Asus RT-BE7D00 Quick Start Manual

Quick
Start Guide
RT-BE7D00, RT-BE7D00-1
RT-BE86U , RT-BE6800
BE6800 Dual-band WiFi Router
Router Setup Steps
01
Prepare your Modem
Unplug the power of cable / DSL modem. If it
1
has a battery backup, remove the battery.
Install your Router
02
Plug the adapter into the DCIN port, and press the Power switch.
1
– Via app
[App] On your iOS or Android mobile device, go
3
to the app store, search for ASUS Router, and
download the app.
– Or via web browser
[Wired] Connect your PC to LAN port at the back side
3
of the router using an additional network cable.
Gain Another 10GE LAN Port
01 Set up 2.5GE WAN connection to release another 10GE LAN Port
– Under factory defaults
Connect to the 2.5GE WAN port
Connect the modem to the 2.5GE WAN port with a
network cable.
Connect your modem to WAN port at the back side of the router with the
2
network cable provided.
Power on the modem. Plug modem to the power outlet and power on.
3
Modem back Modem back
[App] On your iOS or Android mobile device, tap Settings > Wi-Fi, connect
4
to the default network SSID shown on the product label on the back side of
the router. Or scan the QR code on the product label to connect the default
network SSID.
[Wireless] Connect to the network with default SSID shown on
the product label on the back side of your router "ASUS_XX".
Login and Connect
[ASUS Setup Wizard] Select "Manual Setting".
1
Hardware Explanations
I/O Ports Overview
Reset button 2.5G LAN 2-4 ports
2.5G WAN/
LED button Power switch
LAN 1 port
DCIN port
USB 3.2 Gen 1 port
(USB 3.0 port)
Specifications:
DC Power adapter DC Output: +19.5V with 2.31A current
Operating Temperature 0~40 C
o
Operating Humidity
50~90%
Check the modem LED lights to ensure the connection is active.
4
The power LED will light up when the hardware is ready.
2
[App] Launch ASUS Router App and follow the
5
instructions to complete the setup.
_
* XX refers to the last two digits
of MAC address. You can find
it on the label on the back of
your router.
[Wired / Wireless] Open a web browser.
4
You will be redirected to the ASUS Setup Wizard. If not, navigate to
http://www.asusrouter.com.
Follow the instructions to
complete the setup.
http://www.asusrouter.com/
[ASUS Setup Wizard] Select "2.5G WAN", then follow the instructions to
2
complete the setup of SSID and login information.
LED Lights Overview
LAN LEDs
WAN (Internet)
LED
10G LED
WPS button
10G WAN/LAN
(Internet) port
USB 2.0 port
+12V with 5A current
Storage 0~70 C
o
Storage 20~90%
If you are using DSL for internet,
you will need your username
/ password from your Internet
service provider (ISP) to properly
configure your router.
Modem front
E23051
Power LED
USB LED
2.4GHz LED
5GHz LED
