Summary of Contents for CP Plus CP-ANW-HPU8H2D-N12
- Page 1 Outdoor Network PoE Switch Notice: This Manual takes 8-port switch as an example V3.0.1...
-
Page 2: Table Of Contents
User Manual Table of Contents Foreword -----------------------------------------------------------------------------------------3 Important Safeguards and Warnings ----------------------------------------------------- 4 Main Characteristics -------------------------------------------------------------------------- 5 Installation Guidelines ------------------------------------------------------------------------ 6 Port Description -------------------------------------------------------------------------------- 6 Specification ------------------------------------------------------------------------------------ 7~9 Trouble Shooting & RJ 45 Making Method---------------------------------------------- 10... -
Page 3: Foreword
User Manual Foreword General This manual introduces the features and structure of PoE or others product (hereinafter referred to as "the Device") Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a hazard with a high level of risk, which if not avoided, will result in death or serious DANGER injury. -
Page 4: Important Safeguards And Warnings
User Manual Important Safeguards and Warnings The manual helps you to use our devices properly. To avoid danger and property damage, read the manual carefully before using the device, and we highly recommend you to keep it well for future reference. -
Page 5: Main Characteristics
User Manual Main Characteristics 1.Using network patch cords support power for the wireless AP/CPE and IP camera/PTZ 2.Networking standard: IEEE802.3af/at/bt. 3.Some models have adaptive transmission of 250m 4.PoE Watchdog AI Function: Detection front-end PoE cameras and PD, Automatic detection, Automatic restart. 5.Upload port automatic flip (Auto MDI / MDIX). -
Page 6: Installation Guidelines
User Manual Installation Guidelines Installation Steps: Please follow installation steps as below: 1.Please turn off the signal source and the device's power, installation with power on may damage the device. 2.Use 8pcs network cables to connect 8pcs IP cameras with the product's1~8 RJ45 Ethernet ports; 3.Use another network cable or (optical fiber) to connect switch’s UPLINK port with NVR or computer. -
Page 7: Port Description
User Manual Port Description Indoor PoE++ Switch Items Outdoor PoE++ Switch Items AI PoE++ Switch Power Cable User Manual Outdoor PoE++ Power Cable Mounting Kits User Manual Switch User Manual User Manual Notice: This Manual takes 8-port switch as an example V3.0.1 Notice: This Manual takes 8-port switch as an example V3.0.1... -
Page 8: Specification
User Manual Specification CP-ANW-HPU8H2D-N12 Model 8 * 10/100Mbps PoE Ports (RJ45) Ports 2 * 10/100Mbps Uplink Port (RJ45) Transmission 200Mbps Full Duplex. Rate 10 or 100Mbps Half Duplex Transmission 1~2 ports 250m 10Mbps Distance 3~8 ports 130m 100Mbps Bandwidth 2.0Gbps Network Latency (10 to 100Mbps): ≦16μs (use the 64byte package size) - Page 9 User Manual Specification Model CP-ANW-HPU16G2F1D-N30 15 * 10/100Mbps PoE ports (RJ45) 1 * 10/100/1000Mbps PoE port (RJ45) Ports 2 * 10/100/1000Mbps uplink ports (RJ45) 1 * 10/100/1000Mbps SFP port Transmission 2000Mbps Full Duplex, Rate 10 or 100 or 1000 Mbps Half Duplex Transmission 100Mbps /10Mbps, Auto-Adaption 250m Distance...
- Page 10 User Manual Specification CP-ANW-GPU8G2F2D-N12 Model 8 * 10/100/1000Mbps PoE port (RJ45) Ports 2 * 10/100/1000Mbps uplink ports (RJ45) 2 * 10/100/1000Mbps SFP port Transmission 2000Mbps Full Duplex, Rate 10 or 100 or 1000 Mbps Half Duplex Transmission 130m Distance Bandwidth:24Gbps Network Latency (10 to 1000Mbps): ≦16μs (use the 64byte package size) Performance Specification...
- Page 11 User Manual Trouble Shooting Please find the following solution when the device doesn't work 1. Please confirm if the installation is correct; 2.Please confirm if the RJ45 cable order is in accordance with the EIA/TIA568A or 568B industry standards; 3.The power supply of af / at PoE port is not more than 30W, and the power supply of BT Poe port is not more than 60W;...
- Page 12 Thank You for Choosing CP Plus! Website:- www.cpplusworld.com Email id: - sales@cpplusworld.com; support@cpplusworld.com V3.0.1...
