the boring template at the wall and at- tach it with adhesive tape (leave suffi cient la- teral distance to be able to release the casing screws).
  • Page 6 8) 2 x 6 edging screw for opening the cover 3) Screw for opening the click-bracket 9) Connection point for control line 4) Main circuit board Luxtronik 10) Connection point for sensor line 5) Cable ducts with cover 11) Terminal block with power supply...
  • Page 7 CABLE FANNING / ELECTRIC ASSEMBLY WALL CONTROLLER Wall controller cable duct (to be provided by customer) necessary for strain relief cable entry point 230V control line to the heat pump Control voltage 1-230V / N / PE on (Acessories necessary for operation) terminal block (cable cross section max.

  • Page 8: Control Circuit Board

    ASSEMBLY Control circuit board 831107 External return sensor (accessory) Outdoor sensor Service water sensor/-thermostat Sensor mixer 1 (accessories) Remote setting control (accessories) Remote setting control (accessories) Mixer 1 CLOSED Mixer 1 OPEN Heat generator 2 / collective fault Second heat generator 1 Service water circulation pump Supplementary pump / circulation pump Floor heating pump...
  • Page 9 ACCESSORIES Sensors Domestic hot water sensor Position on the north / Sensor (D = 6 mm) north-east side. Do not expose to Hot Water direct insolation! Casing back: Distance between screws: Heat Ex- changer Cold Water As far as not prepared by factory confi guration, assembly at half height of the tank, but above the internal heat exchanger.

  • Page 10: Operating Device

    ASSEMBLY Operating device Please fi nd the detailed assembly description of the operating device in the instruction manual of your heat pump. Hang up the operating device in the two square openings of the front plate (there is an alternative fastening possibility beneath) ...

  • Page 11: Graphics Display

    END USER The operating device STATUS ANNUNCIATOR TURN & TIP BUTTON = green turn select status: heatpump is running correct press confi rm = blinking (for a moment) self-resetting green/red interruption of operation after 3 seconds: = red return to the fault navigation screen GRAPHICS DISPLAY...

  • Page 12: Standard-Screen

    END USER Standard-Screen First screen. This screen serves for quick setting of the heating temperature. The display also appears if you don’t use the operating device for more than 10 minutes; simultaneously, the display lighting will be switched off. When moving the lock-down switch, the display will be illuminated again. Auto + 1.0°C (If a modem is connected which is just communicating with the controller, the...
  • Page 13 END USER Navigation-Screen When turning the switch to the screen below will be displayed. The operation by the end user is basically done by heat pump running since 10 : 45 : 12 heating mode info+settings (When turning the switch, you move back and forth in the menu. At the position of the cursor, the text is displayed on a dark background (reversed).
  • Page 14 END USER Info-setting: heating Settings Auto temp. -> +0.0°C Auto heating day (temperature rise) setv -> 45.0°C night (temperature drop) (fi tter) Auto domestic hot water off-time domestic hot water (fi tter) By return you leave the SETTINGS OPERATION MODE menu and reach the next level Party With button...
  • Page 15 END USER Switching times SETTINGS > HEATING TEMPERATURE If you want to modify the temperature of your heating, Week: Week please turn to. Monday-Sunday 1: 06:00 - 10:00 Auto 2: 16:00 - 22:00 Temp. - > and push the button. The variation from the preset heating curve will be dis- played.
  • Page 16 END USER Info-setting: domestic hot water Settings Auto temp-> +0.0°C Auto setv-> 45.0°C Auto At a push of the button, you confi rm the selection: > settings complete installation SETTINGS > OPERATING MODE > Domestic HOT WATER OFF-TIME The operating modes for domestic hot water are the same You have the possibility to switch to the symbol for dome- than for heating.
  • Page 17 END USER Info-setting: complete installation Settings Auto Temp-> +0.0°C Holidays setv-> 35.0°C ---------- At a push of the button, you confi rm the selection: > settings „complete installation“ OPERATING MODE > INDIVIDUAL SETTING OPERATING MODE > OFF In the above example, HEATING is set to “automatic” and If you want to switch OFF simultaneously heating and do- Domestic HOT WATER to “holidays”.
  • Page 18 FITTER heatpump running since: 10 : 45 : 12 heating mode Heating At a push of the button, you confi rm the selection: > heating > settings survey operating modes: SETTINGS > OPERATING MODE Operating mode Heating Domestic hot water Turn ...
  • Page 19 FITTER SETTINGS > TEMPERATURE +/- SETTINGS > HEATING CURVES Turn the switch and select HEATING CURVES: Settings Mode of operation Temperatur +/- Temperature +/- Settings Heating curve Mode of operation Time programs Temperature +/- Heating curve Time programs This menu corresponds to the fi ne adjustment of the hea- ting curves.
  • Page 20 FITTER The second line shows the parallel translation. SETTINGS > HEATING CURVES > HEATING CIRCLE If the setting of the return temperature changes, the set- ting aside changes analogically (column: Day (rise) When entering the menu, the cursor is standing on the Heat curve Hc heat curve end point (here: 50°C).
  • Page 21 FITTER SETTINGS > HEATING CURVES > HEATING CIRCLE SETTINGS > HEATING CURVES > HEATING CIRCLE Night (lowering) Standard interpretation temperature The third cursor position represents the difference tempe- Heat curve Hc rature for the lowering at night (setting behind the “moon”- symbol).
  • Page 22 FITTER ... you will fi nd the menu: SETTINGS > HEATING CURVES > MIXING CIRCLE Heating curve System: Heating circle DFR/BP/FL ---------- Control CP Mixing circle1 Setting Fixed Tp Screed h. w. mixer When entering the menu, the cursor is standing on the heating curve end point (here: 50°C).
  • Page 23 FITTER SETTINGS > TIME PROGRAM SETTINGS > TIME PROGRAM Settings We recommend to start the setting of the programmers with “week” or “5+2”. Different settings for individual days Mode of operation might be overwritten in the menu. Temperature +/- Heating curve Attention: If you change the settings in the Time programs menu “week”, the other programmers will be...

  • Page 24: Hot Water

    FITTER heatpump running since: 10 : 45 : 12 heating mode Hot water At a push of the button, you confi rm your selection: > domestic hot water SETTINGS > OPERATING MODE SETTINGS > CARE PROGRAMS Mode of op. Care progs ⌧...
  • Page 25 FITTER SETTINGS > CARE PROGRAMS SETTINGS > HIGH-SPEED CHARGE Circulation If there is an urgent need of domestic hot water in spite If there is any circulation pump, you can set 3 switching of the domestic hot water off-time, with the option “high- points per day.
  • Page 26 FITTER heat pump is runnin(g) since 10 : 45 : 12 heating mode cooling By pushing the button, you confi rm your selection: > cooling Please note: Passive cooling only in connection with brine/water heat pump Compact and special cooling package. Set the feature ‚cooling‘...
  • Page 27 FITTER settings > temperature +/- settings > operating mode Settings Settings Operating Mode Operating mode temperature +/- temperature +/- Operating mode: When setting the feature „automatic“ for cooling, the coo- Fixing the set value for the cooling and setting of an out- ling mode will be activated.
  • Page 28 FITTER Heat pump is running Since 10 : 45 : 12 Heating mode Ventilation At a push of the button, you confi rm your selection: > ventilation Attention: The symbol for ventilation will be displayed only if the controller is built-in a Komfort building services centre! MENÜ...
  • Page 29 FITTER SETTINGS > TIME PROGRAM SETTINGS > TIME PROGRAM Switching times Contrary to the heating program, the switching times for the ventilation can be set for DAY as well as for NIGHT. Week (Mon-Sun) This is valid for Week, 5+2 and Day. 5+2 (Mon-Fri,Sat-Sun) Example: Days (Mon,Tue...)
  • Page 30 FITTER SETTINGS > FORCED VENTILATION SETTINGS > INFORMATIONS If you select ‚Informations‘ you can check the settings of Forced Ventilation your ventilation: Activate Terminate Information Interm. vent. is active Temperatures Inputs Outputs up-to-date: When confi rming this selection by you have Automatic activated the intermittent ventilation.
  • Page 31 FITTER SETTINGS > INFORMATIONS NOTE: FILTER EXCHANGE Informations Filter exchange Temperatures Inputs Please exchange fi lter Outputs and confi rm Actual: Automatic After 4 month of operation time of the venting module, the fi lter exchange sign will be displayed. The fi...
  • Page 32 SERVICE heatpump is running since: 10 : 45 : 12 heating mode Service At a push of the button, you confi rm your selection: > service Heats. out output temperature heat source SERVICE > INFORMATION Mixval. 1 in fl ow temperature mixing circle 1 Turn to „information“...
  • Page 33 SERVICE MOT: Motorprotection Service Informationes Temperatures Information Informationen On means: motorprotection is OK Inputs Settings Outputs Low pressure: low pressure pressostat Timings Language Operating hours On means: pressure is OK Date and Time Error memeory SW-therm switch: domestic hot water thermostat Disconnections Screed heating Machine status...

  • Page 34: Set Values

    SERVICE Settings Informations Temperatures Access Inputs Short programs Outputs Temperatures Timings Operating hours Priorities Error memory System Settings Disconnections System Ventilation Machine status SERVICE > INFORMATIONS > DISCONNECTIONS SERVICE > SETTINGS > TEMPERATURES Temperatures: Disconnection Limit return 50.0°C ERR-IN010704 10:34 Hystereses HC 3.0K ----------...
  • Page 35 SERVICE HP-Type = heat pump type Tp-defr. air = temperature defrosting air, only for de- vices type LW, if the air defrosting is activated (air, brine, water, Kompakt heating system, central heat station - see table page 45) Setting of the release temperature for the air defrosting.
  • Page 36 SERVICE SET VALUES Service Settings Information Access Short programs Settings Language Temperatures Display Factory Access Range of values settings Date and Time Priorities Screed heating System Settings Electric. no 2.HG no 2.HG / with AS ( ) Installat. conf. System Ventilation suppl.
  • Page 37 SERVICE Electric. suppl. 2nd heat gen. 2 type: no means: without 2nd heat gen.: no 2nd heat gen. is connected, the output has the func- also blocked during off-time by local energy supply companies tion error signal with 2nd heat gen. means: heating rod means: released during off-time by local energy supply companies a heating rod is connected as 2nd heat gen., bivalent...
  • Page 38 SERVICE Serv.-w 2 1CP/2CP - Defr. yes/no display only for devices type SW and WW with two compressors - display only for air-water devices. 1CP means: domestic hot water production with one com- Defr. yes generally releases air defrosting above the set pressor temperature.
  • Page 39 SERVICE Defr/Brin/Flow no/brinepres/fl ow Display only for devices type SW and WW. No means: neither brine pressure pressostat nor fl ow switch are connected Brinepres means: at the brine-water devices, a brine pressure pressostat is connected at the input Defr/Brin/ Flow Flow means: a fl...
  • Page 40 SERVICE Service Settings Service Information Access Information Short programs Settings Settings Language Temperatures Language Date and Time Priorities Date and Time Screed heating System Settings Screed heating Installat. conf. System Ventilation Installat. conf. SERVICE > SETTINGS >SYSTEM VENTILATION SERVICE > LANGUAGE Ventilation: Language German...
  • Page 41 SERVICE Automatic screed heating The temperature data and the relevant time slices of the Service screed heating program will be fi lesaved by the controller; Information thus, the authorized after-sales service partner can read Settings them after the screed heating phase. Language Date and Time Screed heat.
  • Page 42 Errorr diagnosis DIAGNOSIS Display Abr. Description Remedy Error low pressure Low pressure pressostat in the refrigeration cycle Check HP for leakages, switching point presso- has responded once (SW/WW) or several times (LW) stat, defrosting and minimum tempera-ture > Please call AS Low pressure stop Low pressure in the refrigeration cycle has see N°...
  • Page 43 DIAGNOSIS Errorr diagnosis Display Abr. Description Remedy Power screed heat. S-AHP The screed heating program has been stopped Checking of capacity needs during SHP because of too small heating capacity > Please call fi tter Error cooling S-KKP The Hotwater-temperature falls several times Checking of mixer and heating circulation pump under 16°C >...

  • Page 44: Technical Details

    ANNEXE Technical Details Characteristic curve temperature sensor Assembly: Only in frost-proof and dry rooms, protected against T/°C R/kΩ weather 16,538 Ambient temperature 1°C - 40°C. 12,838 230V AC, 18 VA, 0,1 A 10,051 Outputs: - Relay contacts 8A/230V, fi tted with noise suppression 7,931 - Fuse 6,3 A (for all relay outputs), i.e.

  • Page 45: Basic Settings

    ANNEXE Basic Settings Display Factory Settings Range of values Access Limit return 50°C 35-70 AS ( ) Hysteresis Hc 2,0K 0,5 to 3 AS ( ) Return incr. max 1 to 10 AS ( ) Release 2.CP 5°C -20 to 20 AS ( ) Release 2.
  • Page 46 ANNEXE Survey / Explanation of Abbreviations Abbr. Explanation Abbr. Explanation 2. HG1 Second heat generator 1 Release 2. HG Release second heat generator 2. hg1 fct. Function of second heat generator (hea- Ret. target Return target temperature ting or heating + domestic hot water) Room stat.
  • Page 47 The customer is obliged to inform us immediately about compulsory enforcement measures by third parties referring to these goods or any claims or securities Alpha-Innotec GmbH Deutschland assigned to us and he is obliged to transmit us the necessary documentation to Industriestrasse 3 enable us to make an intervention.
  • Page 48 Alpha-InnoTec GmbH Industriestrasse 3 The future of heatpumps D-95359 Kasendorf Tel.: +49 (0)9228 9906 0 Fax.: +49 (0)9228 9906 29 e-mail: info@alpha-innotec.de www.alpha-innotec.com Certified Quality SCOTLAND ENGLAND / WALES Renewable Energy Options Ltd. In view of offering the heat pump MS Frise Ltd.
