- Page 1 ” Full HD 1080P ATV40FHDG-1123 User Manual AFTER SALES SUPPORT tempo.org/support 1300 002 534 MODEL: ATV40FHDG-1123 PRODUCT CODE: 713503 11/2023...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new BAUHN product. ® Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN are manufactured to the highest standards of performance and safety and, ®... -
Page 3: Table Of Contents
Contents Welcome How to play personal videos, Accessibility photos and music Restart Contents How to set up Google TV app Remote & Accessories Unpack and Prepare Smart TV High Dynamic Range (HDR) What's in the Box Download or Delete Apps TV Guide Stream using Chromecast- Important Tips... -
Page 4: Unpack And Prepare
Unpack and Prepare What's in the Box See the box flap for how Before installing your new TV, check you have everything to handle the TV without needed. damaging it! In the box you will find: A. 40" Full HD Android TV B. -
Page 5: Important Tips
Important Tips • Place the TV on a level surface. • Place the TV away from any source that may generate heat or vibrations. • Make sure there is enough space around vents for airflow. • The remote control works up to 5 metres away from the TV. •... -
Page 6: Attaching The Stand
Attaching the Stand • Unplug the TV from the power outlet before installing or removing the stand. • DO NOT place the TV standing upright without its stand attached; it could damage the remote sensor at the bottom of the TV. •... -
Page 7: Wall-Mounting The Tv
Wall-Mounting the TV • Unplug the TV from the power outlet before wall-mounting. • Contact a professional for assistance with wall-mounting the TV. Required 200mm • VESA Mounting Bracket • 4 x M6*10mm screws (or longer as required) The TV comes with holes on the back panel for use with wall-mounting brackets (bracket not included). -
Page 8: Connect To Power
Connect to Power Don't forget to plug in the TV to the power outlet. Leave the power switched off until installation is finished. Make sure the TV is switched off at the power outlet until you have finished connecting your cables. Connect your Antenna Free-to-air TV in HD (High Definition) Example... -
Page 9: Controls And Connections
Controls and Connections Get to Know your TV On/Standby light and Remote sensor Buttons on the TV • /STANDBY: Press the button to turn on the TV. Press and hold the button to turn the TV off. Bottom View CONTROLS AND CONNECTIONS | 9... -
Page 10: Ports On The Tv
Ports on the TV Connect to your broadband modem using a network cable (not included) for best steaming experience. However, the TV also has built-in WiFi. HDMI IN Use a high-speed All-digital connection between the TV and any HDMI device. Supports Full HD HDMI cable for resolution. - Page 11 You can use this to connect Audio to your TV for AV or Component video AUDIO IN inputs. Requires an AV cable (not included). You can use this to connect your DVD player. Supports Standard Definition (SD) VIDEO IN picture quality. Requires an AV cable (not included). Headphone Connect to your headphones, amplifier, soundbar or audio device, using an AUX cable (not included).
-
Page 12: Remote Control
Remote Control Setup Insert two AAA size batteries according to the polarity markings (+ / -) inside the compartment. Make sure the AAA size batteries are correctly aligned and properly pushed into batteries place. included Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 13: Using The Remote Control
Using the Remote Control Remote Hints and Tips To use the remote, point it towards the remote sensor at the front of the TV. The remote will not operate if its • Do not drop, step on or otherwise path is blocked. impact the remote control. -
Page 14: Remote Overview
Remote Overview : Switch the TV to On or Standby NUMBER BUTTONS (0-9) : Press to select a TV channel directly when (MUTE) : Mute or restore sound watching TV Microphone (lights up when active) INFO : Display additional information : Launch the TV guide : Display system settings EXIT : Quick current interface... - Page 15 : Launch the Netflix app : Launch the YouTube app : Launch Google Play store : Launch Prime Video app (Google Assistant) : Summon the : Go to the next or previous Google Assistant channel : Turn the volume up or down : Switch between input signal sources USB: Enter USB mode...
-
Page 16: On-Screen Set Up
On-Screen Set Up 3. Remote Pairing 1. Press and hold the buttons at the same time Make sure equipment is properly connected (as shown on page for 3 seconds and let go when the indicator light on the 10-11) before connecting the TV to power. remote flashes. -
Page 17: How To Access Other Devices Connected To The Tv
How to access other devices connected to the TV 1. Press the button on the remote control, select your desired input sources and press OK. 2. (OR) select the icon from the Android TV home screen. You can rename the inputs to easily identify the device connected to it by going to: Settings >... -
Page 18: How To Set Up Google Tv App
How to set up Google TV app You can navigate your Android TV using your phone or tablet with the Google TV app. On your smart phone, scan the QR code below and download the Google TV app. 1. After app has downloaded and installed, open up the app. Ensure that both your smart phone and Android TV are using the same Wi-Fi network. -
Page 19: Smart Tv
Smart TV Function Remote Button Before you start using apps, your TV must be Display the Android TV home connected to the internet. screen The speed of your internet connection determines Change the order of apps / the quality of your audio/video experience when you Press and hold OK remove an app from favourites watch streaming content. -
Page 20: Download Or Delete Apps
Download or Delete Apps You can download apps and games for your Android TV through the Google Play Store app. Download apps 1. From the Android TV Home screen, Select the Google Play Store app. 2. Browse or search for apps and games. To browse: Move up or down to view different categories. -
Page 21: Stream Using Chromecast-Enabled Apps
Stream using Chromecast-enabled Apps With chromecast built-in, you can cast content from chromecast-enabled apps and chrome browser on your phones, tablets or laptops to your TV. Make sure to turn "Chromecast built-in always available" to On during the first time setup process. -
Page 22: Using Voice Interaction
Using Voice Interaction Your TV remote has a built-in microphone. To enable Google Assistant, you must pair the remote control with the TV which should have been completed during the initial TV setup. If the remote is not paired, see page 39 for pairing instructions. -
Page 23: Tv Setting Menus
TV Setting Menus Menus Index Menu Navigation Buttons Picture • Picture Mode See the guide below for all the other buttons you'll need to use to adjust and change your settings. • User Mode Settings: • Backlight, Brightness, Contrast, Saturation, Hue, Sharpness •... - Page 24 Channel Apps Power • Recently Opened Apps • Channel Scan • Sleep Timer • Single RF Scan • See All Apps • Picture Off • Channel Skip • App Permissions • Switch Off Timer • Channel Edit • Special App Access •...
-
Page 25: Picture
Picture To access picture settings, navigate from Settings > Device Preferences > Picture Picture Mode : Settings are optimised for viewing in brightly-lit environments such as store-fronts. Standard : Enhanced brightness with lower contrast, colour depth and edges for standing out in very bright places such as storefronts. - Page 26 Gamma Advanced Video Adjust the mid level brightness of the picture. Option Description DNR (Digital Colour Temperature Reduce screen noise to make the image Noise clean. Adjust the on-screen colour temperature. Reduction) In user mode, you can individually adjust white balance by changing R/G/B gain settings.
-
Page 27: Sound
Sound To access sound settings, navigate from Settings > Device Preferences > Sound Option Description Select your preferred sound mode. Sound Style Vivid Sports Auto Balance Adjust the balance between the left and right speakers. Bass Adjust the bass Treble Adjust the treble Sound Surround Turn surround sound effect On/Off. -
Page 28: Channel
Channel To access channel settings, navigate from Settings > Channel Option Description Channels > Channel Scan Automatically scan DTV channels. Channels > Single RF Scan Manually scan DTV channels one frequency at a time. Channels > Channel Skip Hide channels from the channels list. Channels >... -
Page 29: Network & Internet
Network & Internet To access network settings, navigate from Settings > Network & Internet You can set up your TV so that it can access the Internet through your home network using a wired or wireless connection. When you connect an ethernet cable, the TV automatically accesses the Internet. Wireless Network Settings Make sure that you have the wireless router's SSID (name) and password settings before attempting to connect. - Page 30 Wired Network Settings Option Description Not connected Display the network once connection is successful. Make sure you have an ethernet cable connected Proxy settings Manually setup proxy settings. to the TV DHCP: The TV will automatically connect to the network. IP settings Static: Manually assign network settings.
-
Page 31: Accounts And Sign-In
Accounts and Sign-in To manage account settings, navigate from Settings > Accounts & Sign-in and click on the account Option Description Add Account Add your Google account to your TV. Choose Synced Manage which apps are synced with your Google account. Apps Remove Remove your Google account from your TV. -
Page 32: Apps
Apps To access app settings, navigate from Settings > Apps Option Description Recently Displays your most recently opened apps. Opened Apps See All Apps View all installed apps on your TV. Set app permissions for your installed apps. Permissions Special App Modify the APP access settings. -
Page 33: About
About To access about settings, navigate from Settings > Device Preferences > About Option Description System Update Check if a system software update is available. Factory Reset Reset your TV to factory default settings. Status ® View information on IP address, MAC address, Bluetooth address Legal Read up on legal notices and opt out of personalised ads. -
Page 34: Date & Time
Date & Time To access date & time settings, navigate from Settings > Device Preferences > Date & Time Option Description Automatic Date & Use network provided date and time or enable setting update and Time time manually. Set Date Manually set the date. -
Page 35: Inputs
Inputs To access input settings, navigate from Settings > Device Preferences > Inputs Option Description Inputs Select the input source to customize the input name. Allow your TV remote to control other devices (that support CEC) HDMI Control connected via HDMI. Device Auto Power off connected HDMI devices when you switch off your TV. -
Page 36: Power
Power To access power settings, navigate from Settings > Device Preferences > Power Option Description Sleep Timer Select the desired Auto Sleep (Standby) duration. Turn off the screen while sound continues. Press the OK button to turn on Picture Off the screen again. -
Page 37: Screen Saver
Screen Saver To access screen saver settings, navigate from Settings > Device Preferences > Screen Saver Option Description Screen Saver Set the screen saver mode. When To Start Set the screen saver start time. Start Now Select to instantly start the screen saver. Location To access location settings, navigate from Settings >... -
Page 38: Accessibility
Accessibility To access accessibility settings, navigate from Settings > Device Preferences > Accessibility Option Description Audio Type Choose a different audio type. Captions Enable closed captions, to see audio as text on the screen. High Contrast Text Enable high contrast text. Text to Speech Adjust for preferred engine or General settings. -
Page 39: Remote & Accessories
Remote & Accessories To access remote and accessories settings, navigate from Settings > Remote & Accessories In this menu,you can pair Bluetooth speakers, keyboards and other devices. ® To pair the TV remote: 1. Press the buttons for 3 seconds and release when the indicator light on the remote flashes. -
Page 40: High Dynamic Range (Hdr)
High Dynamic Range (HDR) About the HDR feature High Dynamic Range (HDR) is a picture feature on your TV that attempts to mimic the way visuals are perceived in real life by the human eye. By using this feature, this TV can reproduce greater dynamic range of luminosity by capturing and then combining several different exposures. -
Page 41: Tv Guide
TV Guide (Free to air TV) To access the TV guide, press the button on the remote. TV Guide Functions To activate the TV Channels use Function Remote Button buttons to select a channel in the left column, then Select a Program press OK to confirm. -
Page 42: Recording
Recording Important Tips: • Back-up your personal data before plugging in your USB to the TV. We do not assume liability for any loss of data due to misuse or malfunction. • You cannot change channels while in recording mode. •... -
Page 43: Recording Live Tv
Before you can record with this TV (including time-shift recording), you must Recording, scheduled recording and pause insert your USB storage device into the live TV functions only work in DTV mode USB port. (free-to-air). Recording Live TV Playback Press the button then press the Start Recording button to go to Record section, and Record... -
Page 44: Pause Live Tv (Time-Shift)
Pause Live TV (Time-shift) Recording, scheduled recording and pause Temporarily pause the live TV signal, then resume live TV functions only work in DTV mode playback at your convenience. (free-to-air). Before you can record with this TV (including time-shift recording), you must insert your USB storage device into the USB port. -
Page 45: Troubleshooting
Troubleshooting If you experience problems with your TV, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 002 534. Problem Solution Make sure that the batteries are installed with their poles (+/–) in the correct direction. Remove any obstacles between the remote control and remote control sensor on the TV. - Page 46 Problem Solution Ensure that connection to the device is correct and that all cables are fully inserted. There is no picture/ Remove and reconnect all cables connected to the TV and the external devices. Try new cables if possible. sound or distorted picture/sound from Restart the connected devices by unplugging each device's power cord and then plugging it in again.
- Page 47 Problem Solution When using Wi-Fi, make sure the Wi-Fi password is entered correctly. Turn off the access point. Wait for 2 minutes and then turn them back on. Ensure that there are no obstacles between the TV and the access point. (The Wi-Fi strength can be decreased by appliances, cordless phones, stone walls/fireplaces, etc.) Reduce interference by not using or turning off other wireless devices.
-
Page 48: Specifications
Specifications Power consumption Active screen size 100.3cm (diagonal) With stand: 904 x 180 x 563 mm Resolution 1920 x 1080 Dimensions (W x D x H) Without stand: 904 x 80 Refresh rate 60Hz x 516 mm Aspect ratio 16:9 5.4 kg AVI, MPEG-1, Weight... -
Page 49: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging The packaging of your product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can National Television and Computer Recycling be a suffocation hazard for babies and young children, please ensure all packaging materials are out of Scheme reach and are safely disposed of. -
Page 50: Warranty Lnformation
Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 51: Repair And Refurbished Goods Or Parts Notice
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. - Page 52 Online support Visit bauhn.com.au for software updates to keep your TV up-to-date, as well as the latest User Manual for information on the updated features. Warranty returns tempo.org/support Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.
