1. Assembly
Side Brush
Pressure
Adjustment
1
The handle is mounted by means of knobs. The handle can be fixed in one of two different
positions as shown.
Quick Start Guide
96190
1
Handle Knobs
Main Brush
Pressure
Adjustment
Main Brush
Pressure Reading
Scale
