Kunath Paetzold Manual

Hide thumbs Also See for Paetzold:
Table of Contents

Advertisement

Quick Links

Download this manual
Congratulations
On your new Paetzold by Kunath square recorder.
An excellent choice!
Your new instrument will be a reliable companion with whom to share your
joy in music and many wonderful hours of music-making. We promise!
On the following pages we have put together important information for you
so that you can get to know and understand your instrument and its special
features.
We hope you enjoy reading about and playing your new square bass recorder!
Further information and fascinating videos can be found in the online version of the Paetzold-by-
Kunath manual at https://paetzoldbykunath.info/
If you have a question that is not answered in these pages, please write to us
or give us a call.
We will be happy to answer your question as soon as possible and supplement the manual
accordingly.
E-Mail: info@kunath.com
Tel: +49 (0) 661 968 938 0
Last updated: February 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Paetzold and is the answer not in the manual?

Questions and answers

Related Manuals for Kunath Paetzold

Summary of Contents for Kunath Paetzold

  • Page 1 We hope you enjoy reading about and playing your new square bass recorder! Further information and fascinating videos can be found in the online version of the Paetzold-by- Kunath manual at https://paetzoldbykunath.info/ If you have a question that is not answered in these pages, please write to us or give us a call.

  • Page 2: Table Of Contents

    Table of Contents The sub-sub-great bass................3 The head: bocal vs. direct-blow .............. 7 Handling the instrument................9 Getting started ..................12 Operation of the keys ................13 Tuning and fingering ................17 Care and maintenance ................19 In case of a problem ................... 25 Warranty ....................

  • Page 3: The Sub-Sub-Great Bass

    Sub-sub-great bass The instrument The sub-sub-great bass (Subsubgroßbass/Kontragroßbass – KGB), whose lowest note is C1, sounds an octave lower than notated. Its sounding range: It is playable chromatically over two octaves. The instrument has an overall height of max. 220 cm (87 in.), but can also be assembled in a 210 cm (83 in.) configuration.
  • Page 4 Batteries, charging device, power adapter (as applicable) Maintenance and cleaning accessories (as applicable)
  • Page 5 Instrument assembly Slot the four panels of the instrument stand into the foot of the lower body joint (d). Remove the seal protectors and place them in the case. Place the middle body joint (c) onto the lower joint (d). Pay close attention to the orientation of the keys—the thumb keys to the rear, all other keys facing forward.
  • Page 6 • The middle body joint (c) has keys on opposing sides. It also has seals on both ends. • The lower body joint (d) has the right-hand key group on the front and a large central panel hiding the electromagnetic key mechanism. Gently tighten the ribbed thumb nuts while pressing down on the middle joint (c) to slightly compress the seals.
  • Page 7 After drying, place the protectors back on the joint seals so that they cannot become damaged during storage. Charge the batteries if necessary. About the electronics The sub-sub-great bass is equipped with electromagnetic keys and requires electrical power. You have the option of using rechargeable batteries or an external power supply plugged into an electrical outlet.

  • Page 8: The Head: Bocal Vs. Direct-Blow

    The head joint: bocal vs. direct-blow For every instrument in the Paetzold by Kunath square recorder family there is a suitable head-or heads—as we offer the choice of two, depending on the musical style and the preferred means of expression: The HP-ORIGINAL (with a short bocal and mouth piece) and the DIRECT- BLOW.
  • Page 9 In order to offer more flexibility in adjusting the height of the mouthpiece on our largest square basses, the DIRECT-BLOW heads on our subcontrabass and sub-sub-great bass are provided with an articulated extender. The mouthpiece is inserted into the extender, which itself is then gently inserted while rotating into the windhole (arrow) on the rear of the head joint.

  • Page 10: Handling The Instrument

    A refurbished Paetzold (by Kunath) square bass recorder will sound like a new instrument. The importance of always using the seal protectors...
  • Page 11 Do not grasp or otherwise lift up on the keys of your square recorder When removing your instrument from the case or bag, it is best to grasp the body itself, taking care to avoid the keys. If you should lift the instrument by its keys, you could damage their mechanism.
  • Page 12 The batteries must be removed from the instrument after playing and for storage. When not in use, the power switch should be set to off (center position). When traveling abroad, please pay attention to the country- specific power specifications and use a suitable adapter if necessary.

  • Page 13: Getting Started

    Focus on the hidden beauty within your instrument; your new Paetzold by Kunath square bass will fully reward the effort.

  • Page 14: Operation Of The Keys

    Yet another reason that we can promise you lasting enjoyment of your Paetzold by Kunath square bass. And should a problem arise, we are always there to help.
  • Page 15 Often in a modern composition, the composer will intentionally make use of a percussive effect with the Paetzold keys. This is easily achieved by letting your fingers rapidly and forcefully fall onto the keys.
  • Page 16 Paetzold by Kunath square bass. The double keys for tone holes 6a and 6b thus offer a clever solution here: Although the two holes are a bit far apart, they can be played comfortably with a small movement of the finger thanks to the double keys.
  • Page 17 The electromagnetic key mechanism—very similar to that used in organ building—offers a low-maintenance, effective alternative. In our sub-sub-great bass we use a combination of mechanical and electromagnetic keys. The left hand plays manually operated keys as usual; these are only slightly larger compared to our other square basses.

  • Page 18: Tuning And Fingering

    Tuning and fingering Paetzold by Kunath square recorders are tuned to 442 Hz and largely follow traditional baroque fingering. Thanks to our proprietary 180 degree construction bend(s), our square recorders can be built much smaller than would actually be necessary for the desired tuning.

  • Page 19: Care And Maintenance

    Care and maintenance The surface of your square recorder To preserve and protect the surface, you should gently wipe down your bass recorder from time to time with a lint-free, clean cloth. A few drops of furniture polish on the cloth will help to maintain the silky shine and protect the finish from cracking.
  • Page 20 Replacing the seals You can replace damaged seals on the instrument as follows: Carefully remove the old seals and any adhesive residue. Note the correction orientation of the seals. The larger seal is attached to the lower body joint between the assembly tabs. Peel off the protective film from the larger replacement seal and place it adhesive-side down gently on the lower body section without changing or disturbing its shape.
  • Page 21 Carefully remove the old seals and all adhesive residue. Take note of which seal sits where on the tuning ring. Place the smaller seal with the protective film facing up inside the larger seal of the instrument’s upper body section. Carefully remove the protective film from the smaller seal, making sure that the two gaskets remain in their nested position.
  • Page 22 Disinfection If you share your instrument with other players from time to time or if several people play the same instrument, it is advisable to disinfect the mouthpiece regularly. We recommend Flautisept for this purpose; it is available in our online shop at: www.blockfloetenshop.de Flautisept is safe for player and recorder.
  • Page 23 The two-part axle can be pushed in on one side with a thin knitting needle and carefully drawn out with a fine pliers on the other side until the first key is free. With the help of the pliers, carefully reinsert the axle and push it back in the other direction using the knitting needle until the extraction process can be repeated on the other side and the other keys are free.

  • Page 24: In Case Of A Problem

    If you should still need help, you can contact us by telephone at +49 (0) 661 968 938 0 or by e-mail at info@kunath.com. We are also happy to speak with you via video chat. Your Paetzold by Kunath square contrabass recorder comes with a five- year warranty.
  • Page 25 condensation water is trapped by the condensation plug and drip cup before it can reach the windway. Narrowing of the windway Another type of hoarseness can occur after an extensive period of regular or frequent playing; clearing the windway will not eliminate it and it tends to become more pronounced with continued use of the instrument.
  • Page 26 to help you. Should a lever key begin to make a slight creaking noise, this is in most cases because the cork strip on the rear end of the key is too dry. The addition of a spot of cork grease or key oil on the cork strip will usually take care of the noise.

  • Page 28: Warranty

    Warranty Purchase guarantee Your Paetzold by Kunath instrument comes with a five-year guarantee, beginning from the date of invoice. The guarantee is valid worldwide and relates to the absence of defects in the instrument, including functionality and material or production defects. If a defect should arise during the guarantee period, we will repair the product free of charge or-if necessary—...
  • Page 29 According to the European Directive 2006/66 /EC, defective or used batteries must be collected and disposed of in an environmentally responsible manner. Do not dispose of them in the household waste! Additionally, please dispose of accessories and packaging in such a way that the materials can be recycled.
  • Page 30 The other components of the instrument have been just as ingeniously thought out-and continually improved over the years—such that a Paetzold by Kunath square recorder, as a rule, will play and remain in service far longer, on average, before a visit to the workshop becomes necessary.
  • Page 31 Replacement of all key springs Replacement of axles Replacement of key stop screws Renewal as applicable of cork or seals in bocal, mouthpiece, condensation plug and head joint Replacement of cork on the key levers Replacement of the cork covering on the thumb key. Replacement of screws and washers Adjustment and lubrication of mechanics Replacement of cedar block...

  • Page 32: Accessories

    Accessories For every Paetzold by Kunath square recorder we offer a large number of accessories to make transport, storage, and playing safer and easier. In addition to cases and bags, we offer a variety of stands and supports for your instrument. Microphone pickups for amplification are also available—so equipped, our large basses, in particular, really come into their own.
  • Page 33 Hard case The first and foremost task of our hard case, handcrafted in Germany, is to protect your instrument. The interior offers well-padded individual compartments for the instrument parts and accessories. In this way, the instrument is safely protected from the hard knocks and rigours of everyday transport.

  • Page 34: Instrument Stand

    Instrument stand The instrument stand for your sub-sub-great bass is included with the purchase of your instrument. It consists of four identical legs (wings) that are held in place by means of pins inserted into slots in the base of the instrument.

  • Page 35: Fingering Chart

    Fingering chart...

  • Page 36: Contact Us

    Contact Address Kunath Instrumentenbau Am Ried 7 36041 Fulda, Maberzell Germany Telephone +49 (0) 661 968 938 0 +49 (0) 661 968 938 49 E-Mail info@kunath.com Website www.kunath.com...
