In the MEMORY CHANNEL MODE, by turning the
TUNING CONTROL, the OPERATING FREQUENCY
displayed on the frequency display can be changed. This
is very convenient for tuning a slightly off frequency or to
change the operating frequency, or to rewrite the memo-
rized frequency in the selected memory channel.
FOR EXAMPLE:
Now you are operating on 14.271MHz and USB with
memory channel 7. By turning the TUNING CONTROL
clockwise increases the frequency and counterclockwise
decreases one, the same as a VFO.
To tune to "14.295MHz", turn the TUNING CONTROL
clockwise to obtain the desired frequency ''14.295.0"
on the display.
Turning the
TUNING CONTROL.
If you wish to transfer this operating frequency (14.295
MHz) and mode (USB) into a VFO, push the FREQUENCY
TRANSFER (M > VFO) button, and the operating fre-
quency ''14.295MHz'" and mode "USB" are transferred
into the VFO previously selected.
NOTE: Don't push the VFO/MEMORY switch before
pushing the FREQUENCY TRANSFER button to
transfer the operating frequency (at this time,
14.295MHz), or the operating frequency is erased
and the original memorized frequency (14.271
MHz) will be transferred into the VFO.
If you wish to rewrite the memorized frequency in the
selected channel (at this time, '07'') to this frequency
(14.295.0'), push the MEMORY WRITE button, and the
operating frequency '14.295MHz'' and mode ''USB" are
memorized into the memory channel 7.
To change the operating memory channel again, turn the
MEMORY CHANNEL SELECT SWITCH.
5-2-2 MEMORY-WRITE (PROGRAMMING THE
MEMORY CHANNELS)
Any operating frequency and mode can be memorized into
a memory channel.
1. Set the operating frequency and mode to desired ones
by a VFO. For example, set them for "15.725MHz"
and "AM" by using VFO B.
2. Select a memory channel to be memorized by turning
the MEMORY CHANNEL SELECT SWITCH. For
example, select memory channel 10.
3. To check the contents in the memory channel, push the
VFO/MEMORY switch, and the contents are displayed
on the frequency display. If you don't want to rewrite
the contents, select another memory channel which has
erasable contents or no memorized frequency.
(When no frequency has been memorized, only the MHz
and KHz decimals are displayed at the frequency posi-
tion.) After checking, push the VFO/MEMORY switch
again to return to the VFO.
4. One push of the MEMORY WRITE button erases the
previous memorized contents (if any) and memorizes the
displayed frequency and mode into the selected memory
channel (at this time channel 10).
5. Memorize other desired frequencies and modes into
memory channels in the same manner. Memory channel
1 and 2 are used also for the PROGRAMMED SCAN.
For PROGRAMMED SCAN _ operation, refer to
"SCANNING OPERATION" on page 13.
Frequency and mode
to be memorized.
Turning the MEMORY
CHANNEL SELECT SWITCH.
Pushing the
VFO/MEMORY
switch to check
contents of the
channel.
Pushing the VFO/MEMORY
switch to return to the VFO
then pushing the MEMORY
WRITE button.
,
(This is displayed after pushing the
VFO/MEMORY switch.)
5-2-3 MEMORY CLEARING
If you want to clear contents of a memory channel, the
first, select the channel to be cleared, the second, push the
FUNCTION KEY then the MEMORY WRITE button.
=
