General
• The air pump requires an external power adapter (not included) to operate.
• Air pump input voltage / current rating: 5V
5.3 (CFM).
• Make sure the output of the external power adapter, such as USB Wall Charger, Portable
USB Charger, 12V Car Charger or USB Port is rated 5V
operation.
• The pump is suitable for infl ating items with an overall air volume not exceeding 1.3 m
3
46 ft , such as infl atable beach balls, swim rings, tubes, ride-on aquatic toys, kids fl oats,
baby pools, single or double users air mats or lounges, single height queen size airbed or
camping mats.
• No specifi c air pump maintenance is required. Air pump has no user serviceable parts.
1. Attach a suitable nozzle to the infl ation or defl ation connector if necessary and hold pump
against infl ation valve on item to be infl ated or defl ated. See Fig (1).
OR
INFLATION
2. Plug the small end of the USB cable into the USB socket under the pump. See Fig (2).
3. Connect the other end of the USB cable to one of the following external power adapters
(not included):
• USB Wall Charger rated 5V
• Portable USB Charger rated 5V
• 12V Car Charger rated 5V
• USB Port rated 5V
USB Wall Charger
FIG (3)
SAVE THESE INSTRUCTIONS
(55IO) AP635 MINI USB ELECTRIC AIR PUMP ENGLISH 4.875" X 7.25" 05/17/2022
OPERATING INSTRUCTIONS
/ 2A or more. See Fig (3).
/ 2A or more. See Fig (4).
/ 2A or more. See Fig (5).
/ 2A or more. See Fig (6).
Portable USB Charger
FIG (4)
Page 2
/ 2A or more. Minimum air fl ow: 150 (L/Min) /
/ 2A or more for optimum
FIG (1)
DEFLATION
FIG (2)
12V Car Charger
FIG (5)
55
IO
3
/
OR
5V/2A USB Port
FIG (6)
