Fortinet FortiBridge FortiBridge-1000F Quick Start Manual

LED Indicators
LED State
Green
PWR
Off
Green
INT 1, INT 2,
EXT 1, and
EXT 2
Flashing
Connectors
Connector Type Speed
INT 1, INT 2,
EXT 1, 1000Base
LC SFP
EXT 2, and -SX
management
CONSOLE RJ-45 9600 bps
1
Checking the package contents
Default settings
Administrator account
Password
Management IP
Netmask
Management Access
2
Connecting the FortiBridge
• Connect the FortiBridge INT 2 interface to the
FortiGate unit internal interface.
• Connect the FortiBridge EXT 2 interface to the
FortiGate unit external interface.
• Connect the FortiBridge INT 1 interface to the
internal network.
• Connect the FortiBridge EXT 1 interface to the
external network.
• Optionally connect the FortiBridge Management
interface to your network.
• Turn on the FortiGate unit and any network
equipment that was turned off.
• Connect the AC adapter to the power connection at
the back of the FortiBridge unit and to a power
outlet.
The PWR and Bypass Mode LEDs turn on. After a short
time, the FortiBridge unit switches to Normal mode. The
Bypass LED turns off and the Normal LED turns on.
Description
The FortiBridge unit is powered on.
The FortiBridge unit is powered off.
The correct optical fiber patch cable is
connected to the gigabit fiber interface.
Network activity at the gigabit fiber
interface.
Protocol Description
Multimode fiber optic
connections to gigabit optical
networks. The FortiBridge-
1000F is shipped with 4
1000Base-SX Small
Formfactor Pluggable (SFP)
Ethernet
transceivers that you must
insert into the INT 1, INT 2,
EXT 1, and EXT 2 sockets on
the back panel. The
management connection is
optional.
RS-232 Console connection to the
serial command line interface (CLI).
admin
(none)
192.168.1.99
255.255.255.0
Telnet and ping access to the INT 1
Management interfaces.
FortiBridge-1000F

QuickStart Guide

The FortiBridge unit functions as a pass-through device when a
FortiGate unit or FortiGate HA cluster operating in Transparent mode
fails or loses power. The FortiBridge unit bypasses the FortiGate unit to
make sure that the network can continue processing traffic. The
FortiBridge unit is not a firewall or antivirus device. FortiGate services
are not applied when the FortiBridge unit bypasses traffic.
